Профессиональный завод 3 дюймовый водяной насос шланг муфта всасывающий для водяного насоса

Сохранить в закладки 1601200336768:


Цена:71 072,33-77 429,42 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product  Advantages
- Abrasive and high viscosity media: The hose has no restrictions on the wear of the media, there is no seal, and no other parts and media contact
- Uninterruptible media: Very gentle pumping does not cause any damage to the media
- High viscosity medium: produces an almost total vacuum to inhale the medium
- Crystallizing media: No valves or corners cause crystals to form and block the channel
- Metering use: The medium can not backflow so that the amount of pumping medium is very stable
-Where maintenance costs are high the hose is the only worn part and the maintenance time is very short
-Self-priming applications: The pump can dry rotate and lubrication is done on the outside of the hose
-Medium containing more solid substances: medium containing up to 80% solid substances can be transported, such as mining
-Where the suction inlet is blocked: the pump can be dry, and can be reversed to discharge the blockage
-Explosion-proof occasion: there is no contact between metal and metal inside the pump






Products Description


Specification
Caliber/form
customized
Speed range rpm
0-130
Power range kw
0.75-45
Pump head material
QT
Spare parts material
EPDM/NBR/NR


                                                       PARAMETER   TABLE   OF  HOSE  PUMP
52
model
maximum flow
suggested traffic
pressure
rotate speed
motor power
HXRB—15
600L/h
30—315L/h
0.8MPa
10—60rpm
0.75kw
HXRB—20
1000L/h
102—535L/h
0.8MPa
15—60rpm
0.75kw
HXRB—25
2m³/h
0.3—1m³/h


1.6MPa
20—60rpm
 2.2kw
HXRB—32
5m³/h
0.8—3m³/h
1.6MPa


20—80rpm
    3kw
HXRB—40
9m³/h
1.5—6m³/h
1.6MPa
20—80rpm
4kw
HXRB—50
13m³/h
2.4—9m³/h
1.6MPa
16—60rpm
5.5kw
HXRB—65
24m³/h
3.8—18.2m³/h
1.6MPa
10—48rpm
11kw
HXRB—80
40m³/h
9—36m³/h
1.6MPa
10—40rpm
15kw
HXRB—100
54m³/h
10—40m³/h
1.6MPa
10—30rpm
18.5kw
HXRB—125
80m³/h
20—66m³/h
1.6MPa
10—30rpm
30kw
