Cardlan CL-A818 public transport payment reader rfid touch screen pos system all in one Android tablet with thermal printer






818G working flow









Product Description



1. Application environment:


CL-A818 smart bus validator can support RFID card, with GPS positioning module, support GPRS, WIFI wireless communication etc. Can be used for electronic payment or card validation in following field:


Public transport fare collection


Scenic spots/amusement park card payment


Balance inquiry


Employee shuttle bus card validation


Safety school bus system


2. Functional features:


Big screen can play promote advertise video to make money for sponsor.


Support wireless communication, remote connect to server management software to realize real time time-revision, black-list downloading and data collection etc.


Support data real time uploading or USB local data collection


Support live voice prompts, supports 15 kinds of voice prompts: such as "student card",  "employee card"


Support consumption details and statistics query, according to card No., time, operator No. etc.


3. Technical specifications:











































































































Model: CL-A818B smart bus validaotr for public transportation Data capacity:

more than 2 million detailed data for console storage, unlimited data with 4G connection

Dimension:

270*172*28 mm

Card capacity: 91880,000 pcs
Material: Engineering Plastics(Anti static electricity coating design, be protected from high-frequency interference) Black list:

2 hundred million,more with TF card

Display:

8 inch TFT-LCD, 1280*800

Working Voltage:  DC 8V-50V
Operating system:  Android system 5.1 Data collection:  WIFI/GPRS wireless collection and USB local collection
CPU:

Quad-core cortex-a9 main frequency 1.4GHz,integrated GPU Mali-400 MP4

Operating temperature:  -25℃~65℃
Memory:

128MB NAND Flash main memory, support TF card, Max 32G

Storage temperature:  -45℃~85℃

Indicator light:

Red and green

Humidity: 0-90% RH non condensing
Sound prompting:

Buzzer,Single channel loudspeaker

Audio:

 8Ω ,2W

Flash Memory:

DDR3 1G(default)

RFID:

Can read and write ISO14443 Type A\\B Electronic tag

Read card distance:  0~50mm Frequency: 13.56MHz
Supporting card:

Mifare 1 card, CPU card, UnionPay IC card

Interfaces/Connectors:

USB-HOST,USB-OTG,RS485 or  TTL-232

Printing module:

 Support external POS 58 printer

(need 5pin aviation plug turn DB9 cable)

Width of receipt:  Thermal paper, 58 mm
Power consumption: ≤10 W

Wireless Communication:

GPRS.,3G,4G, WIFI optional

WIFI:

Support 802.11n/b/g standard,150Mbps,2.4Ghz

Voice Prompt:

16KHz,16bit single channel voice prompt
Upgrading: Connect USB to PC, upgrade with GPRS Position way:

GPS, Beidou positioning (Optional)

Working Mode:

 Stand-alone or connect to server Warning Function:  Warning when card balance is insufficient or data memory is full




PROVIDE FREE SDK, SUPPORT SECONDARY DEVELOPMENT TO TOPOLOGY YOUR OWN SPECIFIC FUNCTION !









Company Information


More than 22 years Factory Manufaturing Experience and Project Experience


Shenzhen Cardlan Technology Co. Ltd was established in 2000 in Shenzhen Longgang District.We specialize in manufacturing high-quality bus POS systems, fare collection POS systems, urban all-in-one card systems, intelligent internet information systems and other RFID systems. Cardlan has done so many kinds of project in foreign countries, such as Myanmar, Cambodia, United Kingdom, Chile, Zimbabwe, Thailand, United States, Tajikistan,Dubai, Russia,Qatar...









Packaging & Shipping


 Package for Bus card reader:
1. Each device with foam into a box.
2. 1 unit / gift box; 21 boxes / carton, carton size 57*51*30 cm.
3. 60 set of cables / carton, 56 kgs / carton, carton size 58*38*51 cm.
4. Packed as customers' request.







Quality Control


Strictly hightemperature/low temperature testing, Vibration testing, Waterprooof testing, to make sure all products can meet the extreme environment on bus.










Certifications







FAQ



A: Are you manufacturer?
    -Yes, we are a manufacturer, which is focus on R&D(research and develop) bus pos system with hardware&software since 2000.





A: Would you provide SDK?
    -Yes, we will offer free SDK for your own topology after (sample) order setted.





A: What warranty for the products?
    -According to our warranty policy, we will provide 12 months warranty time from the shipment date for all products (Excluded the consumable parts).





A: What is the minimum order?
    -We can accept one unit for standard products, for sample and manager system test.





A: Can I get the free sample?
    -Sorry, generally we would not provide free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.





A: Do you accept Paypal?
    -Yes, PayPal is available. Besides, we accept Western Union, T/T, L/C, Secure payment (Escrow Service from Alibaba) and so on.





A: What's the delivery time?
    -Generally, sample can be shipped in 2-3 working days after payment. For quantity, the leading time will be 1-4 weeks, depends on exact quantity and model.

A: Which way to deliver the goods?
    -By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.
    -By Sea: Inform us the Sea Port to check the ship line.
    -By Air: Inform us the Airport to check the flight.
    -Or pick up by the customers.

A: What the after sale service?
    -a. Our all products will provide 12 months warranty;
    -b. Enough stock spare parts for guarantee;
    -c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
    -d. As for the returned failure products, we will fix it and return to the customers in one week after we receive it;


    -e. We can remoting control to helps you solve problems.
