Настольная волоконно лазерная маркировочная машина 20 Вт 30 50 роторный лазерный гравер для кольца и бутылки гравировальная
- Категория: >>>
- Поставщик: Suzhou Fang Shiheng Precision Machinery Co. Ltd.Suzhou Ltd.
Сохранить в закладки 1601194596044:
Описание и отзывы
Характеристики
Product Overview
FSH series
Intelligent fiber laser marking machine.
The FSH series intelligent laser marking machine belongs to the desktop fifiber laser marking equipment. It is a special model specially developed by Mac Laser for the needs of simple, compact, flflexible and convenient equipment. The equipment is extremely cost-effective, It adopts high-quality fifiber laser source, high-stability galvanometer system, hidden keyboard and mouse design, it can easily meet most common laser marking applications.
The FSH series products use a 1064nm wavelength fifiber laser source, which is suitable for various metal materials such as iron, copper and aluminum, gold, silver, and some non-metal materials such as PC, ABS, PVC, and PC+ABS.
The FSH series products use a 1064nm wavelength fifiber laser source, which is suitable for various metal materials such as iron, copper and aluminum, gold, silver, and some non-metal materials such as PC, ABS, PVC, and PC+ABS.
PRODUCT SIZE
PRODUCT SPECIFICATIONS
Model series | Intelligent mini laser marking machine | ||||
Model | FSH-20W | FSH-30W | |||
Laser parameters | Laser source model | MFP-20X/20QS | MFP-30X/30QS | ||
Output Power | 18.5 | 30W | |||
Beam quality M2 | ≤1.4 | ≤1.4 | |||
Pulse repetition frequency | 27-60 kHz | 30-60 kHz | |||
Laser wavelength | 1064±5 nm | ||||
Output power stability | ＜3% | ||||
Working life | About 100,000 working hours (non-lifetime) | ||||
Optical properties | Marking range | 100~150mm (range optional) | |||
Engraving depth | ≤1mm (depending on power and time) | ||||
Engraving speed | ≤10000mm/s | ||||
Repeat accuracy | ±0.002 | ||||
Minimum marking line width | 0. 1mm | ||||
Minimum character height | 0.15mm | ||||
Use environment | Cooling way | Built-in air cooling | |||
System power supply | 500W / 220V / 50Hz (110V can be connected) | ||||
Temperature humidity | 0~40°, 30% RH 85%, air conditioner should be installed when used outside the range | ||||
Oil mist, condensation | Not allowed | ||||
Other parameters | Support system | Windows operating system | |||
Dimensions | 460X300X683mm | ||||
Packing size | 550X440X690 mm | ||||
Total Weight | About 25kg | ||||
The marking is directly hit on the surface with the help of a strong pulsed laser beam to produce extremely deep, high
contrast markings on the surface, achieving permanent markings with uniform viewing angles, and corrosion resistance
contrast markings on the surface, achieving permanent markings with uniform viewing angles, and corrosion resistance
MARKING EFFECT
MODEL CHARACTERISTICS
Company Profile
Company Advantage
1.A professional team with rich experience more than 20 years in the laser industry.
2.Customized technical solution and after-sales support.
3.ODM/OEM service avaliable.
2.Customized technical solution and after-sales support.
3.ODM/OEM service avaliable.
Packing &Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1.Who are we ?
We are based in Suzhou, China, start from 2003,sell to Western Europe,South America,Southeast Asia,South
Asia,Eastern Europe,Africa,Mid East,Eastern Asia,Northern Europ,Southern Europe,Domestic Market,North America,Central America,Oceania.
2.How can we guarantee quality?
A team with 20 years of rich experience in the laser industry.
3.What can you buy from us?
Industry Laser Equipment
4. Why should you buy from us not from other suppliers?
Innovation makes Difference,Technology and innovation is always our focus,we has strong capabilities in the design, research and development, and production of non-standard mechanical products, and can customize various specialized mechanical equipment for users according to their needs.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese.
We are based in Suzhou, China, start from 2003,sell to Western Europe,South America,Southeast Asia,South
Asia,Eastern Europe,Africa,Mid East,Eastern Asia,Northern Europ,Southern Europe,Domestic Market,North America,Central America,Oceania.
2.How can we guarantee quality?
A team with 20 years of rich experience in the laser industry.
3.What can you buy from us?
Industry Laser Equipment
4. Why should you buy from us not from other suppliers?
Innovation makes Difference,Technology and innovation is always our focus,we has strong capabilities in the design, research and development, and production of non-standard mechanical products, and can customize various specialized mechanical equipment for users according to their needs.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese.
