Лучший поставщик подводный ультразвуковой преобразователь погружной
820,00-920,00 $
28 кГц 40 погружной ультразвуковой преобразователь из нержавеющей стали вибрационная пластина
- Категория: >>>
- Поставщик: Guangdong Easy Clean Ultrasonic Technology Co. Ltd.Guangdong Ltd.
Сохранить в закладки 1601173603609:
Описание и отзывы
Характеристики
Products Description
Title goes here.
1. Imported SUS 304 and SUS316L optional（other harder material pls remark).
2. Hard chrome plated surface can be choose.
3. Special gluing process which can ensure highly coupled between ultrasonic transducer and SUS plate.
4. High quality ultrasonic transducer , stable performance and high output efficiency.
5. Optimized ultrasonic vibration and sound field.
6. Single frequency 28KHZ, 40KHZ, 68KHZ, 80KHZ and 120KHZ , other frequencies can be customized.
7. Dual-frequency 28 / 40KHZ , 40 / 80KHZ and 40 / 120KHZ.
3. Special gluing process which can ensure highly coupled between ultrasonic transducer and SUS plate.
4. High quality ultrasonic transducer , stable performance and high output efficiency.
5. Optimized ultrasonic vibration and sound field.
6. Single frequency 28KHZ, 40KHZ, 68KHZ, 80KHZ and 120KHZ , other frequencies can be customized.
7. Dual-frequency 28 / 40KHZ , 40 / 80KHZ and 40 / 120KHZ.
Item | Value |
Place of Origin | Guangdong, China |
Use | Cleaning, dispersion, homogenizing |
Plug Type | US PLUG, UK Plug, AU Plug, EU Plug |
Tank Material | Stainless Steel SUS304/316, or customize |
Service | OEM, ODM, wholesale |
Ultrasonic Power | 0-1500W Adjustable, or customize |
Ultrasonic Frequency | 40kHz or customize |
Transducer Quantity | 30pcs |
Ultrasonic plate Size | 600*250*100MM or customize |
Certificates | CE, ROHS,FCC |
Warranty | 1 year warranty and lifetime technical support |
You can Find below Parameters for this Serie with Different Sizes, or Customize
Model# | Plate Size (MM) | Plate Material | Transducer Qty | Ultrasonic Power (Adjustable) | Ultrasonic Frequency | Timer |
YJ-ZB06 | 305*205*100 | SUS304/316L | 6PCS | 0-300W | 28/40KHZ | 1-99min. |
YJ-ZB12 | 340*280*100 | SUS304/316L | 12PCS | 0-600W | 28/40KHZ | 1-99min. |
YJ-ZB18 | 355*305*100 | SUS304/316L | 18PCS | 0-900W | 28/40KHZ | 1-99min. |
YJ-ZB24 | 430*280*100 | SUS304/316L | 24PCS | 0-1200W | 28/40KHZ | 1-99min. |
YJ-ZB30-46 | 460*370*100 | SUS304/316L | 30PCS | 0-1500W | 28/40KHZ | 1-99min. |
YJ-ZB30-50 | 500*300*100 | SUS304/316L | 30PCS | 0-1500W | 28/40KHZ | 1-99min. |
YJ-ZB30-60 | 600*250*100 | SUS304/316L | 30PCS | 0-1500W | 28/40KHZ | 1-99min. |
YJ-ZB36-55 | 550*450*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB36-60 | 600*400*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB36-70 | 700*400*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB36-80 | 800*350*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB36-90 | 900*300*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB36-100 | 1000*300*100 | SUS304/316L | 36PCS | 0-1800W | 28/40KHZ | 1-99min. |
YJ-ZB48-70 | 700*500*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
YJ-ZB48-80 | 800*500*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
YJ-ZB48-90 | 900*400*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
YJ-ZB48-100 | 1000*400*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
YJ-ZB48-110 | 1100*350*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
YJ-ZB48-120 | 1200*300*100 | SUS304/316L | 48PCS | 0-2400W | 28/40KHZ | 1-99min. |
FAQ
Q:Are you a factory or trading company?
A:We are a leading factory in ultrasonic cleaning field in China for 21years. We have our own factory building including several floors of production sites and offices.
Q:Do the products have CE/ROHS certificate?
A:All of our products are under CE, FCC, KC regulations and compliance to ROHS, REACH.
Q:What frequency is better for my parts?
A:Frequency is suggested based on pollutants in the objects. 28khz frequency is stronger,better for car/motor /truck/ vessel parts(oils, grease, rust, pastes, etc. ); 40khz is better for PCB boards.electronic parts,etc. Higher precision goods, higher frequency.
Q:Why should we use cleaning solution even though we have the ultrasonic cleaner?
A:Proper cleaning solution helps us to get the best cleaning effect.Like washing machine, when we use it to wash clothes, washing powder is needed to have the best effect.
Q:What's the production lead time?
A:For bench-top ultrasonic cleaners, usually we have some in stock.we could ship out in 5 days if the quantity is less than 100pcs. lf the qty is bigger, welcome to consult us. For industrial ultrasonic cleaners, production lead time is 7-30 days depends on styles.
Q:What's the payment method and terms?
A:For sample orders, 100% advance payment is required. For bulk orders,50%/80% deposit before production, the balance before shipment. We accept T/T. The payment terms EXW,FOB, CIF,DAP and DDP are offered.
Q:How about after sales services?
A:One year warranty for all the ultrasonic cleaners. lf any technical problem during warranty time, replacement parts will be sent free Technical support and customer service is also available lifelong.
Q:Do the products have CE/ROHS certificate?
A:All of our products are under CE, FCC, KC regulations and compliance to ROHS, REACH.
Q:What frequency is better for my parts?
A:Frequency is suggested based on pollutants in the objects. 28khz frequency is stronger,better for car/motor /truck/ vessel parts(oils, grease, rust, pastes, etc. ); 40khz is better for PCB boards.electronic parts,etc. Higher precision goods, higher frequency.
Q:Why should we use cleaning solution even though we have the ultrasonic cleaner?
A:Proper cleaning solution helps us to get the best cleaning effect.Like washing machine, when we use it to wash clothes, washing powder is needed to have the best effect.
Q:What's the production lead time?
A:For bench-top ultrasonic cleaners, usually we have some in stock.we could ship out in 5 days if the quantity is less than 100pcs. lf the qty is bigger, welcome to consult us. For industrial ultrasonic cleaners, production lead time is 7-30 days depends on styles.
Q:What's the payment method and terms?
A:For sample orders, 100% advance payment is required. For bulk orders,50%/80% deposit before production, the balance before shipment. We accept T/T. The payment terms EXW,FOB, CIF,DAP and DDP are offered.
Q:How about after sales services?
A:One year warranty for all the ultrasonic cleaners. lf any technical problem during warranty time, replacement parts will be sent free Technical support and customer service is also available lifelong.
Paper Carton Packing
For tabletop small ultrasonic cleaners with product details printed on the carton markings.
Wooden Case Packing
For industrial big ultrasonic cleaners, the product details are printed on the paper stickers then put on the outside case.
