Вкл и вне сети инвертор 30 кВт 100 Гибридный солнечный Atess 150 все в одном инверторе с системой питания
5 882,00-6 239,00 $
Гибридный Солнечный инвертор
- Категория: >>>
- Поставщик: Hefei Hefu Import And Export Co. Ltd.Hefei Ltd.
Сохранить в закладки 1601151505919:
Описание и отзывы
Характеристики
Product Paramenters
TECHNICAL SPECIFICATION | ||||||||||
Model | SSE-HL3K6-P1EU | SSE-HL4K-P1EU | SSE-HL4K6-P1EU | SSE-HL5K-P1EU | SSE-HL6K-P1EU | |||||
INVERTER OUTPUT | ||||||||||
Rated Power | 3600W(bypass) | 4000W(bypass) | 4600W(bypass) | 5000W(bypass) | 6000W(bypass) | |||||
Voltage (Nominal or Range) | 230/176~270Va.c, L+N+PE | |||||||||
Frequency (Nominal or Range) | 50/60Hz | |||||||||
Power Factor Range | 0.8 leading to 0.8 lagging | |||||||||
Wave Form | Pure sine wave | |||||||||
Switch Time | <10ms | |||||||||
Current(MaximumContinuous) | 15.6 A a.c | 17.4 A a.c | 20A a.c | 21.7A a.c | 26A a.c | |||||
Maximum Output Overcurrent Protection | Support | |||||||||
BATTERY | ||||||||||
Battery Type | Li-ion/Lead-acid | |||||||||
Voltage (Nominal or Range) | 45-58V | |||||||||
Nominal Battery Voltage | 45-58V | 45-58V | 45-58V | 45-58V | 45-58V | |||||
Discharge Current (MaximumContinuous) | 70/80A d.c | 80/90A d.c | 90/100 A d.c | 100/110 A d.c | 100/110 A d.c | |||||
Charge Current (MaximumContinuous) | 70/80A d.c | 80/90A d.c | 90/100 A d.c | 100/110 A d.c | 100/110 A d.c | |||||
Reverse Connect Protection | Support | |||||||||
PV INPUT | ||||||||||
PV Charging Mode | MPPT | |||||||||
MAX.PV Input Power | 5400W | 6000W | 6900W | 7500W | 9000W | |||||
Max. DC Voltage(V) | 550 V d.c | |||||||||
MPPT Voltage Range(V) | 120-500V d.c | |||||||||
Max. Input Current | 15 A d.c | |||||||||
Isc PV (Absolute Maximum) | 24/24Ad.c | |||||||||
EPS OUTPUT | ||||||||||
EPS RatedOutput Voltage | 230V a.c | |||||||||
EPS RatedOutput Frequency | 50/60Hz | |||||||||
EPS RatedOutput Active Power | 3600W | 4000w | 4600w | 5000w | 6000W | |||||
EPS RatedOutput Apparent Power | ||||||||||
EPS RatedOutput Current | 15.6A a.c | 17.4A a.c | 20A a.c | 21.7A a.c | 26A a.c | |||||
EPS Output Power Factor | 0.8 leading to 0.8 lagging | |||||||||
EPS Output Peak Power | 6600VA | |||||||||
EPS Output Inrush Current | 96Aa.c@ 3μ s | |||||||||
EPS Max.Output Fault Current | 96Aa.c@ 3μ s | |||||||||
EPS Max.OutputOvercurrent Protection | 250Va.c/63 A a.c | |||||||||
Switch Time | <10ms | |||||||||
EFFICIENCY | ||||||||||
MPPT Efficiency | 99 .90% | |||||||||
Euro-efficiency | 0.97 | |||||||||
Max.Efficiency | 0.978 | |||||||||
PROTECTION & FEATURE | ||||||||||
Insulation Monitoring | Yes | |||||||||
Residual Current Monitoring | Yes | |||||||||
Parallel Function | Yes | |||||||||
Protection Degree | IP65 | |||||||||
Certifications | CEI 0 -21, EN 50549 -1, VDE-AR- N 4105, UNE 217002, NTSTYPEA, G99, AS/NZS 4777.2 and so on | |||||||||
Other Protection | Overload/over temperature, shortcircuit protection | |||||||||
GENERAL PARAMETER | ||||||||||
Storage Temperature | -25~ +60 ° C | |||||||||
Operating Temperature | -25- +60 ° C ( Linely derating to 80% when exceed +45 to +60 ° C) | |||||||||
Humidity | 0-100% ( Non-condensing) | |||||||||
Altitude | 2000 m (>2000 Derating) | |||||||||
Noise | < 35dB | |||||||||
Dimensions (L*W*H) (mm) | 556*506*206mm | |||||||||
Shipping Dimensions (L*W*H) (mm) | 650*592*375mm | |||||||||
Machine Weight/ N.W.(kg) | 25.6kg | |||||||||
Active Anti-islandingMethod | Support | |||||||||
DISPLAY & COMMUNICATION | ||||||||||
Display | LED | |||||||||
Interface | CAN/ RS485/Bluetooth/ WIFI/4G/DRM | |||||||||
Company Profile
Customer Photos
VR
FAQ
A: What are your main products?
We mainly manufacture solar systems, solar panels, inverters, controllers, batteries and mounting systems and all related solar accessories..
B: Are you a factory or a trading company?
We are a factory with more than ten years of experience in the production of solar energy series products. You are welcome to visit our factory.
C: Can you print our company logo on the nameplate and packaging?
Yes, we can do it according to your design.
D: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, full support and assistance services.
E: How does your factory conduct quality control?
Quality first. We have a professional QC team to strictly control the quality. Only when the quality meets the requirements, will it be packaged out of the factory.
F: What are your strengths in solar systems?
Fully automatic production line using international advanced production equipment such as Japan and Germany. The price and quality are very competitive, and we have cooperated with well-known brands such as Jinko, JA, TRW, etc.,and can provide large-brand solar energy series products.
B: Are you a factory or a trading company?
We are a factory with more than ten years of experience in the production of solar energy series products. You are welcome to visit our factory.
C: Can you print our company logo on the nameplate and packaging?
Yes, we can do it according to your design.
D: Can you support OEM and field installation?
Yes, as a professional solar system manufacturer, we can provide customers with OEM and on-site installation, full support and assistance services.
E: How does your factory conduct quality control?
Quality first. We have a professional QC team to strictly control the quality. Only when the quality meets the requirements, will it be packaged out of the factory.
F: What are your strengths in solar systems?
Fully automatic production line using international advanced production equipment such as Japan and Germany. The price and quality are very competitive, and we have cooperated with well-known brands such as Jinko, JA, TRW, etc.,and can provide large-brand solar energy series products.
