40 Вт Летающая волоконно лазерная маркировочная машина для пластиковых пакетов кабельная проволока ПЭТ бутылка лазерная
- Категория: >>>
- Поставщик: Suzhou Fang Shiheng Precision Machinery Co. Ltd.
Сохранить в закладки 1601198904116:
Описание и отзывы
Характеристики
Product Overview
FSH series
Fiber flying laser marking machine
Marking speed 200m/ min
No consumables ,long-term maintenance-free
PRODUCT DESCRIPTION
The FSH series fiber flying laser printer is a high-speed continuous marking machine designed to improve productivity. It adopts IPG industrial-grade high-performance laser source which are with stable performance , fast processing efficiency and marking speed on the production line . It can reach high speed up to 200 meters per minute (single-line 2MM-high numbers and letters) with high-yield application identification requirements , it mainly used in production date , anti-counterfeiting , medical and food packaging industries . This model supports functions such as automatic encoding , serial number , batch number , date , barcode , two-dimensional code , automatic number skipping , etc. , to meet the needs of customers in different industries.
Fiber laser online marking machine is suitable for online marking of most metal materials and some non- metallic materials with surface treatment , such as metal products , PVC , HDPE , aluminum film , rubber and plastics . It is widely used in the production of personal care products , food and beverage packaging , wine , dairy products , electronic components , chemical building materials and other fields , and the expiration date , batch number , shift , manufacturer name and logo and other graphics andtext markings .
Fiber laser online marking machine is suitable for online marking of most metal materials and some non- metallic materials with surface treatment , such as metal products , PVC , HDPE , aluminum film , rubber and plastics . It is widely used in the production of personal care products , food and beverage packaging , wine , dairy products , electronic components , chemical building materials and other fields , and the expiration date , batch number , shift , manufacturer name and logo and other graphics andtext markings .
PRODUCT SIZE
Fiber flying laser marking machine
The F series uses the nanosecond pulsed fiber laser of German IPG laser
source. The features include extremely high pumping efficiency, adjustable or fixed pulse waveform, wide range of pulse repetition frequency, compactdesign, and reliable performance. It can provide users with the best lasersolutions to meet their application requirements.
source. The features include extremely high pumping efficiency, adjustable or fixed pulse waveform, wide range of pulse repetition frequency, compactdesign, and reliable performance. It can provide users with the best lasersolutions to meet their application requirements.
PRODUCT SPECIFICATIONS
Model serials | FSH serial （Germany IPG laser source） | Data | |||||||
Model | FSH-2000 | FSH-3000 | FSH-5000 | FSH-9800 | |||||
Laser parameters | Laser source model | YLP-V2-20 | YLP-V2-30 | YLP-V2-50 | YLP-V2-100 | ||||
3 | Output Power | 20w | 30w | 50w | 100w | ||||
4 | Beam quality M | ≤2 | ≤2 | ≤2 | ≤2 | ||||
5 | Pulse repetition frequency | 2-200 kHz | 96kN | 5-200 kHz | |||||
6 | Laser wavelength | 1064±10nm | |||||||
7 | Output power stability | ＜5% | |||||||
8 | Working life | About 100,000 working hours (non-lifetime) | |||||||
Marking range | 100~300mm (range optional) | ||||||||
Engraving depth | 1mm (depending on power and time) | ||||||||
Engraving speed | 10000mm/s | ||||||||
Repeat accuracy | ±0.002 | ||||||||
Minimum marking line width | 0.1mm | ||||||||
Minimum character height | 0.15mm | ||||||||
Use environment | Cooling way | Built-in air cooling | |||||||
System power supply | 500W / 220V / 50Hz (110V can be connected) | ||||||||
Temperature humidity | 0~40°, 30% RH 85%, air conditioner should be installed when used outside the range | ||||||||
Oil mist condensation | Not allowed | ||||||||
Operating system | Fly control system | ||||||||
File format | The software supports text, QR code, barcode, serial number, graphics and other marking content | ||||||||
Dimensions | 660X510X1460 mm | ||||||||
Packing size | Host: 790X740X350mm Column: 1350X350X280mm | ||||||||
Total Weight | About 66kg | ||||||||
MODEL CHARACTERISTICS
MARKING SPEED UP TO 200 METERS PER MINUTE
This is the industry 's fastest marking laser coding system , with a marking speed of up to 200 m/ min (single line of 2MM-high
numbers and letters) , which can be used in medium-speed or high-speed production lines
numbers and letters) , which can be used in medium-speed or high-speed production lines
RELIABLE AND DURABLE FIBER LASER SOURCE
It adopts IPG high-quality fiber laser light source , which is in uniform laser
power density and highly focused laser beam Achieved a better logo contrast
and the working life of the laser can reach 100 ,000 hours
and the working life of the laser can reach 100 ,000 hours
COMPACT DESIGN AND FLEXIBLE CONFIGURATION
This model uses compact laser printer marking head to achieve simple
integration to reduce installation costs and improve positioning flexibility
integration to reduce installation costs and improve positioning flexibility
FLEXIBLE INSTALLATION WAY ,
CONVENIENT INSTALLATION POSITION ADJUSTMENT
CONVENIENT INSTALLATION POSITION ADJUSTMENT
The flying model is specially designed for high-speed production lines ,which can be flexibly combined with production lines for installation and use. The frame can be moved up and down and left and right toadjust , the marking head can also be rotated 360° for marking
SAMPIE PICTURES
Marking of soda cans
Marking of hardware parts
Electronic components
Marking of iron wire
ABS hose marking
Plastic bag production date marking
SCOPE OF APPLICATION
Electrical components and
electronic devices
electronic devices
Electrical components
Aviation and automobiles
Food and beverages and
fast moving consumer goods
Medicines and medical devices
Cosmetics, personal and
home care products
Company Profile
Company Advantage
1.A professional team with rich experience more than 20 years in the laser industry.
2.Customized technical solution and after-sales support.
3.ODM/OEM service avaliable.
2.Customized technical solution and after-sales support.
3.ODM/OEM service avaliable.
Packing &Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1.Who are we?
We are based in Suzhou, China, start from 2003,sell to Western Europe,South America,Southeast Asia,South
Asia,Eastern Europe,Africa,Mid East,Eastern Asia,Northern Europ,Southern Europe,Domestic Market,North America,Central America,Oceania.
2.How can we guarantee quality?
A team with 20 years of rich experience in the laser industry.
3.What can you buy from us?
Industry Laser Equipment
4.Why should you buy from us not from other suppliers?
Innovation makes Difference,Technology and innovation is always our focus,we has strong capabilities in the design, research and development, and production of non-standard mechanical products, and can customize various specialized mechanical equipment for users according to their needs.
5.What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese.
We are based in Suzhou, China, start from 2003,sell to Western Europe,South America,Southeast Asia,South
Asia,Eastern Europe,Africa,Mid East,Eastern Asia,Northern Europ,Southern Europe,Domestic Market,North America,Central America,Oceania.
2.How can we guarantee quality?
A team with 20 years of rich experience in the laser industry.
3.What can you buy from us?
Industry Laser Equipment
4.Why should you buy from us not from other suppliers?
Innovation makes Difference,Technology and innovation is always our focus,we has strong capabilities in the design, research and development, and production of non-standard mechanical products, and can customize various specialized mechanical equipment for users according to their needs.
5.What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese.
