SSR120C 10 SANY 12 тонный одинарный Вибрационный каток для дорожного покрытия жилых помещений

Сохранить в закладки 1601196111526:


Цена:5 546 375,00 ₽ - 6 655 650,00 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description




Jobs for Single Drum Rollers
* Leveling ground for sidewalks, driveways and building foundations
* Compacting soil for sports fields or landscaping projects
* Paving roads (although less efficiently than double drum rollers)
* Projects that require extra mobility and precision, like working in tight spaces or making sharp turns.

Features
Extended life time:
◆ The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
◆ Double filtration of engine high intake air, the hydraulic system contains three stage filtration.
High efficiency:
◆ 10% greater excitation force than other products in the same category resulting in 16.7% greater production.
Operator comfort:
◆ Cab mounted on vibration damping mounts
◆ Cab temperature control
◆ Operator control forces have been reduced
Safety features
◆ Rounded bumpers front and rear
◆ Large rear glass and sloped hood for greater visibility


Specification


Technical Specifications


 Model
SSR120C-10


Weight and load
Operating weight (kg)
12000
Weight at drum (kg)
7000
Weight at rear axle (kg)
5000
Drum static linear load (N/cm)
329




Compaction
 Vibration frequency (Hz)
32/36
 Nominal amplitude (mm)
1.8/0.9
 Centrifugal force (kN)
280/178
Drum diameter (mm)
1500
 Drum width (mm)
2130
 Drum edge thickness (mm)
25


Engine
Brand
Dongfeng Cummins
 Model
QSB3.9-C125-30
Emission
NR3
 Rated power (kW)
93

Capacity
 Battery (V×Ah)
24×120

Fuel tank (L)
250

 Hydraulic oil tank (L)
100


Standard Configurations


Config.
Systems
Description
Qty
Details
Remarks




Standard confi.




Main machine



SSR120C-10 single drum roller, standard




1
1. Engine
2. Travel pump
3. Vibration pump
4. Travel motor
5. Vibration motor
6. Reduction gears
7. Operating platform
8.Vibratory drum
(Smooth)
9. Electrical system
10. Operating system
11. Front frame
12. Rear frame
13. Covering part
14. Rear axle assembly
15. Center articulated frame
16. Cab+Air Con





/




Optional confi.
Shed
Shed
1
Low cost
Optional
Vibratory drum with welded pad foot
Drum with welded pad foot

1
Vibratory drum with welded pad foot, which cannot be removed, suitable for compaction of clay, semi-clay, rocks, gravels, expansive soil, and coal cinder base
Substitute smooth drums permissible
Vibratory drum with assembled pad foot
Drum with assembled pad foot
1
Vibratory drum with assembled pad foot, which can be removed to form a smooth drum; suitable for compaction of clay, semi-clay, rocks, gravels, expansive soil, and coal cinder base

Optional
