Product Description




Product Introduction
Rotary vibrating screen machine is designed as a high-precision screening machinery. vibrator sieve sifter is composed of vertical motor,and eccentric weight installed at two ends.We can produce horizontal, vertical, inclined motions by adjusting the upper and lower eccentric weight.Material can be divided into all carbon steel,contact part stainless steel and all stainless steel.

Working Principle
Rotary vibrating screen uses upright motor as the source of vibration, and it is equipped eccentricity hammer on the both sides of motor. Adjust the phase angle on the both sides of the top and bottom to change the movement orbits of the screen surface. It can be equipped with screen cloth cleaning device to avoid clogging effectively. The vertical horizontal and inclined movement of the machine, the track of materials on the screen can be controlled by adjusting the angle of the two eccentric weights.




Features
1.Small size, light weight, saving space.
2.The direction of the discharge port can be adjusted, coarse and fine material automatically discharged.
3.No mesh plug, no powder flying, the smallest screen can be up to 500 mesh (28 microns), the smallest filter up to 5 microns.
4.Single layer rotary vibration screen with unique grid design, long-term use of screen, easy to change screen mesh, only 3-5 minutes, simple operation, easy to clean.
5.No mechanical action, easy maintenance, can be single or multi-layer, contact part of the material is made of stainless steel (except for medical use).
6.Any solid, liquid, powder, granules, slurry materials within a certain range can be screened.




Technical Parameter


Model
Power(kw)
Valid Diameter of screen(mm)
Volume(mm)
Layers
DY-600-1S
DY-600-2S
DY-600-3S
0.55kw
550mm
800*800*680
800*800*780
800*800*880
1
2
3
DY-800-1S
DY-800-2S
DY-800-3S
0.75 kw
750mm
900*900*780
900*900*930
900*900*1080
1
2
3
DY-1000-1S
DY-1000-2S
DY-1000-3S
1.1 kw
950mm
1160*1160*880
1160*1160*1030
1160*1160*1180
1
2
3
DY-1200-1S
DY-1200-2S
DY-1200-3S
1.5 kw
1150 mm
1360*1360*980
1360*1360*1160
1360*1360*1360
1
2
3
DY-1500-1S
DY-1500-2S
DY-1500-3S
2.2 kw
1450mm
1850*1850*1130
1850*1850*1330
1850*1850*1550
1
2
3
DY-1800-1S
DY-1800-2S
DY-1800-3S
3 kw
1750mm
2200*2200*1360
2200*2200*1460
2200*2200*1680
1
2
3




Packing&Shipping


1. Packaging: We usually use wooden boxes, or you can tell us about other requirements.

2. Transportation: We can ship, air or land




Company Introduction




Company Information
Xinxiang Dayong Vibration Equipment Co., Ltd. is a manufacturer of vibrating screens, centrifugal screens, drum screens, rotary screens and conveying equipment. It is equipped with complete testing equipment and strong technical force.

We have a wide range of products, high quality, reasonable price and fashionable design. They are widely used in mining, pharmaceutical, food, chemical, metal powder and other industries.




After Sales Service



1)We provide 12months quality warranty to make sure your machine well runs consistently.

2)Professional engineer design the production line for you.

3)Recommend suitable equipment according to your special demand.

4)Common problem can be solved through web in 24 hours,complex problem can be reacted immediately in 24 hours and solved as soon as possible.


FAQ


Q:What factors I need to get a quotation?
A: Material bulk density, mesh size,deck numbers & ideal capacity for proper type, granularity distribution is recommended. product material requirement (carbon steel Q235A, stainless steel SUS304 or SUS316,etc.) Voltage & Frequency(Hz) is also needed for a precise quotation.

Q:What is the real delivery time of your factory?
A: 7 to 15 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different situations.

Q: How do you ensure the quality of your products?
A: Generally, our equipments are the most durable type in the industry, this is also the feature of the label impression of Dayong for most of our customers at home or abroad.Skilled workers and strict quality control system can ensure every machine with best working performance.

Q: How do your after-sale service work if the product got damaged?
A: In the guarantee time 18 months, our general after-sale service is changing the damaged parts for the customer, but if the damage could be repaired by slight cost, we would wait for the customer's bill for the fix cost and refound this part of cost.(note: Vulnerable parts do not include.)

Q: How could I trust your promise?
A: Firstly, you may check the assessment on our website certified by the appraisal agency Bureau Veritas;

secondly, we attend at least 4 to 6 international industry exhibitions held in China annually, like the Food Ingredients China, China International Battery Fair, CPhI, ICSE BioPh China, ICIF China, etc. We usually met our customers there for negotiation;

Thirdly, company inspection always available, if you have any representative or you would like to come to our site, welcome your visit.
