GoodCut Machinery Hot Sale Engraving Small 9060 1390 CO2 80W 100W 130W 150W Watt Laser Machine for Plastic Acrylic MDF
- Категория: >>>
- Поставщик: Jinan GoodCut CNC Machinery Co. Ltd.Jinan Ltd.
Сохранить в закладки 1601168836387:
Описание и отзывы
Характеристики
High Quality Laser CO2 Laser Engraving machine
Main description
This series models adopt DSP&laser power source, self-developed laser power supply as well as integrated frame-structure. The system’s working performance is stable and reliable.
It is equipped with latest software, Auto CAD, CoreIDRAW, CAD, and other graphical software, and it can directly output pictures.
With dual laser head, the MT-D/F series can ensure two laser tubes or three laser tubes or even four laser tubes work simultaneously.
The system is suitable for large-batch producing industry like patch embroidery.
The advantages of the system are that it can double the processing efficiency and ensure the high quality of cutting. So it can combine saving cost with boosting production optimally.
Specification
| Cutting area | 1300x900mm |
| Laser type | Hermetic and detached CO2 glass laser tube |
| Laser power | 60w, 80w, 100w, 120w, 150w |
| Cooling way | Water cooling and protection system |
| Speed control | 0.1~100% set by software and control panel |
| Location accuracy | ±0.01mm |
| Engraving speed | 0.1~1000mm/s |
| Cutting speed | 0.1~500mm/s |
| Control software | RDWorksV8 |
| Display panel | LCD display |
| Supporting format | BMP, PLT, DXF, AI, DST |
| Software support | AutoCAD,CorelDraw, Photoshop, adobe Illustrator |
| Operating environment | Windows98/2000/XP/win7/8, vista |
| Working voltage | AC110V/60HZ or AC220V/50HZ |
| Running environment | Temperature:0-45°, Humidity: 5%-95% |
| Memory Buffer | 128MB |
| Gross power | <2000W |
| Optional parts | cw5000/cw3000 water chiller, overhead ccd camera |
Advantages
1. Adopt the off-line motion control system which need not be connected to PC operation. Use USB data import, can reserve many processing documents.
2. Co2 Laser Engraving Machine strong and stable mechanical structure and digital control.
3. Imported the American focusing mirror and silicon bottom gilded mirror with thin light spot and cutting force.
4. Equipped with professional industrial cooling water system, so the continuous work performance is very stable.
Application
Application
1. Advertising:
billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel, literal-hole cut, lightbox mold, stamp, mould, seal etc.
2. Woodworking:
MDF,wooden mould, wood planks,bamboo, density board.
3. Decoration:
acrylic, organic glass, double color board, coconut shell, ox horn, ABS board, lamp shade, crafts, crystal, glass, ceramic, stone, metal coating etc.
4. Clothing:
leather, cloth, texitle, shoes, fabric etc.
Sample
Company Information
Jinan GoodCut CNC Machinery Co.,Ltd.
GoodCut has Purchasing department, The design department, The production department, Quality inspection department, packaging and transportation department, The sales department, After sales service department.
We can offer highest quality machine, and competitive price.
Mainly manufacture and sale cnc router, laser engraving, marking, cutting machine,
wood lathe machine, fiber cutting machine, plasma cutting machine, 3D scanner etc.
Jinan GoodCut CNC Machinery Co., Ltd.
The meaning of “GoodCut” brand: Good Quality, Good Price, Good Service
Good Quality
1. 15 engineers with more than 10 years rich working experience, manufacture high precision machines;
2. Three-day 72-hour testing machine inspection, after confirming that the machine has no quality problems, then it will be shipped;
3. 4 QC staffs do strict evaluations on in-coming inspections, in-process inspections and final inspections.
Good Price
1. GoodCut manufactures about 50 sets of machines per month, with a large sales volume. We have long-term cooperation with parts suppliers, can get advantageous prices of parts, so that the price of machine is very competitive;
2. GoodCut aims to develop long-term cooperation with new and regular customers, and to give customers the best prices with the most sincere attitude.
Good Service
1. English manual and video for machine using and maintaining, explaining the operation steps in detail;
2. Professional after-sales service staffs, providing 24-hour online service;
3. Provide free technical training and factory field operation teaching to eliminate customer worries.
