DGM BC-1050S автоматическая машина для высечки
4 703 916,20 ₽
4/6/8 Цветная Клейкая УФ флексографская офсетная печатная машина для этикеток
- Категория: >>>
- Поставщик: Wenzhou Daba Machinery Co. Ltd.
Сохранить в закладки 1601219390814:
Описание и отзывы
Характеристики
Product Description
* Self-adhesive paper,Self-adhesive thermal paper,thermal paper ATM etc.
* Self-adhesive film:Self-adhesive PE film,Self-adhesive PET film,Self-adhesive PVC film,etc.
* plastic film:Cpp film,PET film,PVC film,PE film,etc.
* Laminating Film.
* Paper material:kraft paper,paper cup paper,etc.
* Self-adhesive film:Self-adhesive PE film,Self-adhesive PET film,Self-adhesive PVC film,etc.
* plastic film:Cpp film,PET film,PVC film,PE film,etc.
* Laminating Film.
* Paper material:kraft paper,paper cup paper,etc.
Intermittent Label Offset Printing Machine adopts latest servo control system which can ensure the material nip steady and accuracy. It can free from the printing roller change.
The operation of this machine is faster, convenient and simple. PS plate intermittent printing hits the high level label demands from short run to long run. It’s the best choice for printing highest quality labels with lowest production cost.
The operation of this machine is faster, convenient and simple. PS plate intermittent printing hits the high level label demands from short run to long run. It’s the best choice for printing highest quality labels with lowest production cost.
Machine Parameter | ||||
Model | DBJY-320 | DBJY-450 | ||
Printing speed | 50-180 rpm/min | 50-150 rpm/min | ||
Printing color | 4-10colors | 4-10colors | ||
Max. printing length | 350mm | 380mm | ||
Max. web width | 320mm | 470mm | ||
Max. printing width | 300mm | 450mm | ||
Max. unwinding diameter | 700mm | 700mm | ||
Max. rewinding diameter | 600mm | 600mm | ||
Power supply | 3 phase 380V | 3 phase 380V | ||
Total power | 33.6kw(without UV power) | 40kw(without UV power) | ||
Dimensions(L×W×H) | 10550×1600×1800mm | 11150×1700×1800mm | ||
Main machine weight | about 9.5t | about 11.5t | ||
Details Images
1.Unwinding Unit
2.Web Guide
control paper move straightly
3.Heavy Offset Printing Unit
Printing unit: adopting high quality and heavy offset printing unit.
Assembled with 19 pieces of ink rollers,4pcs of Form Rollers and 4pieces of Water rollers (alchohol dampening system), has nice inking system which can largely avoid gear mark and ghost image.
The fine and accurate printing would never be reached by flexo/letterpress machine.
4.Shaftless Driving System
Every printing unit run by an independent servo motor, 15 sets of servo motors in total for whole machine (6color) to ensure the exact color registration during high speed operation.
The vertical and horizontal motions of every printing unit are all controlled by independent motor (ease the laboring and reduce the waste).
5.Video Inspecting System
By video still system, the machine can regulate vertical & horizontal registering without stopping, it improves the printing quality and increases the producing capacity.
6.Touch Screen Control System
Touch LCD screen, faster CPU, 12inch operating display, independent touch screen in each printing unit, powerful human-computer dialogue system, multi-guide inspecting display interface, instant alarm signal, makes operation much easier and more efficient.
7.Printing Unit Control Pannel
8.Computer Ink Control System
9.Traction Unit
10.Quality Checking Unit
11.Lamination Unit
12.Rewinding Unit
1.Second Pass Register Sensor
Super large printing area of 300x350mm, the max repeat length can go up to 350mm and the max running speed can be 63m/min.
By high-precision photocells, the machine ensures multi-register print on both side, make the possibility of label variety.
2.Cold Foiling Unit
Inline cold foiling, has the characteristic of fast speed, high efficiency, increase the decorative effect for color and graphic.
3.Rotary die cutting station
One big magnetic cylinder used in this machine, largely saves the tooling cost. Different die-cutting job can be achieved by
changing the flexible die.
changing the flexible die.
4.Flexo UV Varnishing Unit with Chamber System
Flexo UV varnishing unit (both solid and spot) makes the printing more shining and attractive.
5.Delam/Relam Unit
Delaminate the adhesive label , then printing on glue surface and re-laminating.
6.Screen Printing Unit
Inline flat screen printing, has characteristic of thick ink layer, strong relief perception.
Samples show
In Factory Photo
Our Service
1.Purchase Service
DABA COMPANY have a specialize and efficiency working team.If you are new onthe printing and packing area Some samples of your
products could be shew to uswill be appreicate we will give you specialized suggestion of whole work
DABA COMPANY have a specialize and efficiency working team.If you are new onthe printing and packing area Some samples of your
products could be shew to uswill be appreicate we will give you specialized suggestion of whole work
2.Shipping Service
DABA COMPANY have a spcialized and independent department which just for
shipping the buyer's goods.The workers are knowing T/T,L/C Items well.All Exporteddocuments could be made perfectly
DABA COMPNAY cooperate with the most famous shipping company in China also.
They could provide the best and economic shipping ways to the buyer's port.
DABA COMPANY have a spcialized and independent department which just for
shipping the buyer's goods.The workers are knowing T/T,L/C Items well.All Exporteddocuments could be made perfectly
DABA COMPNAY cooperate with the most famous shipping company in China also.
They could provide the best and economic shipping ways to the buyer's port.
3.Installation Services
Installation Services are available with all DABA Company machines.DABA Comapnywill dispatch technician to The Buyer's factory to
installation and preoperation ofmachines But the buyer need to surpply the round trip tickets food hotel cost.
Installation Services are available with all DABA Company machines.DABA Comapnywill dispatch technician to The Buyer's factory to
installation and preoperation ofmachines But the buyer need to surpply the round trip tickets food hotel cost.
4.Clients Training Services
DABA Company advise The buyer could send own technican come to DABA factoryto learn how to operate machines.DABA Company
technician will teach and train thelerners hand by hand till he can operate machine by himself.
Obviouslly,Traning within Installation period is acceptable.
DABA Company advise The buyer could send own technican come to DABA factoryto learn how to operate machines.DABA Company
technician will teach and train thelerners hand by hand till he can operate machine by himself.
Obviouslly,Traning within Installation period is acceptable.
5.After Sales Service
DABA Company machines guarantee time is one year.
Many easy broken spare parts will be prepared in the tool box together with
machines.Any parts broken Just a pictures or a videos.The new free parts will reachwithin 3-7 Express working days.
DABA Company machines guarantee time is one year.
Many easy broken spare parts will be prepared in the tool box together with
machines.Any parts broken Just a pictures or a videos.The new free parts will reachwithin 3-7 Express working days.
Company Information
Packing & Delivery
FAQ
Q: What's your delivery date?
A: Usually finish the production within 30days after your 30% advanced payment, actually need to check according our stock & production plan.
Q: Terms of payment?
A: We accept T/T, 30% in advance and 70% balanced against B/L copy. We accept L/C at sight. We accept Cash.
Q: How many days will you finish installing ?
Q: How many days will you finish installing ?
A: We will finish installation and training within 15days.
Q: How long is your machine's warranty period?
A: All our machine have one year guarantee, starting from finished installation.
Q: How could we do after one year warranty period?
A: We also can do service for you, however, if require overseas service, you need pay salary to our technician 100USD/day.
Q: How could we do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
Q: How many worker do we need running those machines?
A: For flexo printing, slitting, die-cutting machine, only need one person for each.
Q: What should we charge for your engineer?
A: You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 100USD one day per person.
