Высокоскоростной вакуумный настольный УФ-принтер
1 545 650,40 ₽ - 1 656 054,00 ₽
Многофункциональный принтер машина для алюминия УФ цифровой планшетный
- Категория: >>>
- Поставщик: Jinan Yingcai Digital Technology Co. Ltd.
Сохранить в закладки 1601202219418:
Описание и отзывы
Характеристики
Products Description
Printhead
EPSON DX5/DX7/
XP600/TX800/I3200
Printhead 2-4 units
Print Effect
Color, white, varnish and 3D embossing effect optional
Printing Areas
Glass/Ceramic/Decoration/
Advertising&Sign industry
Product Paramenters
YC6090 UV Flatbed Printer
①UV LED Lamp
④Switch Area
②Industrial Printhead
⑤Universal Wheel
③ROUST mute
Specifications | ||||||||
Product Model | YC6090 | |||||||
Printhead Type | EPSON | |||||||
Printhead Number | 2-4 heads | |||||||
Ink Characteristics | UV Curing Ink (VOA Free) | |||||||
Ink reservoirs | Refillable on the fly while printing/2500ml per color | |||||||
LED UV Lamp | more than 30000-hours life | |||||||
Printhead arrangement | CMYKW V Optional | |||||||
Printhead Cleaning System | Automatic Cleaning System | |||||||
Guide Rail | ROUST mute | |||||||
Working Table | Vacuum Sucking | |||||||
Printing Size | 900*600mm | |||||||
Print Interface | USB2.0/USB3.0/Ethernet Interface | |||||||
Media Thickness | 0-100mm | |||||||
Print Resolution& Speed | 720X600dpi | 4PASS | 4-16sqm/h | |||||
720X900dpi | 6PASS | 3-11sqm/h | ||||||
720X1200dpi | 8PASS | 2-8sqm/h | ||||||
Life of printed image | 3 years(outdoor),10years(indoor) | |||||||
File Format | TIFF,JPEG,Postscript,EPS,PDF etc. | |||||||
RIP Software | RIP/Photoprint optional | |||||||
Power Supply | 220V 50/60Hz(10%) | |||||||
Power | 3100W | |||||||
Operation Environment | Temperature 20 to 30 ℃,Humidity 40% to 60% | |||||||
Machine Dimension | 2100*1060*1160mm | |||||||
Packing Dimension | 2435*1225*1335mm | |||||||
Weight | 400kg | |||||||
Warranty | 12 months exclude the consumables | |||||||
Above specification subject to change without notice beforehand | ||||||||
Machine Details
Epson Print Head
Equiped with Japanese Epson DX5/DX7/XP600/TX800/I3200 heads with 180 nozzles 6 or 8 channels, which provides a high-precision printing.
Vacuum Suction
The vacuum suction platform is easy to operate and save energy,good for vario-us sizes of personalized printing; With full cover for bleeding printing, it will im-prove the utilization of materials.
High Precision Mute
Linear Guide Rail
Linear Guide Rail
Use high precision mute liner guide rail,
long service life, high stability,immensely
decrease noise while printer is printing,
within 40DB while printing.
long service life, high stability,immensely
decrease noise while printer is printing,
within 40DB while printing.
Customized Rotary Device
The rotary device is mounted above the vacuum suction platform, which realize both the flat material and Cylinder obje-cts printing, like bottle or cup. And, the rotary device can be customized accor-ding to customer's need.
Lift Cap Station System
Temperature Control System
Korea UV LED Lamp
Automatic height measurement
Antistatic System
Customized Rotary Device
EPSON Nozzle
Adopt Epson piezoelectric nozzle, the accuracy can reach 2160dpi, the new variable ink drop technology, provide 3/3.5pl ink dot size, can achieve high speed or low resolution cases can also easily achieve high quality picture, to achieve no point printing effect.
CMYK+W+V ALL three colors at once
The use of gloss oil makes the product more gorgeous gloss and "high gloss" effect, not only makes the surface of the whole picture has a gloss sense, get a more exquisite printing effect, but also can better protect the coating, make the product more durable.
Printing Samples
Photo Case
Floor Mat
Ceramic
Glass Photo
Advertising Sign
Plastic
Wood
Pen
Car Sticker
Wall Background
Glass Cup
Mouse Pad
Company Profile
Jinan Yingcai Digital Technology Co., Ltd
Jinan Yingcai Digital Technology Co., Ltd ( short as”Winscolor”) was established in 2015, locating in Jinan City, Shandong province, China. The independent plant covers more than 20,000 square meters, with six professional production lines to support annually sales volume.
Winscolor is an exporter of UV digital printing machines . Now our printer series include UV Flatbed
printer, UV Flatbed with Roll to roll printer, and UV Hybrid printer, as well as smart UV printer.
Winscolor digital printing machine was exported since 2015, with widespread praise and recognition by our customers, our printers are welcome more than 150 countries in Asia, Europe, Australia and Africa etc.
Winscolor UV printers have been widely used in advertisement, sign,decoration, glass, crafts and other industries. We strengthen technological innovation, optimize the cost of consumption, and strive to create the best quality UV digital printing machines for our customer, and some comprehensive solu-tions according to different demands in various industries.
Winscolor uphold the concept of excellence, and continuously improve product quality, to become the most trusted brand in UV printing equipment industry. We will continue to committed to industrial printing R & D and innovation and promote the healthy development of printing industry.
Winscolor UV printers have been widely used in advertisement, sign,decoration, glass, crafts and other industries. We strengthen technological innovation, optimize the cost of consumption, and strive to create the best quality UV digital printing machines for our customer, and some comprehensive solu-tions according to different demands in various industries.
Winscolor uphold the concept of excellence, and continuously improve product quality, to become the most trusted brand in UV printing equipment industry. We will continue to committed to industrial printing R & D and innovation and promote the healthy development of printing industry.
Winscolor UV Flatbed Printer-Warranty
We provide one year warranty for our uv printers including all the electronic parts including the main board, driver board,control board, motor, etc, except the consumables, such as printhead, ink pump, ink filter, and slide block etc.Packing & Delivery
Customer Photos
FAQ
1.How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors, and more than 10 years indoor.
The printing images can last at least 3 years outdoors, and more than 10 years indoor.
2.What is the cost of ink for printing on the materials?
Normally it is around 0.5-1USD per square meter for ink cost.
Normally it is around 0.5-1USD per square meter for ink cost.
3.How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability, best result.
This UV flatbed printer can used to print on most of medias with best quality, durability, best result.
4.How about the maintenance and after sales service?
Our engineer available service overseas, and we can provide remote control service and online service for customers. But customer has to be responsible for the accommodation and transportation costs of the technical staff.
Our engineer available service overseas, and we can provide remote control service and online service for customers. But customer has to be responsible for the accommodation and transportation costs of the technical staff.
5.Are you a manufacturer or trade agent?
We are the manufacturer of UV flatbed printers.
We are the manufacturer of UV flatbed printers.
6.Is there any guarantee for this printer?
Yes, we have guarantee for the printer. We provide 13 months warranty for all the electronic parts including the main board,driver board, control board, motor, etc, except the consumables, such as ink pump, printhead, ink filter, and slide block etc.
Yes, we have guarantee for the printer. We provide 13 months warranty for all the electronic parts including the main board,driver board, control board, motor, etc, except the consumables, such as ink pump, printhead, ink filter, and slide block etc.
7.How can I install and start to use the printer?
Normally we will arrange technician for installation and training in your factory. or you can read the users' manual to understand the machine. If you need any help, our technician can help you via Teamviewer. Whenever you have questions to the machine, you can contact our technician or me directly.
Normally we will arrange technician for installation and training in your factory. or you can read the users' manual to understand the machine. If you need any help, our technician can help you via Teamviewer. Whenever you have questions to the machine, you can contact our technician or me directly.
8.Can I get supplies and wearing parts from you?
Yes, we provide all the wearing parts for our printers always and they are in stock.
Yes, we provide all the wearing parts for our printers always and they are in stock.
9.How will you achieve the warranty?
If any electronics or a mechanical part is confirmed to be broken, Ntek should send the new part within 48 hours by express like TNT, DHL, FEDEX .etc to the buyer. And the shipping cost should be born by the buyer.
If any electronics or a mechanical part is confirmed to be broken, Ntek should send the new part within 48 hours by express like TNT, DHL, FEDEX .etc to the buyer. And the shipping cost should be born by the buyer.
10.What kinds of materials need premier before printing?
Glass, ceramic, metal, acrylic, marble etc
Glass, ceramic, metal, acrylic, marble etc
