Hysun Office с модифицированным контейнерным домом металлическое стальное строительство вилла модифицированное здание
826 584,75 ₽ - 859 648,14 ₽
FMX дом бунгало Плоская Упаковка Контейнер для дома продажи современные контейнерные сфабрикованный контейнерный
- Категория: >>>
- Поставщик: Suzhou Fengminxuan Mobile House Co. Ltd.
Сохранить в закладки 1601208454767:
Описание и отзывы
Характеристики
Frame Structure: | Project | Specifications | Unit | Quantity | ||
Top Frame: | Top Long Beam: 2.3mm Galvanized Steel, Top Frame 180mm | Pieces | 2 | |||
Top Short Beam: 2.0mm Galvanized Steel, Top Frame 180mm | Pieces | 2 | ||||
Bottom Frame: | Bottom Long Beam: 2.3mm Galvanized Steel, Bottom Frame 160mm | Pieces | 2 | |||
Bottom Short Beam: 2.0mm Galvanized Steel, Bottom Frame 160mm | Pieces | 2 | ||||
Columns: | Column: 2.3mm C-shaped Galvanized Steel, 160*160mm | Pieces | 4 | |||
Bolts: M12*25mm High-strength Carriage Bolts | Set | 64 | ||||
Angle Heads: | 160*160mm, Wall Thickness 4.0mm | Set | 8 | |||
Powder Coating: | Powder Coating: | Electrostatic spray process, does not fade for 5 years | Suite | 1 | ||
Pressing Slot | Top Beam Pressing Slot: Alloy Profile Thickness 1.0mm | Pieces | 2 | |||
Top Short Beam Pressing Slot: Alloy Profile Thickness 1.0mm | Pieces | 2 | ||||
Square Tube System | Chassis Purlin | 50mm*100mm Galvanized Square Tube, Thickness 1.2mm | Pieces | 9 | ||
Top Plate Purlin | 50mm*50mm Galvanized Square Tube, Thickness 1.5mm | Pieces | 2 | |||
50mm*50mm Galvanized Square Tube, Thickness 1.1mm | Pieces | 1 | ||||
40mm*60mm Galvanized Square Tube, Thickness 1.1mm | Pieces | 6 | ||||
Door Frame Column | 20mm*40mm Galvanized Square Tube, Thickness 1.1mm | Pieces | 1 | |||
Wall | Rock Wool Wall Panel | Color steel composite board thickness 50 mm, color steel double-sided thickness 0.3 mm, PE film attached, white color, double-sided ribbed; PU sandwich panel | set | 1 | ||
Door & Window | Steel Door | Steel package door, size ≥ W925 mm × H2035 mm, fire door lock | piece | 1 | ||
External Window | PVC window with double glass, 0.93*1.2 m | pieces | 2 | |||
Other | Interior Floor | Bulu Board Thickness: 1.8m | pieces | 5 | ||
Roof Waterproof Tile | Single-layer Color Steel Waterproof Tile with Interlocking Thickness: 0.3mm | sheets | 6 | |||
Roof Insulation Layer | Glass Wool Roll, Thickness: 40mm, Density: 20kg/m3, Non-combustibility Class A | roll | 1 | |||
Interior Ceiling Tile | 0.3 mm double-layer color steel 831 type corrugated tile | sheets | 6 | |||
Other Auxiliary Materials | Includes all standard screws, structural adhesives, etc. | set | 1 | |||
Electrical system | Electrical Configuration | 1. Standard national standard wire; incoming wire 4, air conditioner socket 4, general socket 2.5, lighting 1.5. (Circuits can be customized to meet certification requirements of different countries) | Set | 1 | ||
2. Circuit breaker system; 2P63A main switch 1 | Set | 1 | ||||
3. Lighting; LED ceiling light*2. | Set | 1 | ||||
4. Five-hole socket*4; standard three-hole socket*1 (socket standard can be configured according to customer requirements) | Set | 1 | ||||
Performance Parameters | Insulation Performance | λ=0.048 W/m·K | ||||
Sound Insulation Performance | Sound insulation level ≥ 30 dB | |||||
Waterproof Performance | 360-degree bite, free drainage, 16 mm/min precipitation without leakage | |||||
Floor Live Load | 2.0 KN/㎡, 400-500 kg per square meter | |||||
Wind Resistance | 0.6 KN/㎡, withstand 11-12 level wind | |||||
Fire Resistance | A grade | |||||
Earthquake Resistance | ≥ 8 level | |||||
Temperature Range | -45°C to 60°C | |||||
Bathroom | Bathroom (Optional) | Glass door for bathroom * 2 (frameless glass door optional), 1 set of toilet, 1 set of washbasin, 1 handheld shower, floor drain, plumbing | Set | 1 | ||
Cabinet | Kitchen Cabinet (Optional) | Integrated kitchen marble cabinet with sink and pipes，Size can be customized, please contact customer service. | Set | 1 | ||
Terrace | Terrace (Optional) | includes wood-plastic flooring, guardrails | Set | 1 | ||
Elevated Container Bottom | Bottom of Box Raised | Set | 1 | |||
Roof Cover | Roof Cover (Optional) | Sloping roof, enhances overall appearance and facilitates drainage, material options: composite panels, EPS panels, resin tiles, including keel. | Set | 1 | ||
1.Q.Are you a factory or trading company?
A.Shanghai Tangcheng Container House Co., Ltd. is an integrated company of factory and trade located in the major city of Shanghai, China.
2.Q.Do you provide on-site installation service?
A.1) Only large projects provide installation services
2) General projects, we can provide Installation guide service based on customers' request.
3) Installation supervision charge standard: 150USD/day, customer should responsible for the travel fee, accommodation, translation fee, and ensure staff' s health and safety.
3.Q.If there is a clear service life of your products?
A. Under normal climate and environmental conditions, the steel frame of a container house has a lifespan of 20 to 30 years.
4.Q.What is your Minimum Order Quantity and pricing?
A.The MOQ for each product is different, so it would be best to refer to the detail page of the product you are interested in.If you need further clarification, send me the product link and I will reply as soon as possible.
5.Q.What kind of packaging options do you offer?
A.We use PP packaging, but we also customize packaging for our OEM customers.
6.Q.What is the minimum quantity for mass purchase?
A.Different models can be mixed in one container, but the quantity of each model should not be less than MOQ，The MOQ for each product is different, so it would be recommended to refer to the detail page of the product you are interested in. If you need further clarification, send me the product link, and I will reply as soon as possible.
A.Shanghai Tangcheng Container House Co., Ltd. is an integrated company of factory and trade located in the major city of Shanghai, China.
2.Q.Do you provide on-site installation service?
A.1) Only large projects provide installation services
2) General projects, we can provide Installation guide service based on customers' request.
3) Installation supervision charge standard: 150USD/day, customer should responsible for the travel fee, accommodation, translation fee, and ensure staff' s health and safety.
3.Q.If there is a clear service life of your products?
A. Under normal climate and environmental conditions, the steel frame of a container house has a lifespan of 20 to 30 years.
4.Q.What is your Minimum Order Quantity and pricing?
A.The MOQ for each product is different, so it would be best to refer to the detail page of the product you are interested in.If you need further clarification, send me the product link and I will reply as soon as possible.
5.Q.What kind of packaging options do you offer?
A.We use PP packaging, but we also customize packaging for our OEM customers.
6.Q.What is the minimum quantity for mass purchase?
A.Different models can be mixed in one container, but the quantity of each model should not be less than MOQ，The MOQ for each product is different, so it would be recommended to refer to the detail page of the product you are interested in. If you need further clarification, send me the product link, and I will reply as soon as possible.
