Products Description
XCMG generator sets provide customers with reliable, safe, energy-saving, environmentally friendly and intelligent backup power source and base station power supply. It can be widely used in mines, ports, communications, transportation, airports, hotels, data centers and other industries. It is suitable for special environments such as isolated islands, deserts, mountains and extremely weather regions.
By using the world's leading power engines, efficient generators and controller systems with different designs, it make diesel generator sets running in the best state with enough power and stable performance.
The design, material selection and manufacture of the silent power station have fully considered its use environment, rainproof, waterproof, snow, soundproof, heat insulation, sunscreen, anticorrosion etc.
For multi machine parallel applications with complex load management, the integrated master control system is combined with the generator set controller to form an unattended fully automatic power management platform. No matter from the operation level or from the security point of view, we will provide reliable guarantee.
Designed to meet international safety standards. Meet modern power management requirements through open communication protocol and dedicated PLC software real time remote monitoring requirements. The compact design is convenient for transportation.
Product Paramenters
One the main parameters of the set | The model of the unit | XHZC-450GF | |
Rated Power | 360KW/450KVA | ||
Standby power | 400KW/500KVA | ||
Rated voltage | 400/230 V | ||
Rated current | 648A | ||
Frequency/Speed | 50Hz/1500RPM | ||
The waste of fuel with full load | 205g/kw.h | ||
Engine specification | Model | KTA19-G3 | |
Rated Power | 450KW/563KVA | ||
Standby power | 470KW/588KVA | ||
No. of Cylinders | 6 | ||
Type | 4 cycle | ||
Aspiration | Turbocharged and Charge Air Cooled | ||
Standby power | 50Hz/1500RPM | ||
Bore*Storke: | 159*159MM | ||
Displacement | 19L | ||
Compression Ratio | 13.9:1 | ||
Lubricating oil capacity | 38L | ||
Cooling system | 74L | ||
Starting way | DC24V starting with electricity | ||
Alternator specification | Brand | XCMG | |
Model | WXHZ-450 | ||
Type | brushless | ||
The connecting way of the phase | three phase four lines | ||
Frequency/Speed | 50Hz/1500RPM | ||
Insulation degree | H degree | ||
Grading Protection | IP23 | ||
Winding connection | Star | ||
Voltage regulator type | AVR | ||
Bearing | Single Bearing | ||
Coating | Vacuum impregnation | ||
Coupling | Flexible disc | ||
Dimensions and Weingts | Open Type | Length | 3400mm |
width | 1200mm | ||
Height | 2100mm | ||
Weight | 3500kg | ||
Silent Type | Length | 4300mm | |
width | 2000mm | ||
Height | 2200mm | ||
Weight | 5500kg |
Product Show
Product Characteristics
Generator Type Selection
One-button Start/ Automatic/ Manual Mode Switch
High-density Wave Sound-absorbing Cotton
High-density wave sound-absorbing cotton
Customer site
Packing and shipping
We have been engaged in foreign trade for more than ten years, and have very rich experience in sea transportation.
According to past cases, each of our goods is intact and delivered to customers on schedule.
We have rich experience in Shipment by by bulk vessel, by Flat rack, by Roro, by container, by railway
About us
In order to meet the requirements of different countries for emission standards, our company and products have relevant
certificates issued by authoritative agencies, you can buy at ease.
Our Advantage:
1 Over 10 Years' Foreign Trade Experience for machinery and parts
2 Rich experience in sea transportation for bulk shipment, flat rack, roro, etc.
3 Enthusiastic sales team with professional technology for machines
4 Plenty of Spare parts support, quick delivery and response
Pre-sale service
Dear friends, before the sale, we will fully understand your needs, according to your machine requirements and your
budget, choose the right model for you, to ensure that you buy high-quality products at a lower price.
At the same time, you are welcome to visit our factory in Guangzhou, Xuzhou, China, we will book hotels, air tickets
and take you to the scenery of Guangzhou, Xuzhou in advance.
After-sale service
After the sale, we will properly arrange the transportation of the machine to ensure that the goods are safely delivered to
your hands. At the same time, we will provide you with technical support 24 hours a day, or send engineers to guide the
installation and operation. If there are any quality problems with the machine, we will solve it for you in the first time.
FAQ
Q1:Which country do you export to? Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,
etc. Middle east:Saudi Arabia,UAE,Jordan,Oman,Syria,Pakistan,etc. Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc. South America:Brazil,Peru,
Chile,Cuba,Venezuela,Mexico,etc. Oceania:Papua New Guinea,Australia,etc.
Q2:What is the proportion of your products export? 75% of our products are exported to all over the world.
Q3:What is the payment term? Payment term is negotiable and there will be favorable payment terms for long-term customers.
TT,L/C,,depending on the cooperation time,country and contract value.
Q4:What kind of logistic service do you supply? FOB,CIF,DAP,ETC.
Q5:What spare parts can you supply? All kinds of spare parts of xcm g, shantui, zoomlion, sinotruck, shacman,
liugong, san y, sdl g, lonking, xgma, etc.
