20 40 футов контейнер 3 спальни планы дома расширяемый контейнерный дом
5 900,00 $
20 40 футов контейнер 3 спальни планы дома расширяемый контейнерный Дом Съемный
- Категория: >>>
- Поставщик: Hebei Jiacheng Integrated Housing Co. Ltd.Hebei Ltd.
Сохранить в закладки 1601215648550:
Описание и отзывы
Характеристики
You may also like
Products Show
EXPANDABLE CONTAINER HOUSE |
Type | Open Size | Total Area(㎡） | Loading Quantity | UNIT PRICE FOB TIANJIN(US$/Unit) | ||
Unit/40'OT | ||||||
A | 6320*5900*2650mm | 2200*5900*2650mm | 36.54 | 2 | ||
LIFE SPAN | more than 30 years | WATER PROOF | 99.9999% | |||
EARTHQUAKE RESISTANCE | Grade 10 | SOUND RESISTANCE | ≥30dB | |||
HEAT INSULATION | 0.506317W/(m^2·K) | WIND RESISTANCE | ≥120KM/Hour | |||
ROOF LIVE LOAD | ≥1.0KN/㎡ | FLOOR LIVE LOAD | ≥2.5KN/㎡ | |||
FIREPROOF GRADE | A | |||||
FRAME STRUCTURE | Middle Container | Top and bottom upright beams | 210*150*2.5mm and 80*100*2.5mm P shaped beams Q235B | ||
Top and bottom cross beams | 2.5mm shaped beams(Q235B) | ||||
top purlins | 40*60*2.5mm Q235B | ||||
bottom purlins | 40*80*2.5mm Q235B | ||||
side beams | 80*100mm Q235B | ||||
FRAME STRUCTURE | Side Containers | Top and bottom vertical beams | 40*60*2.5mm P shape Q235B | ||
top and bottom cross beams | 40*60*2.5mm P shape Q235B | ||||
bottom purlins | 40*80*2.0mm Q235B tubes | ||||
side wall frames | 40*60*2.5mm Q235B tubes | ||||
WALL PANELS | MIDDLE CONTAINER TOP PANEL | T75mm glass wool sandwich panel(side EPS panels) | |||
SEPERATING PANELS | T50mm EPS sandwich | ||||
FLOORING | Fireproof glass magnesium floor 15mm+1.5mm PVC floor leather | ||||
OTHERS | FOLDING HINGE HANGING HEAD | T4mm,Q235B |
FOLDING HINGE | 13mm,galvanized | |
TOP CONTAINER EXTERNAL | T0.5mm gal.steel sheet |
Can be customized according to your needs any size!
Please contact customer service, they will be professionally customized for you!
Please contact customer service, they will be professionally customized for you!
Prefabricated box house is a modular building product based on steel frame and light wall panel structure system. This product adopts the proprietary third-generation packing box technology, which is composed of top frame, bottom frame, corner post and interchangeable wall panels. It can be packaged, easy to install, and convenient for land or sea transportation. It can be used as an office, accommodation, restaurant , sanitary ware and combined large space use, which can meet the needs of construction site barracks, field work barracks, municipal resettlement houses and various commercial houses. It is currently widely used in Europe, Africa, Southeast Asia, North America, South America and the Middle East and other regions .
Rock Wool
New fire-proof rock wool sandwich panel is made of two layers of high-quality color coated steel plates or other precision-shaped metal plates. Vertical to the upper and lower layers of steel plates), high-strength, high-adhesion, and high-fire-proof adhesives are used to bond high-quality rock wool and metal panels to form a beautiful, flat, rigid and tough building board. The formed board has excellent fire protection, thermal insulation, environmental protection and other characteristics, providing an excellent choice for industrial building envelope systems.
Hebei Jiacheng Integrated Housing Co., Ltd. was established on December 22, 2021, with a registered capital of 10 million yuan. Its address is located in the Economic Development Zone of Fucheng County, Hengshui City, Hebei Province. Covering an area of over 50 acres, it has a production workshop of over 8,000 square meters with approximately 120 people. It is located in the Development Zone of Fucheng County, Hengshui City. The workshop covers an area of over 20,000 square meters and the stock of standing prefabricated houses is about 2000. Convenient and fast ordering and pulling at any time. The company is committed to building prefabricated integrated buildings, green and environmentally friendly, portable and fast residential buildings.
The prefabricated houses produced by our company are made of galvanized strip with high zinc content through cold pressing. Our main products include foldable container houses, detachable container houses, flat packaging container houses, expandable container houses, spacecraft, etc.
Through professional welding techniques, polishing, painting, packaging, the appearance is neat, bright in color, not deformed, does not peel off paint, does not change color, and is more durable. Prefabricated houses adopt modular
combinations. The walls, top and bottom are entirely made of fire-resistant materials, making them safer and more environmentally friendly. Houses are widely used in construction projects, such as office buildings, temporary accommodation, private dining, tourist landscapes, farmhouse accommodations, post disaster resettlement, and epidemic isolation.
combinations. The walls, top and bottom are entirely made of fire-resistant materials, making them safer and more environmentally friendly. Houses are widely used in construction projects, such as office buildings, temporary accommodation, private dining, tourist landscapes, farmhouse accommodations, post disaster resettlement, and epidemic isolation.
In the past few years since novel coronavirus, our company has actively participated in the construction of container hospitals in China.
Our products are also exported to many other countries and regions, such as North America, South America, East Asia, Africa, and Europe.
Since the earthquake in Turky, we have sent many container houses to Turky, and made contributions to the people and society of Turky in 2023.
FAQ
1.\tWhat is the advantage for expandable folding container houses?
You can assemble the expandable folding container house within 10 minutes,and you can fold and transfer the container houses to other place within very short time,and they can be reused for many times,and it has very good living effect.
2.\tYou are manufacture or trading company?
We are manufacture factory.And you are welcomed to visit us at any time.The quality control and sales team will show you our professionalism.Also you will get best and most competitive price after visiting us.
3.\tIs your price competitive compared with other companies?
Our business objectives are too give the best price with same quality,or best quality with the same price.We will do everything to reduce your cost and guarantee you get the best product that you paid for.
4.\tCan you send engineers or whole team to install my project?
We will give detailed installation drawings and video for free.We can send engineers as installation director or a team upon request if you really need them to,but you should pay the costs for that.
5.\tDo you accept container loading inspection?
You are welcomed to send an inspector,not only for container loading,but any time during the production time.
6.\tDo you offer designing service for us?
Yes,we could design full solution drawings as your requirements.By using Auto CAD,PKPM,MTS,3D3S,Tarch,Tekla Structures and etc.,we can design complex industrial building like office mansion,super marker,auto dealer shop,shipping mall,etc.
7.\tWhat is the delivery time?
Delivery time depends on order quantities.In general the delivery time to nearest seaport in China will be within 10 days after receiving the deposit.
8.\tHow can we get a quotation for our projects?
You can contact us by email,phone,Alibaba TM,Whatsapp,Skype and so on 24*7 and you will get quick reply.
You can assemble the expandable folding container house within 10 minutes,and you can fold and transfer the container houses to other place within very short time,and they can be reused for many times,and it has very good living effect.
2.\tYou are manufacture or trading company?
We are manufacture factory.And you are welcomed to visit us at any time.The quality control and sales team will show you our professionalism.Also you will get best and most competitive price after visiting us.
3.\tIs your price competitive compared with other companies?
Our business objectives are too give the best price with same quality,or best quality with the same price.We will do everything to reduce your cost and guarantee you get the best product that you paid for.
4.\tCan you send engineers or whole team to install my project?
We will give detailed installation drawings and video for free.We can send engineers as installation director or a team upon request if you really need them to,but you should pay the costs for that.
5.\tDo you accept container loading inspection?
You are welcomed to send an inspector,not only for container loading,but any time during the production time.
6.\tDo you offer designing service for us?
Yes,we could design full solution drawings as your requirements.By using Auto CAD,PKPM,MTS,3D3S,Tarch,Tekla Structures and etc.,we can design complex industrial building like office mansion,super marker,auto dealer shop,shipping mall,etc.
7.\tWhat is the delivery time?
Delivery time depends on order quantities.In general the delivery time to nearest seaport in China will be within 10 days after receiving the deposit.
8.\tHow can we get a quotation for our projects?
You can contact us by email,phone,Alibaba TM,Whatsapp,Skype and so on 24*7 and you will get quick reply.
