Windproof Structure Steel Office Building prefabricated Commercial Car Showroom
VR
Product Display
Items | Specifications | |
Main structure | PEB Welded H-shaped steel or hot rolled steel, Q355 or Q235 | |
Anti-rust protection | Hot dip galvanized or anti-rust painting | |
Purlins and girts | Cold rolled C or Z steel, Q355 or Q235 | |
Roof and wall | Single layer steel sheet or sandwich panel | |
Gutter | Heavy duty galvanized steel | |
Down pipe | PVC | |
Door | Sliding door or roller shutter | |
Windows | PVC or aluminum alloy | |
Other components available upon request. Please provide the following information for detailed custom design. | ||
Basic Building Parameters We Take into Consideration
Building Width:
No matter what primary framing system is used, the building width is defined as the distance from outside of eave strut of one
sidewall. Building width does not include the width of Lean-To buildings or roof extensions.
Building Length:
The longitudinal length of the building measured from out to out of end wall steel lines
Building Height:
Building height is the eave height which usually is the distance from the bottom of the main frame column base plate to the top outer point of the eave strut. When columns are recessed or elevated from finished floor, eave height is the distance from finished floor level to top of eave strut.
Roof Slope (x/10):
This is the angle of the roof with respect to the horizontal .The most common roof slopes are 0.5/10 and 1/10. Any practical roof slope is possible.
End Bay Length:
The distance from outside of the outer flange of end wall columns to center line of the first interior frame column.
Interior Bay Length:
The distance between the center lines of two adjacent interior main frame columns.The most common bay lengths are 6m,7.5m and 9m.
Design loads:
Design for snow loads,earth quake loads,collateral loads.crane loads or any other loading condition,if required must be specified at the time of request for quotation.
No matter what primary framing system is used, the building width is defined as the distance from outside of eave strut of one
sidewall. Building width does not include the width of Lean-To buildings or roof extensions.
Building Length:
The longitudinal length of the building measured from out to out of end wall steel lines
Building Height:
Building height is the eave height which usually is the distance from the bottom of the main frame column base plate to the top outer point of the eave strut. When columns are recessed or elevated from finished floor, eave height is the distance from finished floor level to top of eave strut.
Roof Slope (x/10):
This is the angle of the roof with respect to the horizontal .The most common roof slopes are 0.5/10 and 1/10. Any practical roof slope is possible.
End Bay Length:
The distance from outside of the outer flange of end wall columns to center line of the first interior frame column.
Interior Bay Length:
The distance between the center lines of two adjacent interior main frame columns.The most common bay lengths are 6m,7.5m and 9m.
Design loads:
Design for snow loads,earth quake loads,collateral loads.crane loads or any other loading condition,if required must be specified at the time of request for quotation.
Basic design requirements and design Load,
1. Project site location;
2. Overall dimension (length*width*eave height in meters);
3. Mezzanine or not? How many kgs of load per square meter on mezzanine?;4. Single-layer steel sheet wall or sandwich panel wall;
5. Snow load if applicable;
6. Wind speed/load;
7. Interior column allowed or not;
8. Overhead crane needed or not, capacity?;
9. Any other particular requirements?
Building Purpose: we will recommend the best design for the purpose of the building.
A. Warehouse/Storage
B. Factory
C. Agriculture Barn
D. Retail Store
E. Repair/Mechanic Shop
F. Office Space
G. Medical Warehouse
H. Animal Farm (please confirm what kind of animal)
Design Strength+Certifications
Widely used prefabricated steel structure gas station petrol station design storage buildings warehouse
Company Profile
Tianying Group is a recognized giant in manufacturing prefabricated strvcture steel, steel sheets, steel coil, prefabricated house and sandwich panels.
Tianying Group has developed products and services now reaching across the globe and serving multiple industries. The group consists of Shenyang Lanying Colored Steel Co, Ltd, Liaoning Tianying Steel Structure Co., Ltd, Harbin Tianying Steel Structure Co., Ltd and Xinghan Steel Material Corporation Limited. With more than 400 employees, we are able to deliver quality products on time at a fair price and serving customers from over 22 countries.
Customer satisfaction is Tianying people's ultimate pursuit. Sustainability is at the very heart of what we do and we are dedicated to managing our operations responsibly and to continuously improve our performance.
Our job is to provide you a strong building with material in superior quality.
Customer satisfaction is Tianying people's ultimate pursuit. Sustainability is at the very heart of what we do and we are dedicated to managing our operations responsibly and to continuously improve our performance.
Our job is to provide you a strong building with material in superior quality.
Our Vision
To be the world's most reliable and innovative manufacturer, service and solution provider in the steel and construction industry.
Our Mission
To supply high-quality steel products, providing related services and solutions to a worldwide client base while utillzing innovative technologies within an environment of motivated employees, focused on continuous improvement ,highest business standards, work ethics, and added value for our customers.
To be the world's most reliable and innovative manufacturer, service and solution provider in the steel and construction industry.
Our Mission
To supply high-quality steel products, providing related services and solutions to a worldwide client base while utillzing innovative technologies within an environment of motivated employees, focused on continuous improvement ,highest business standards, work ethics, and added value for our customers.
Our company's typical steel structure projects are the primary steel frames for wood and paper processing industry, power plants, ship yards, industrial buildings, business centers, office and residential buildings, sport and airport hangars as well as primary steel structures for road, water crossings and pedestrian bridges. The claddings and erection works are often included in the scope of delivery.
Exhibition
Mongolia Exhibition
Dominica Exhibition
Philippine Exhibition
Customer Visit
Project Cases
Advantages of steel structure buildings | ||||||||
1.The components of the steel structure have small section, light weight, easy to transport and installation, suitable for large span, high height, heavy bearing structure. | ||||||||
2.Suitable for withstand impact and dynamic load, with good seismic performance.The internal structure of steel is uniform with high reliability. | ||||||||
3.Factory mechanized production of steel structure components finished products of high precision, high production efficiency,site assembly speed, short construction period. | ||||||||
Our prefabricated steel structure buildings are pre-cut, pre-drilled, and ready for quick and efficient assembly. Steel buildings work for virtually any building application:Agricultural/ Barns/ Aircraft Hangars/ Welding Shops/Commercial center/ Garages/Storage/ Suburban Buildings/ Warehouses/ Workshops/school/wedding hall/dormitory etc. | ||||||||
Packaging Logistics
China Fabricated prefab steel structure workshop metal building structures hangar prefabricated construction
FAQ
Q1: You are manufacture factory or trading company?
A: We are manufacture factory. And you are welcomed to visit us at any time for inspection. The quality control flow and sales team will show you our professionalism. Also, you will get best and most competitive price after visiting us.
Q2: What the quality assurance you provided and how do you control quality?
A: Established a procedure to check products at all stages of the manufacturing process - raw materials, in process
materials,validated or tested materials, finished goods, etc. SGS, BV and other testing are available for us. We could deal with you by Trade Assurance via Alibaba.
Q3: Is your price competitive compared with other companies?
A: Our business objectives are to give the best price with same quality and best quality with the same price. We will do
everything we can to reduce your cost and guarantee you get the best product that you paid for.
Q4: Can you send engineers or whole team to install my project?
A: Yes, we will send you the detailed installation drawing and video for free, we can provide the service of installation,
supervision, and training by extra. We can send our professional technical team to supervise installation on site overseas.
Q5: Do you accept container loading inspection?
A: You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
Q6: Do you offer designing service for us?
A: Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) etc., we can design complex industrial building like office mansion, super marker, auto dealer shop,
shipping mall, 5 stars hotel.
Q7: What is the delivery time?
A: Delivery time depends on order quantities. In general, the delivery time to nearest seaport in China will be 30 days after
receiving deposit.
Q8: How can you get a quotation for your projects?
A: You can contact us by email, phone, Alibaba TM, WhatsApp, Skype, Viber and so on 24*7 and you will get reply within 8 hours.
Q9: How to ensure the product you supply is what we want exactly?
A: Before placing order, our sales and engineers’ team will provide you the suitable solution according to your requirements. Proposal drawing, 3D drawing, Materials’ photos, finished projects photos are available, which will help you understand the solution we provided deeply.
A: We are manufacture factory. And you are welcomed to visit us at any time for inspection. The quality control flow and sales team will show you our professionalism. Also, you will get best and most competitive price after visiting us.
Q2: What the quality assurance you provided and how do you control quality?
A: Established a procedure to check products at all stages of the manufacturing process - raw materials, in process
materials,validated or tested materials, finished goods, etc. SGS, BV and other testing are available for us. We could deal with you by Trade Assurance via Alibaba.
Q3: Is your price competitive compared with other companies?
A: Our business objectives are to give the best price with same quality and best quality with the same price. We will do
everything we can to reduce your cost and guarantee you get the best product that you paid for.
Q4: Can you send engineers or whole team to install my project?
A: Yes, we will send you the detailed installation drawing and video for free, we can provide the service of installation,
supervision, and training by extra. We can send our professional technical team to supervise installation on site overseas.
Q5: Do you accept container loading inspection?
A: You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
Q6: Do you offer designing service for us?
A: Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) etc., we can design complex industrial building like office mansion, super marker, auto dealer shop,
shipping mall, 5 stars hotel.
Q7: What is the delivery time?
A: Delivery time depends on order quantities. In general, the delivery time to nearest seaport in China will be 30 days after
receiving deposit.
Q8: How can you get a quotation for your projects?
A: You can contact us by email, phone, Alibaba TM, WhatsApp, Skype, Viber and so on 24*7 and you will get reply within 8 hours.
Q9: How to ensure the product you supply is what we want exactly?
A: Before placing order, our sales and engineers’ team will provide you the suitable solution according to your requirements. Proposal drawing, 3D drawing, Materials’ photos, finished projects photos are available, which will help you understand the solution we provided deeply.
