Solis On Grid Eu склад Pv инвертор 6 кВт 10 20 трехфазные солнечные инверторы

Solis On Grid Eu склад Pv инвертор 6 кВт 10 20 трехфазные солнечные инверторы

Категория: >>>
Поставщик: Sunevo Solar Co. Ltd.

Цена:86 640,29 ₽ - 125 243,47 ₽*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

Models

3K

4K

5K

6K

8K

10K

12K

15K

20K

Input DC

Recommended max. PV power

4.5 kW

6 kW

7.5 kW

9 kW

12 kW

15 kW

18 kW

22.5 kW

30 kW

Max. input voltage

1100 V

Rated voltage

600 V

Start-up voltage

180 V

MPPT voltage range

160-1000 V

Max. input current

16 A / 16 A

32 A / 32 A

Max. short circuit current

20 A / 20 A

40 A / 40 A

MPPT number/Max. input strings number

2/2

2/4

Output AC

Rated output power

3 kW

4 kW

5 kW

6 kW

8 kW

10 kW

12 kW

15 kW

20 kW

Max. apparent output power

3.3 kVA

4.4 kVA

5.5 kVA

6.6 kVA

8.8 kVA

11 kVA

13.2 kVA

16.5 kVA

22 kVA

Max. output power

3.3 kW

4.4 kW

5.5 kW

6.6 kW

8.8 kW

11 kW

13.2 kW

16.5 kW

22 kW

Rated grid voltage

3/N/PE, 220 V / 380 V, 230 V / 400 V

Rated grid frequency

50 Hz / 60 Hz

Rated grid output current

4.6 A /

4.3 A

6.1 A /

5.8 A

7.6 A /

7.2 A

9.1 A /

8.7 A

12.2 A /

11.5 A

15.2 A /

14.4 A

18.2 A /

17.3 A

22.8 A /

21.7 A

30.4 A /

28.9 A

Max. output current

4.7 A

6.4 A

7.9 A

9.5 A

12.7 A

15.9 A

19.1 A

23.8 A

31.8 A

Power factor

>0.99 (0.8 leading - 0.8 lagging)

THDi

<2%

Efficiency

Max. efficiency

98.3%

98.5%

98.6%

98.7%

EU efficiency

97.7%

97.9%

98.0%

98.1%

Protection

DC reverse-polarity protection

Yes

Short circuit protection

Yes

Output over current protection

Yes

Surge protection

Yes

Grid monitoring

Yes

Anti-islanding protection

Yes

Temperature protection

Yes

Integrated AFCI (DC arc-fault circuit protection)

Yes (1)

Integrated DC switch

Optional

General Data

Dimensions (W*H*D)

310*563*219 mm

Weight

17.8 kg

18.8 kg

20 kg

Topology

Transformerless

Self-consumption (night)

<1 W

Operating ambient temperature range

-25 ~ +60°C

Relative humidity

0-100%

Ingress protection

IP66

Cooling concept

Natural convection

Intelligent redundant fan-cooling

Max. operation altitude

4000 m

Grid connection standard

G99, VDE-AR-N 4105 / VDE V 0124, EN 50549-1, VDE 0126 / UTE C 15 / VFR:2019, RD 1699 / RD 244 / UNE 206006 /

UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530

Safety/EMC standard

IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4

Features

DC connection

MC4 connector

AC connection

Quick connection plug

Display

LCD

Communication

RS485, Optional: Wi-Fi, GPRS

Products Series

On Grid Residential Inverter

0.7-10KW

1-3 MPPTs
Single Phase 220-240V 50/6Hz

On Grid Residential Inverter

3-20KW

2 MPPTs
Three Phase 380-415V 50/6Hz

On Grid Commercial Inverter

25-70KW

5/6 MPPTs
Three Phase 380-415V 50/6Hz

On Grid Commercial Inverter

50-125KW

10 MPPTs
Three Phase 380-415V 50/6Hz

On Grid Utility Scale Inverter

215-255KW

9-14 MPPTs
Three Phase 800V 50/6Hz

Energy Storage Inverter

3-6KW

Battery Voltage: 42-58V
Single Phase 220-240V 50/6Hz

Energy Storage Inverter

5-10KW

Battery Voltage: 120-600V
Three Phase 380-415V 50/6Hz

Applications

Pictures and Packages

Project Case

Contact Us

FAQ

Q1:who are we?

A1:We are based in Anhui, China, start from 2017,sell to Southern Europe (40.00%),Southeast Asia (20.00%), Africa
(18.00%), Domestic Market(2.00%),South Asia(2.00%),North America(2.00%),Northern Europe (2.00%),Central America (2.00%), Western Europe(2.00%),Eastern Asia(2.00%),Mid East(2.00%),Oceania(2.00%),Eastern Europe (2.00%), South America (2.00%). There are total about 101-200 people in our office.

Q2:How does your factory control the quality?

A2:We adopt iso 9001 quality system to control the quality. We have incoming quality control department to test and confirm raw material meets high quality producing requirements, production quality control department contains. The first inspection, in-process quality control, acceptance inspection and full inspection, outgoing quality control department confirm no defective batteries come out from the factory.

Q3:Can I have a sample order?
A3:Yes, we welcome sample order to test and check quality.

Q4:Do you support customized design?

A4:Yes,we can accept your customized requirements,we can also help you create your new designs.

Q5:How can I place an order?

A5:You can contact us for the details and after all the details confirmed,you can place an order.

If you want to know more information, you can send inquiry to our team, we will cover more details.
