Колеса monjaro geely для деталей легкосплавных колес atlas nl3 haoyue l okavango coolray автомобильные аксессуары бампер r19
- Категория: >>>
- Поставщик: Sichuan Pengqin Automobile Service Co. LTD
Сохранить в закладки 1601211326757:
Описание и отзывы
Характеристики
Pengqin Wheels Strength
Pengqin cast wheels,only focus on flow forming wheels
Flow Forming Wheels:
Advantage: High strength, good toughness, low overall mass, good air tightness while ensuring high quality and low prices
Disadvantage: Overall performance is not as good as forged wheels.
Advantage: High strength, good toughness, low overall mass, good air tightness while ensuring high quality and low prices
Disadvantage: Overall performance is not as good as forged wheels.
Technical Details：Flow forming is based on low-pressure casting of the rim part of the rotary stamping, changing the internal structure of the rim part of the metal, the molecules are more dense fibrous arrangement, compared with the ordinary casting has a higher mechanical properties performance, which is manifested as a higher strength, toughness is better. The spinning rim has a thinner cut, so the overall weight of the wheel is reduced, which is the most direct technical advantage of the spinning process.
Normal Cast Wheels:
Advantage: Lowest price, but no guarantee of quality
Disadvantage:Low strength, easy to disform and crack after heavy impact.
Technical Details：Aluminium water enters the mould under pressure and the aluminium liquid solidifies and crystallises under pressure. The whole process is carried out mechanically, so the process level is stable. Nowadays, the vast majority of car manufacturers specify low pressure casting to ensure the quality of their wheels.
Cast Wheels | Flow Forming Wheels | Forged Wheels | |
Material | A356.2 | A356.2 | Aluminum Alloy 6061-T |
Yield Strength | 152MPa | 200MPa | 276MPa |
Tensile Strength | 220MPa | 290MPa | 310MPa |
Elongation | ≥7% | ≥10% | ≥12% |
Products Description
Products Brand | Pengqin |
Products Model | DP164 |
Wheels Type | Cast Wheel |
Wheel Structure | Monoblock |
Warranty | 3 Years Warranty |
Place of Origin | Wuhu,Anhui |
Certificates | TUV/JWL/VIA/ DOT/ CNAS/IATF16949/ISO(169001、14001、45001） |
Wheel Diameter | 18/19/20 inch |
Material | Aluminum Alloy |
Colour | gunmetal gray |
PCD/Bolt Pattern | 5x108 |
Hub Bore/Center Bore | 63.4 |
Rim Width | 7.5j &8J |
Offset | 46 |
Test | Bending Test/Impact Test/Radial Fatigue Test |
MOQ | 4 Pcs |
Company Profile
Sichuan Pengqin Automotive Service Co., Ltd, with 16 years of experience in the field of automotive wheels, is a high-end aluminium alloy wheels comprehensive enterprise integrating design, R&D, sales and after-sales. The factory is located in Wuhu City, Anhui Province, China, covering an area of more than 200,000 square meters, more than 200 employees, the main products are original wheels, modified wheels (including automotive wheels, off-road wheels, racing wheels), wheels ranging from 13 inches to 26 inches, and to support the customer's personalised forging and customisation, complete product lines and stable supply chain meet the needs of all kinds of scenarios.Each wheel comes with a 3-year warranty and $10 million in insurance from ZURICH.
Our products are exported to USA, Malaysia,Japan, Russia,Holland, Mexico, Canada, Spain, Singapore,Thailand ,Australia, Korea, Vietnam, and other countries. Our products ensure safety while providing consumers with a great driving experience. We have won the favour of many customers with our quality products, competitive pricing and meticulous service, and our expertise and service enable us to provide our customers with the best quality products.
Our products are exported to USA, Malaysia,Japan, Russia,Holland, Mexico, Canada, Spain, Singapore,Thailand ,Australia, Korea, Vietnam, and other countries. Our products ensure safety while providing consumers with a great driving experience. We have won the favour of many customers with our quality products, competitive pricing and meticulous service, and our expertise and service enable us to provide our customers with the best quality products.
Our Factory
Each of our wheels has passed strict quality tests (Bending Fatigue Test, Impact Test, Radial Fatigue Test), and has been certified by more than 10 industries(ATF16949 , ISO14001,OHSAS18000, TÜV, DOT, VIA, TIP, INMETRO, GOST and other certifications.)
Our careful packaging will ensure the safety of your goods.
Each wheel comes with a 5-year warranty and $5 million in insurance from Allianz.
Shipping
Ocean freight, container railway transport, LCL transport and RO-RO transport.
Customer‘s Modification Effect
FAQ
Q1:How do you ensure the quality of your products?
A:Each of our wheels has passed strict quality tests (bending fatigue test, impact test, radial fatigue test), and has been certified by more than 10 industries(ATF16949 , ISO14001,OHSAS18000, TÜV, DOT, VIA, TIP, INMETRO, GOST and other certifications.), and each wheel comes with a 5-year warranty and $5 million in insurance from Allianz.
Q2: What information should I provide with my quote?
A:We need to know: car model and wheel size, PCD, CB, ET (offset), colour and quantity ordered in order to provide you with the best possible quote.
Q3:What is your MOQ?
A:4 Pcs for inventory, 80 Pcs for existing mould，We can discuss the MOQ if you need New design.
Q4:What is the production and delivery time?
A: We start production after receiving the prepayment and ship the products after receiving the final payment. You can choose shipping method such as sea, air, railway, express, etc. The logistics time is not more than 25 days.
Q5:What are your shipping methods?
A: Ocean freight, trailer transport, container railway transport, LCL transport and RO-RO transport.We offer you the most economical way of transport.
Q6:Can we accept customised service?
A: We can provide customised services for every buyer, whether they are suppliers, free buyers or purchasers. The range of customisation services includes wheels, outer packaging, logos, engraving.
A:Each of our wheels has passed strict quality tests (bending fatigue test, impact test, radial fatigue test), and has been certified by more than 10 industries(ATF16949 , ISO14001,OHSAS18000, TÜV, DOT, VIA, TIP, INMETRO, GOST and other certifications.), and each wheel comes with a 5-year warranty and $5 million in insurance from Allianz.
Q2: What information should I provide with my quote?
A:We need to know: car model and wheel size, PCD, CB, ET (offset), colour and quantity ordered in order to provide you with the best possible quote.
Q3:What is your MOQ?
A:4 Pcs for inventory, 80 Pcs for existing mould，We can discuss the MOQ if you need New design.
Q4:What is the production and delivery time?
A: We start production after receiving the prepayment and ship the products after receiving the final payment. You can choose shipping method such as sea, air, railway, express, etc. The logistics time is not more than 25 days.
Q5:What are your shipping methods?
A: Ocean freight, trailer transport, container railway transport, LCL transport and RO-RO transport.We offer you the most economical way of transport.
Q6:Can we accept customised service?
A: We can provide customised services for every buyer, whether they are suppliers, free buyers or purchasers. The range of customisation services includes wheels, outer packaging, logos, engraving.
