Многослойная промышленная просеивающая машина вращающийся вибрационный экран круговой Вибрационный
97 579,66-103 319,64 ₽
Ротационное сито для порошкового покрытия вибрирующее круглое сухое маниоки
- Категория: >>>
- Поставщик: Xinxiang Zhonghao Machinery Equipment Co. ltd.Xinxiang ltd.
Сохранить в закладки 1601224479405:
Описание и отзывы
Характеристики
Products Description
Performance and Characteristics:
1. Rotary vibration screen is a kind of Universal screening machine, it not only can be used for sieving dry powder and granules, it also can be used for filtering. It is widely used in industries such as food, pharmaceuticals, chemicals, minerals etc.
2. Small size, low noise, high efficiency, fast change the screen(3-5 minutes), fully closed structure.
3. The diameters have 400mm/600mm/800mm/1000mm/1200mm/1500mm/1800mm/2000mm.
4. Screen decks:1-5decks for 400-1200mm，1-3decks for 1500-2000mm.
5. Mesh cleaning method: Bouncing balls/ ultrasonic system / Rotary brush.(Refer the below pictures)
No mesh cleaning system
No mesh cleaning system is widely used for liquid filtering or removing the impurity from material.It should be the material easy pass through the mesh.
Bouncing balls
Boucing balls mesh cleaning system is widely used for the fine material has good fluidity,which is easy pass through the mesh.
Ultrasonic system
Ultrasonic mesh cleaning system is mainly used to solve the screening problems of materials with strong adsorption, easy agglomeration, high static electricity, high precision, high density, and light specific gravity
Rotary brush
The rotary brush cleaning system is mainly used for materials that are prone to static electricity and agglomeration,and it is easily be broken up.
Rotary vibration screen is made of an upright motor as a source of vibration, the motor is installed at the upper and lower ends of the eccentric heavy hammer, the motor rotation motion into horizontal, vertical, oblique three-dimensional motion, and then the motion to the screen surface. Adjust the phase Angle of the upper and lower ends to change the motion track of the material on the screen surface.
Details Images
Applied field
Chemical industry: resin pigment, calcium carbonate, decorative coatings, medicine, grease, paint, palette, etc.
Abrasive material and ceramic industry: building sand, mica, alumina, silica sand, abrasive, refractory material, slurry, etc.
Food industry: sugar,salt, alkali, flour powder, nut powder, whey protein powder , maltodextrin , flavors , sucralose , xanthan gum, soy lecithin,farina, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
Paper-making industry:coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
Metallurgy and mining industry: quartz sand,sand, ore, titanium oxide, zinc oxide, etc. Mechanical industry: casting sand, charcoal, grafito, powder metallurgy,electromagnetic material and metal powder, etc
Product Paramenters
Model | Diameter (mm) | Deck | Screen mesh area (mm) | Mesh size (Mesh) | Power (KW) |
XZS-400 | 400 | 1-5 | 380 | 3-500 | 0.55 |
XZS-600 | 600 | 600 | 3-500 | 0.55 | |
XZS-800 | 800 | 750 | 3-500 | 0.75 | |
XZS-1000 | 1000 | 900 | 3-500 | 1.1 | |
XZS-1200 | 1200 | 1100 | 3-500 | 1.5 | |
XZS-1500 | 1500 | 1-3 | 1450 | 3-500 | 2.2 |
XZS-1800 | 1800 | 1750 | 3-500 | 2.5 | |
XZS-2000 | 2000 | 1950 | 3-500 | 2.5 |
Product Display
Product Packaging
Company Profile
Xinxiang Zhonghao Machinery Equipment Co.,Ltd
Xinxiang Zhonghao Machinery Equipment Co., Ltd. is a company dedicated to the production and supply of vibrating sieve,mixer,pulverizer,feeder,conveyor etc. With years of experience and a professional team, we bring together expertise in this field. We uphold a philosophy of professionalism, precision, and outstanding service, aiming to provide our customers with high quality machines. We consider product quality as our lifeline, strictly adhering to rigorous quality control standards, and are committed to delivering high-quality products and services to our customers.
Due to our responsible attitude, good products, and reasonable prices, we have gained a good reputation from our customers. Currently, our company's products have been exported to the United States, United Kingdom, Spain, Argentina, Mexico, Australia, New Zealand, South Africa, Singapore, Indonesia, India, Philippines, Russia, Vietnam, etc.
FAQ
Q1：If you can advised the suitable sieving machine?
A1：Yes,sure,we have experienced engineer can help you recommend the suitable sieving machine.
Q2:Can I get special design for my own products?
A2: We have R&D department to offer customization service for our customer.
A2: We have R&D department to offer customization service for our customer.
Q3:What's the delivery time?
A3:7-15days for standard products,the delivery time of batches products or customized products will be depended on the situation.
Q4:How about the after-sale service?
A4:(1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.
(2) To solve the problems with videos/pictures.
(3) One years warranty for our machine(except the easy wear parts).
A4:(1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.
(2) To solve the problems with videos/pictures.
(3) One years warranty for our machine(except the easy wear parts).
