Промышленный Пищевой Стерилизатор реторт для готовых к употреблению блюд

Промышленный Пищевой Стерилизатор реторт для готовых к употреблению блюд

Категория: >>>
Поставщик: Shandong Mosen Machinery Co. Ltd.Shandong Ltd.

Цена:11 000,00-12 000,00 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Industrial Food Sterilizer Retort For Ready-to-eat Meals

Products Description

1.Cooling is accomplished with a plate and frame heat exchanger. Water used for sterilization in steam water spray retorts is ported through the heat exchanger with a cooling source on the other side of the heat exchanger. This design allows for sterile water to contact the product, separating cooling water with the heat exchanger. Sterile cooling eliminates the need for any additional chlorine in the batch sterilization process.
2.The Water Spray process is also an overpressure process, like water immersion, except that the product is exposed to the influence of the overpressure air. It is similar to the Saturated Steam process in that steam is the driving force for reaching the center of the load. But, the Water Spray process is different from Saturated Steam in that air can be introduced into the vessel during sterilization. Overpressure is provided by introducing air (or steam) into the retort. To overcome the insulating effects of the air, the spray nozzles vaporize the steam and mix the steam with the air.

Industrial Food Sterilizer Retort For Ready-to-eat Meals

Water Spray Retort is suitable for all kinds of high temperature resistant packaging materials, such as PE bottles, tinplate cans,
gas packaging, glass cans, flexible packaging, aluminum foil bag packaging.
Plastic Container: PP bottles, HDPE bottles
Metal Containers: tin cans, Aluminum cans
Soft bag packaging: aluminum foil bag, transparent bag, vacuum bag, and so on

Specification

Model	Inner diameter （mm）	Length（mm）	Capacity（mm）	Temperature（℃）	Pressure（Mpa）	Voltage（V）	Power（kw）
PLJ.10-1.B.3	1000	950	1.00	147	0.3	380	3.5
PLJ.10-2.B.3	1000	1900	1.80	147	0.3	380	6
PLJ.12-2.B.3	1200	1900	2.60	147	0.3	380	6
PLJ.12-3.B.3	1200	2870	3.70	147	0.3	380	11.5
PLJ.12-3.6B.3	1200	3820	4.06	147	0.3	380	11.5
PLJ.14-3.B.3	1300	4000	5.62	147	0.3	380	23

Why Choose Us

All our products are guaranteed for one year and maintained for life.

A set of wearing parts will come with the machine for free.
For more information,pls contact our sales stuff.

FAQ

Q: Are you manufacturer or trading company?
A: We are a professional manufacturer.
Q: What is your business scope?
A: There are three categories, such as food sterilization machine, jacket cooker, rubber vulcanization autoclave.
Q: How about the installation? And what if the machine goes down?
A: We will do that. There are two options.
a. We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa,
accommodation and labor cost shall be on your side.
b. On-line service will be provided. If still is under guarantee period, the necessary accessories and parts will be provided
free, but the transportation cost of it shall be on your side.
Q: Do you take L/C?
A: Yes, we accept L/C, T/T and irrevocable L/C payable.
