Kebos KH-I WP 30 кВт высокоэффективная система питания Mppt трехфазный чистый синусоидальный Гибридный солнечный инвертор с ЖК-дисплеем
369 428,28 ₽ - 380 449,41 ₽
10 кВт ЖК дисплей 3 фазный ветер солнечные гибридные инверторы производители в Китае без литиевой батареи
- Категория: >>>
- Поставщик: Shenzhen Gitenno Technology Co. Ltd.
Сохранить в закладки 1601193142833:
Описание и отзывы
Характеристики
Product Paramenters
MODEL InfiniSolar WP HB 10kw | ||||||||
MAXIMUM PV INPUT POWER | 14500W | |||||||
RATED OUTPUT POWER | 10000 W | |||||||
MAXIMUM CHARGING POWER | 10000 W | |||||||
GRID-TIE OPERATION | ||||||||
Nominal DC Voltage / Maximum DC Voltage | 720 VDC / 900 VDC | |||||||
Start-up Voltage / Initial Feeding Voltage | 320 VDC / 350 VDC | |||||||
MPP Voltage Range | 350 VDC ~ 900 VDC | |||||||
Number of MPP Trackers / Maximum Input Current | 2 / A: 18A, B: 18A | |||||||
GRID OUTPUT (AC) | ||||||||
Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |||||||
Output Voltage Range | 184 - 265 VAC per phase | |||||||
Nominal Output Current | 14.5 A per phase | |||||||
Power Factor range | 0.9 lag ~ 0.9 lead | |||||||
EFFICIENCY | ||||||||
Maximum Conversion Efficiency (DC/AC) | >96% | |||||||
European Efficiency@ Vnominal | >95% | |||||||
OFF-GRID OPERATION | ||||||||
AC INPUT | ||||||||
AC Start-up Voltage / Auto Restart Voltage | 120 - 140 VAC / 180 VAC | |||||||
Acceptable Input Voltage Range | 170 - 280 VAC per phase | |||||||
Maximum AC Input Current | 20 A | |||||||
PV INPUT (DC) | ||||||||
Maximum DC Voltage | 14500 W | |||||||
MPP Voltage Range | 900 VDC | |||||||
Number of MPP Trackers / Maximum Input Current | 350 VDC ~ 900 VDC | |||||||
BATTERY MODE OUTPUT (AC) | ||||||||
Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |||||||
Output Waveform | Pure sine wave | |||||||
Efficiency (DC to AC) | 94% | |||||||
HYBRID OPERATION | ||||||||
PV INPUT (DC) | ||||||||
Maximum DC Voltage | 720 VDC | |||||||
Start-up Voltage / Initial Feeding Voltage | 320 VDC / 350 VDC | |||||||
MPP Voltage Range | 350 VDC ~ 900 VDC | |||||||
Number of MPP Trackers / Maximum Input Current | 2 / A: 18A, B: 18A | |||||||
GRID INPUT | ||||||||
Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |||||||
Output Voltage Range | 184 - 265 VAC per phase | |||||||
Nominal Output Current | 14.5 A per phase | |||||||
AC INPUT | ||||||||
AC Start-up Voltage / Auto Restart Voltage | 120 - 140 VAC / 180 VAC | |||||||
Acceptable Input Voltage Range | 170 - 280 VAC per phase | |||||||
Maximum AC Input Current | 20 A | |||||||
BATTERY MODE OUTPUT (AC) | ||||||||
Nominal Output Voltage | 230 VAC (P-N) / 400 VAC (P-P) | |||||||
Efficiency (DC to AC) | 94% | |||||||
BATTERY & CHARGER | ||||||||
Battery Voltage Range | 204 ~ 408 VDC | |||||||
Maximum Solar Charge Current | 30 A | |||||||
GENERAL | ||||||||
PHYSICAL | ||||||||
Dimension, D x W x H (mm) | 255 x 660 x 600 | |||||||
Net Weight (kgs) | 45 | |||||||
INTERFACE | ||||||||
Communication Port | RS-232, RS-485, USB, CAN and Wi-Fi | |||||||
Intelligent Slot | Optional for SNMP and Modbus cards | |||||||
ENVIRONMENT | ||||||||
Humidity | 0 ~ 100% RH (Non-condensing) | |||||||
Operating Temperature | -25 to 60°C, > 45°C power derating | |||||||
Altitude | 0 ~ 1000 m | |||||||
Why Choose Us
Shenzhen Gitenno Technology Co., Ltd.
Shenzhen Gitenno Technology Co., Ltd. is a comprehensive company dedicated to the research and development, design, production and sales in UPS uninterruptible power supplies and new energy products such as photovoltaic inverters, batteries, energy storage and other products.Shenzhen Gitenno is based in Shenzhen, the core area of the Zhu River Delta Economic Zone and the center of China's R&D and manufacturing as well.
Manufacturing
We are customer-oriented and develop, produce and promote more advanced, efficient and environmentally friendly new energy products and UPS uninterruptible power supplies based on customer and market needs. We have a large-scale R&D team in the industry, with more than 60 R&D personnel, more than 95% of whom have bachelor's and master's degrees or above.
Each worker has more than five years of foreign trade experience. They are well versed in foreign trade processes and familiar with the cultures of various countries. We respect and understand every customer and do our best to satisfy our business partners from all over the world. All of Gitenno people promise that you will receive the most professional and considerate services when cooperating with us.
Product packaging
We trade all over the world, and being responsible for our customers is our number one requirement. Gitenno has the world in mind and is committed to promoting Chinese creations to the world and benefiting people around the world. Our mission is to promote new energy products to every corner of the world and provide green products to the people around the world.
Delivering
Certifications
FAQ
Q: Are you a manufacturer of a trading company?
A: We are a manufacturer as well a trading company.
Q: What are your main products?
A: Our products range from inverter, battery, energy storage to UPS power supplies etc.
Q: Can you provide a sample?
A:Yes, we can provide a sample. But you will pay for it.
Q: What is the production time for a sample?
A: 10-15 days.
Q: What is the production time for mass order?
A: 18-45 days as per the ordering quantity and our production schedule.
Q: Can you accept customized order?
A: Yes, we can.
Q: Can you provide logo printing?
A: Yes, we can. We also can provide different color in logo printing.
Q: What’s your business terms?
A: FOB is common but other business terms is negotiable.
Q: What is your frequently-used payment terms?
A: 1) T.T. 2) Alipay 3) Irrevocable LC 4) Other mode negotiable
Q: What's the FOB port?
A: Tianjin port, Guangzhou Port or Shenzhen Port.
