Product Description
Core Technical Parameters
Model | SSDH-24DH | SSDH-12DH | SSDH-9DH | SSDH-18DH | ||
Power supply | Ph-V-Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | |
Cooling | Capacity | Btu/h | 5763 | 3068 | 2900 | 3409 |
Input | W | 1908 | 1197 | 1123 | 1291 | |
Rated current | A | 8.9 | 5.48 | 5.15 | 5.94 | |
EER | W/W | 3.02 | 2.56 | 2.6 | 2.64 | |
Max. input power | W | 2480 | 798 | 560 | 838 | |
Max. current | A | 11.57 | 3.65 | 5 | 3.96 | |
Heating | Capacity | Btu/h | 6633 | 3061 | 3200 | 3885 |
Input | W | 2069 | 936 | 1100 | 1145 | |
Rated current | A | 9.7 | 4.29 | 5 | 5.28 | |
EER | W/W | 3.21 | 3.27 | 3.03 | 3.39 | |
Max. input power | W | 2689 | 624 | 960 | 763 | |
Max. current | A | 12.61 | 2.86 | 6 | 3.52 | |
Compressor | Model | KSN140D33UFZ3 | KSK75D43UEZA | KSK75D43UEZA | KSK89D33UEZD3 | |
Type | Rotary | Rotary | Rotary | Rotary | ||
Brand | GMCC | GMCC | GMCC | GMCC | ||
Indoor coil | a.Number of rows | 716-12-ⅡK7-1.4(QS) | 530-10-ⅡK7-1.3(QS) | 530-10-ⅡK7-1.3(QS) | 605-12-ⅡK7-1.3(QS) | |
Indoor air flow (Hi/Mi/Lo) | m3/h | 1081 | 481 | 469 | 593 | |
Indoor noise level | dB(A) | 48 | 48 | 48 | 48 | |
Indoor Fan motor | Type | cross flow | cross flow | cross flow | cross flow | |
output | W | 30 | 13 | 13 | 18 | |
Indoor Fan Speed | Cooling | rpm | 1150 | 1150 | 1150 | 1150 |
Heating | rpm | 1050 | 1050 | 1050 | 1050 | |
Dry | rpm | 950 | 950 | 950 | 950 | |
Sleep | rpm | 850 | 850 | 850 | 850 | |
Indoor unit | Dimension(W*H*D) | mm | 950*315*222 | 750*260*196 | 750*260*196 | 840*290*202 |
Packing (W*H*D) | mm | 1048*390*305 | 825*335*255 | 825*335*255 | 920*345*255 | |
Net/Gross weight | Kg | 14/16 | 8/9 | 8/9 | 10.5/12.5 | |
Outdoor fan motor | Type | axial fan | axial fan | axial fan | axial fan | |
Speed | r/min | 860 | 860 | 860 | 860 | |
output | W | 50 | 25 | 25 | 25 | |
Outdoor coil | a.Number of rows | 800-680-20-ⅡB7.94-1.4(QS) | 500-8-ⅠK7.94-1.4-8(QS) | 427-9-ⅠK7.94-1.4(QS) | 500-10-ⅠK7.94-1.4(QS) | |
Outdoor noise level | dB(A) | 50 | 50 | 50 | 50 | |
Outdoor unit | Dimension(W*H*D) | mm | 830*550*295 | 730*550*280 | 630*500*236 | 730*280*550 |
Packing (W*H*D) | mm | 905*373*599 | 845*371*590 | 750*332*528 | 845*371*590 | |
Net/Gross weight | Kg | 32/35 | 22/24 | 20.3/22.4 | 28/32 | |
Refrigerant type/Refrigerant charge | g | R32/1000g | R32/450g | R32/460g | R32/630g | |
Refrigerant piping | Liquid side/ Gas side | mm(inch) | Φ12Φ6 | Φ9Φ6 | Φ9Φ6 | Φ12/Φ6 |
Max. refrigerant pipe length | m | 15 | 15 | 15 | 15 | |
Max. difference in level | m | 5 | 5 | 5 | 5 | |
power cord/Connecting line | Electric wire | Core number x Size x Length | 16A 1.5mm2×3 1.5m | 16A 1.5mm2×3 1.5m | 16A 1.5mm2×3 1.5m | 13A 1.5mm2×3 1.5m |
I&O connection cable | Core number x Size x Length | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | 4×1.5mm2x (3.8m) | |
Operation temperature range | ℃ | 16~31 | 16~31 | 16~31 | 16~31 | |
Room temperature | Indoor(cooling/ heating) | ℃ | 43 | 43 | 43 | 43 |
Outdoor(cooling/heating) | ℃ | -7 | -7 | -7 | -7 | |
Application area (Cooling Standard) | m² | 20~37 | 16~26 | 10~15 | 15~30 |
SYLON Company And Factory Profile
Certificates
Exhibition
Our Brand Partners
Customer Arrival Feedback
Truck Loading And Dispatch
FAQ
1.what is the MOQ?
50set.
2.what is the payment terms?
LT,LC or TT.
3.what is the packing of the products?
Carton package or wooden package.
4.Can you do our brand?
Yes,we can.
5.Which kind of voltage and frequency is available?
220V/50HZ& 110V/60Hz 220V/60HZare available, OR others as customer's requirement.
6.Can you do our country's plug?
Yes,we can.
7.Can you make the printing artworks(such as user manual/packing/rating label) in our language?
Yes,we can.
8.Can you offer CKD/SKD for your products?
Yes, price normally 5-10% higher than normal one price.
