Автоматический полировщик с 9 головками

Сохранить в закладки 1601231101848:


Цена:2 023 777,90 ₽ - 2 078 474,60 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики





Product Information


Main function and characteristic
KBJX-9 terrazzo tile grinding polishing machine Multihead stone polishing machine machine with 9-12-16-18 heads, this machine is mainly for slab polishing. the struture is reasonable, steady performance, high work effiency. With the import PLC controlling systerm, text display is controlled intelligence.

1.Out airbag, long life using, lower hazard rate, lower maintenance cost, etc advantage.
2. With the best quality belt with famous brand, thickness accord, promise the thickness of the slab.
3. Belt move and bridge move is controlled with the automatic controlling system
4. With lower power (7.5kw single head), lower cost, Capacity is 38 square meter per hour. The brightness for G3786 can catch up 85 degree.
5.The control system of this machine adopts PLC terminal control with LCD touch screen terminal for parameter setting and faulte prompts during operationm etc. It is applicable to continuours grounding and polishing granite tile. Operating speeds of plate coverying and crossbeam of polishing disc are controlled by frequency converter. working pleasure and the polishing width of tile are adjustable within the setting values. This machine can also automatically identify the shape of tile, so that each polishing disc (polishing head) could automatically lift and lower according to the identified shape of tile, and conduct tracking records for tile polishing at the same time. The overall machine is produced according the standard requirements with performance up to the leading domestic level.
6. All the electrical parts adopt famous brand, the PLC is Siemens and other electrical parts mainly are Schneider, so these can ensure the machine’s stability and long-term working.


product name
KBJX-9 terrazzo brick polishing machine
Processing width
100-1000mm
Grinding heads
6-9
Grinding head diameter
200-300MM
Application
Terrazzo tile concrete marble granite quartz
Key word
terrazzo grinding machine
Motor
7.kw
Water consumption
cycle
Function
grinding and polishing
Product Keywords
terrazzo brick polishing machine
After Warranty Service
Video technical support
After Warranty Service
Spare parts
After Warranty Service
Field maintenance and repair service


Product Display
