Product Overview
Construction Machinery Concrete Mixer Js750 (0.75m3) In Kyrgyzstan Equipment Js Series Twin Shaft Concrete Mixer Machine
JS750 Concrete Mixer:the mixing tank is made of extra-rigid material that reduces the risk of deformation during the
transportation(or in container) and during the full load operation. In addition, it can directly support the weight of aggregates hopper and scales to form a simple engineering concrete plant that can greatly decrease the occupation area of the plant.
transportation(or in container) and during the full load operation. In addition, it can directly support the weight of aggregates hopper and scales to form a simple engineering concrete plant that can greatly decrease the occupation area of the plant.
PRODUCT SPECIFICATIONS
JS750 Concrete Mixer Machine Introduction.
* JS750 Concrete Mixer Price is widely used for mixing stiff consistency concrete, semi stiff consistency concrete, light weight aggregate concrete and so on.
* JS750 concrete mixer machines can be used alone a separated concrete mixer or used as the mixing machine of HZS35 concrete batching plant.
* Inquiry us to get one set spare for free.
* JS750 concrete mixer machines can be used alone a separated concrete mixer or used as the mixing machine of HZS35 concrete batching plant.
* Inquiry us to get one set spare for free.
Item JS750 Concrete Mixer | Unit | Parameter |
Charging capacity | L | 1200L |
Discharging capacity | L | 750L |
Min. Productivity | m3/h | 35m3/h |
Max.aggregate size | mm | 60mm |
Overall Dimension | mm | 3100x3500x5620mm |
Weight | kg | 6100kg |
Discharging Open | Type | Hydraulic/[neumatic/Manual |
Discharging height | m | 1.5-4.1m |
Mixing blade | No | 2*7pcs |
Mixer power | kw | 30kw |
Lifting power | kw | 7.5kw |
Water pump | kw | 3kw |
JS750 Concrete Mixer Mixing System consists of motor, pulley, gearbox, gear, stirring device, mixing drum and other components. The main motor is connected to the secondary gear reduction box through a belt, and finally the two horizontally-connected stirring shafts are respectively rotated by the two pairs of open gears at the same speed.
JS750 twin shaft concrete mixer with the two shaft, and each shaft will have 7 numbers mixing arm and mixing blade, so this mixer shaft can working more eveness ensure the concrete with the high quality, also inside of the mixer with the liner, after long time using, if any parts broken, just need replace one liner
JS750 concrete mixer is feeded, the mixture to be mixed is placed in the hopper, the feeding system is started, and the wire rope pulling hopper is climbed upward.
JS750 concrete mixer matched the water pump can add the water and weighing in the top of mixer, this weighing system control by time relay
JS750 concrete mixer is manual type lubrication system, on the mixer matched two lubrication pump, when the workers operate, need add oil on this pump
JS750 concrete mixer can matched pneumatic discharge or hydraulic type, for the manual type, no matter which type customer choose all matched
JS750 twin shaft concrete mixer matched the water, oil separator, because it matched the air pipe, using this device can ensure the air is clean
JS750 twin shaft mixer track can matched according the discharging height, different height will using different length, we will supplier on offer also
Successful Project
Delivery Photos
Delivery Photos
Delivery Photos
Delivery Photos
Delivery Photos
Delivery Photos
Installation Photos
Installation Photos
Installation Photos
SIMILAR PRODUCTS
Welcome To Inquiry Us To Discuss More About The Concrete Mixer!!!
FAQ
Q How about the quality of Spark Machinery JS750 Concrete Mixer?
A Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection.Chinese top brands or world grade brands like Siemens motors etc are equiped.
Q How about the price of your Spark Machinery JS750 Concrete Mixer?
A As a manufactory, we can give you lower price than trade companies. Besides, customers from Alibaba can get a discount and ensurance.
Q Do you provide after-sale service?
A Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems.It usually takes 1-3 days for training , 10-15 days for installation,1-2days for commission,1-2days for pre-operation.
Q Do you provide equipment operation training?
A Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training.It's about 120 usd a day.
Q Can you test our samples?
A Yes. You can send your samples to us for test and analysis.
Q How long it takes to do all the installation
A It's at most 5days processing and manufacturing for single machine,for production line,at most 15days.
Q Can we visit your factory?
A Yes. You can visit our factory at anytime you want.
A Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection.Chinese top brands or world grade brands like Siemens motors etc are equiped.
Q How about the price of your Spark Machinery JS750 Concrete Mixer?
A As a manufactory, we can give you lower price than trade companies. Besides, customers from Alibaba can get a discount and ensurance.
Q Do you provide after-sale service?
A Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and thoroughly solve your problems.It usually takes 1-3 days for training , 10-15 days for installation,1-2days for commission,1-2days for pre-operation.
Q Do you provide equipment operation training?
A Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training.It's about 120 usd a day.
Q Can you test our samples?
A Yes. You can send your samples to us for test and analysis.
Q How long it takes to do all the installation
A It's at most 5days processing and manufacturing for single machine,for production line,at most 15days.
Q Can we visit your factory?
A Yes. You can visit our factory at anytime you want.
