Products Description
JTFB-300 turbo molecular vacuum pump system unit by air / water cooling
JTFB series turbo molecular pump station is precisely designed with turbo/compound molecular pump and mechanical pump. It’s easy for operation and convenient for installation. JTFB series molecular station can achieve 3×10-3 Pa after turbo molecular pump reaching 400HZ, and 5×10-4 Pa after turbo molecular pump started in 30mins. The station reaches 3×10-5 Pa ultimate pressure.
Basic information: 1) Model: JTFB-300 air/water cooling compound molecular vacuum pump2) Ultimate vacuum pressure: 1*10-6 torr (abs.) 3) Max suction capacity: 300L/s | ||
Standard woonden case suitable for all countries | ||
Lead Time: Have many models in stock, if not, it is about 10 days when less than 5 units, about 25 days when less than 10 units. If urgent, please tell us. | ||
Serial number | Part number | Instructions | quantity | ||
1 | JT300F-01-00 | rack | 1 | ||
2 | ZDF-5227AX | Vacuum gauge | 1 | ||
3 | JTDY300-95-0022-11-4 | 300 Power source | 1 | ||
4 | JTFB300J-00W | HTFB-300 Molecular pump | 1 | ||
5 | JT300F-02-00 | Test mask | 1 | ||
6 | castor | 4 | |||
7 | JTJZ300-03 | Front panel | 1 | ||
8 | HCHD300-05A | Bottom bar | 1 | ||
9 | JT0604-300F-03B | Side panel | 2 | ||
10 | KF25Angle valve | Hand Angle valve | 1 | ||
11 | ZJ-27-KF40 | Ionization gauge | 1 | ||
12 | 16 | clamp | 1 | ||
13 | 25 | clamp | 5 | ||
14 | 40 | clamp | 1 | ||
15 | Low vacuum gauge | 1 | |||
16 | GYC-JQ25 | outsourcing | 1 | ||
17 | JT300F-150WL-22-11-4 | bellows | 1 | ||
18 | GWSP300组装一体 | 300 Oil-free screw pump | 1 | ||
Advantage:
the system equips a foot wheel for operator to move it conveniently.
Easy operation:
Easy operation:
operator only need to connect the equipments to vacuum receiving chamber, then plug and run. No necessary for
assembling works.
assembling works.
Product name | JTFB-300 turbo molecular vacuum pump system unit by air / water cooling | ||||||
Warranty | 15 months | ||||||
Customized support | OEM, ODM, OBM | ||||||
Brand Name | SJHT | ||||||
Type | JT-300Z | ||||||
Power Source | Electric | ||||||
Pressure | High vacuum/ultra-high vacuum | ||||||
Voltage | Vacuum Pump | ||||||
Vacuum Pump | AC 220V | ||||||
Motor speed | 33000 | ||||||
Ultimate Vacuum | 1*10-6 | ||||||
Weight | 28kg | ||||||
Product Paramenters
Application
JT series grease lubrication molecular pump are used for analytical instruments, research and laboratory, semiconductors, leak detection, lamps and tube manufacture, vacuum freeze drying, vacuum metallurgy, vacuum degassing, vacuum oven, vacuum furnace, vacuum coating, vacuum systems, and so on.
Why choose us
Our factory
Our factory was established in 2011, which is the source factory of vacuum molecular pump manufacturing, and can continuously provide you with high-quality products and services.
Until now, our products have been sold to many countries and regions in the world, and won unanimous praise
Production workshop
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Full range of products
Our factory not only produces a variety of types of vacuum pumps, but also can be customized to ensure high quality, timely delivery, to provide you with the most professional vacuum services.
Product packaging
A solid and reliable wooden box is used outside the packaging, and an anti-shock film is used inside to protect the product.
We will flexibly choose various modes of transportation to ensure that the goods are delivered at the fastest speed
Company Profile
Our factory was established in 2011, which is the source factory of vacuum molecular pump manufacturing, and can continuously provide you with high-quality products and services.
FAQ
Q: What does your company do?
A: We are a company focused on the vacuum field. We offer a wide range of vacuum accessories, vacuum pumps, vacuum chambers and special customisation services. Our products are widely used in scientific research laboratories, industrial processes, medical equipment and other fields.
Q: How do you guarantee the quality of your products?
A: We always put product quality first. We cooperate with reliable suppliers and strictly enforce quality control standards during production. Our products undergo rigorous testing and inspection to ensure their stability, reliability and durability.
Q: What vacuum accessories and types of vacuum pumps do you have?
A: We offer many types of vacuum accessories and vacuum pumps, including but not limited to rotary vane pumps, Roots pumps, rotary vacuum pumps, molecular pumps, etc. In addition, we also provide various specifications, models of vacuum valves, vacuum gauges, vacuum pipes and other accessories.
Q: How do I choose the right vacuum system for me?
A: Please tell us your application requirements and system parameters, such as working pressure, pumping speed, pump size, etc. Our expert team will advise you individually and help you choose the right vacuum system for you.
Q: Do you offer special services?
A: Yes, we do. We offer customized services. If you have special needs, such as custom size, materials or special features, we will design and manufacture to your requirements to ensure that the product meets your unique needs.
Q: I found a problem after receiving the product. What should I do?
A: If you find any quality problem or transportation damage after receiving the product, please contact us in time and provide relevant photos and detailed description. We will actively address your issue and assist in resolving it.
Q: How do you guarantee the quality of your products?
A: We always put product quality first. We cooperate with reliable suppliers and strictly enforce quality control standards during production. Our products undergo rigorous testing and inspection to ensure their stability, reliability and durability.
Q: What vacuum accessories and types of vacuum pumps do you have?
A: We offer many types of vacuum accessories and vacuum pumps, including but not limited to rotary vane pumps, Roots pumps, rotary vacuum pumps, molecular pumps, etc. In addition, we also provide various specifications, models of vacuum valves, vacuum gauges, vacuum pipes and other accessories.
Q: How do I choose the right vacuum system for me?
A: Please tell us your application requirements and system parameters, such as working pressure, pumping speed, pump size, etc. Our expert team will advise you individually and help you choose the right vacuum system for you.
Q: Do you offer special services?
A: Yes, we do. We offer customized services. If you have special needs, such as custom size, materials or special features, we will design and manufacture to your requirements to ensure that the product meets your unique needs.
Q: I found a problem after receiving the product. What should I do?
A: If you find any quality problem or transportation damage after receiving the product, please contact us in time and provide relevant photos and detailed description. We will actively address your issue and assist in resolving it.
