Хорошее качество 40 м 50

Сохранить в закладки 1601231755744:


Цена:867 487,20 ₽ - 1 084 359,00 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики








1


2


3


3.2






















































































































































































































Chassis
BrandDSGK23DSGK28DSGK33DSGK45DSGK25
ChassisJMCDongfengJAC
Drive4 x 2
Dimensions(L x W x H)5995 x 2000 x 3000(mm)8350 x 2230 x 3250(mm)7800 x 2340 x 3400(mm)9720 x 2550 x 3920(mm)

5995 x 2000 x 2600(mm)


EngineIsuzu/Yuchai/ Cummins(customizable)
Gross Vehicle Weight4495 Kg7600 Kg10910 Kg14500 Kg 4495 Kg
Horsepower115 HP156 HP153 HP230 HP 115 HP
Emission StandardEuro VI
Braking systemOil brakeDead air brake Oil brake
Departure angle11°10° 11°
Max. speed99 Km/h115 Km/h100 Km/h98 Km/h 99 Km/h
Wheelbase3360 mm3815 mm4700 mm5000 mm 3360 mm
Approach angle27°20°17° 27°
Aerial work platform
Working platform dimensions1400 x 710 x 1200 mm2400 x 850 x 1200 mm3000 x 1200 x 900 mm3200 x 850 x 1200 mm 1600 x 700 x 1100 mm
Rated load200 Kg260 Kg320 Kg400 Kg 200 Kg
Max. working height23 m28 m32 m45 m 25 m
Max. operating range14 m16 m22 m28 m 11 m
Operating range at max. working height3 m5 m4 m3 m

 2.6 m


Working height at max. operating range14.5 m23 m26 m31 m

 11m





Working boomFour section hexagonal work BoomFour section hexagonal work Boom and one fly jibX-type hydraulic outrigger, separately controlled
PTO SystemMechanical operationElectronic operationSeven section synchronous telescopic boom
Rotary device360 deg continuous rotation
Derricking cylinder1 set2 set 1 set
Telescopic structureOil cylinder and wire rope
OutriggerFront V and rear H, separately controlledX-type hydraulic outrigger, separately controlled
Outrigger span(TVS)4350 mm5010 mm5370 mm8200 mm 4400mm
Outrigger span(I)4050 mm4845 mm5385 mm7300 mm 4100mm
Operation modeRemote / electric / manual
Emergency systemAutomatic
Control systemCAN bus control system
Leveling systemLiquid automatic leveling
Control voltage12 V24 V 12 V




4


7


8


9


10.1


10.2


10.3


10.4


11





12


     Shandong Capstone Machinery Co., Ltd. is a company in northern China specializing in the


design,production, processing, and export of hoisting equipment and construction equipment.


The company was established in 2015 and is located in Jining, the core industrial city of


Shandong. Province, China,  Economic Development Zone. At present, there are two


independent production plants, covering an area of more than 10,000square meters,


production R & D teams, a marketing department, and an after-sales department with more


than 300 people.The production area is equipped with automated cutting equipment, welding


equipment, shot blasting,spraying lines, and other modern technology production chains.


Integrate efficiency,intelligence,safety, and quality control into one.Capstone Machinery was


formerly two independent professional production and sales hydraulic construction


equipment and hoisting equipment companies. In order to integrate its supply chain and


research and development advantages and promote it as a world-class brand, the two


companies reached a strategic cooperation agreement in 2015 to form Capstone


Machinery jointly.


     Since 2015, Capstone Machinery has continuously developed and upgraded products,


striving to build a high-tech industry.All products have obtained ISO9001 ISO14001 ISO18001


CE Ro HS SGS.And obtained a number of patents, established a perfect sales network in


Europe and North America.Our products are sold in large quantities to more than 100


countries and regions such as Germany,  France, Italy, Spain, the United States, Canada,


Mexico, Peru, Brazil, the Middle East, Southeast Asia, etc., and are highly praised by customers.
