Светодиодный сетчатый экран большой площади пиксельный производитель HD занавес стены здания освещения
- Категория: >>>
- Поставщик: Shenzhen Xinqidian Opto Technology Factory
Сохранить в закладки 1601206770467:
Описание и отзывы
Характеристики
Specifications
Product feature
1. The point light source with larger wire diameter is adopted to support the power supply and signal transmission mode with a longer distance.
2. Flexible installation method: the product is small in size and light in weight. With flexible steel wire rope, flexible and diverse installation methods can be realized.
3. It has breakpoint continuous transmission function, even if one pixel is damaged, it will not affect the subsequent pixel
4. Signal reception to minimize product failure rate.
5. Multiple spacing options to flexibly control project costs.
2. Flexible installation method: the product is small in size and light in weight. With flexible steel wire rope, flexible and diverse installation methods can be realized.
3. It has breakpoint continuous transmission function, even if one pixel is damaged, it will not affect the subsequent pixel
4. Signal reception to minimize product failure rate.
5. Multiple spacing options to flexibly control project costs.
The unique feature of the grid screen is its perspective effect, which not only shows what is on the screen, but also allows the city scene to be hidden behind, forming a wonderful sense of hierarchy. Light from the inside of the building interacts with light from the outside, penetrating the gaps in the mesh screen to create a dreamlike visual effect.
Software optimization:
Color correction: Regular color correction to ensure the accuracy and consistency of the display color.
Brightness adjustment: Automatically or manually adjust the screen brightness according to the ambient light changes to maintain the best visual effect.
Environmental adaptation:
Automatic brightness adjustment: Automatically adjust the screen brightness according to the ambient light intensity to ensure that it can be clearly displayed under various lighting conditions.
Anti-glare treatment: Use special coatings or materials to reduce glare and improve visibility in outdoor environments.
Maintenance and cleaning:
Regular check: Check the hardware connection and software system of the grid screen regularly to ensure that everything is running properly.
Cleaning and maintenance: Clean the surface of the screen regularly to avoid dust and stains affecting the display effect.
Software optimization:
Color correction: Regular color correction to ensure the accuracy and consistency of the display color.
Brightness adjustment: Automatically or manually adjust the screen brightness according to the ambient light changes to maintain the best visual effect.
Environmental adaptation:
Automatic brightness adjustment: Automatically adjust the screen brightness according to the ambient light intensity to ensure that it can be clearly displayed under various lighting conditions.
Anti-glare treatment: Use special coatings or materials to reduce glare and improve visibility in outdoor environments.
Maintenance and cleaning:
Regular check: Check the hardware connection and software system of the grid screen regularly to ensure that everything is running properly.
Cleaning and maintenance: Clean the surface of the screen regularly to avoid dust and stains affecting the display effect.
Products Description
Basic product parameters | Product protection parameters | ||||
Product model | XQD-2020-4light mesh screen | Waterproof grade | IP67 | ||
Product size | Φ 20mm*14.5mm | Enclosure flame resistance | V-0 | ||
Application environment | Indoor and outdoor | UV resistance grade | 4 | ||
Product unit weight | About 5.7g | Salt spray test | Salt fog resistance | ||
Shell material | PC | Impact resistance | IK10 | ||
Maximum number of connections | 100 PCS/string | Electrical safety level | Class III | ||
Center spacing | Minimum 5cm | Safety certification | CE FCC RoHS | ||
Average product life | 50000 hours | working temperature | -40℃-55℃ | ||
Optional Accessories | Steel wire clamp | ||||
Wire core | 4x0.25mm ² | ||||
Wire material | PVC | ||||
PCB material | FR-4 glass fiber board | ||||
Product optical parameters | Product electrical parameters | ||||
LED color | RGB | Working voltage | DC12V | ||
Luminous angle | 120° | Rated power | 0.2W | ||
Color resolution | 3*8bit | ||||
Lamp beads | SMD5050*1LED | Auxiliary system | |||
Pixel luminous flux | 7.9 LM | Control system | SPI | ||
Luminance | 2.2-2.5cd | Power supply system | DC12V constant voltage | ||
Dimension
Company information
XQD
Shenzhen XQD Co., Ltd., founded in February 2010, is a professional high-tech Led enterprise engaged in research and development, production, sales and service. We have more than 200 employees and currently have 20 technicians. The factory covers an area of more than 6000 square meters and imports advanced modern professional production equipment and testing equipment. The technology has reached the advanced level of similar products at home and abroad. The company has always been one of the largest manufacturers in China LED pixel lamp.
Various LED lighting festivals, building lighting projects. The products are sold to global markets, including Europe, Asia and the Middle East, covering 100 countries and more than 30 domestic provinces and cities. We have developed our own advertising light source and lighting products with patents. The manufacturer strictly complies with ISO9001 quality management system certification and ISO14001 environmental management system certification, and has passed CE, FCC and other international certifications.
Factory
Customer Photos
Certificates
FAQ
Q1. Can I order samples of led lamps?
A: Yes, we welcome sample orders to test and check the quality. Mixed samples are acceptable.
A: Yes, we welcome sample orders to test and check the quality. Mixed samples are acceptable.
Q2. How about the delivery date?
A: The sample takes 3-5 days, the batch production takes 1-2 weeks, and the order quantity exceeds
A: The sample takes 3-5 days, the batch production takes 1-2 weeks, and the order quantity exceeds
Q3. Do you have a minimum order limit for LED lights?
A: The minimum order quantity is low, and one sample can be provided for inspection
A: The minimum order quantity is low, and one sample can be provided for inspection
Q4. How do you ship the goods and how long will it take to arrive?
A: We usually ship through DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Air and sea transportation are also optional.
A: We usually ship through DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Air and sea transportation are also optional.
Q5. How to order led lamps?
A: First let us understand your requirements or applications.
Secondly, we quote according to your requirements or our suggestions.
Third, the customer confirms the sample and submits the deposit for formal order.
Fourth, we arrange production.
A: First let us understand your requirements or applications.
Secondly, we quote according to your requirements or our suggestions.
Third, the customer confirms the sample and submits the deposit for formal order.
Fourth, we arrange production.
Q6. Can I print my logo on the led lamp product?
A: Yes. Please inform us formally before our production and confirm the design first according to our samples.
A: Yes. Please inform us formally before our production and confirm the design first according to our samples.
