Гибридный однофазный 3 6 кВт безопасный и надежный удобный гарантированный инвертор для солнечной системы
- Категория: >>>
- Поставщик: Hochey Enertech Co. Ltd.
Сохранить в закладки 1601238220315:
Описание и отзывы
Характеристики
Quick Details | ||||||
Place of Origin: | Anhui, China | Brand Name: | Deye | |||
Model Number: | SUN- 3.6/5K/6k - SG03LP1-EU | Input Voltage: | 370V | |||
Output Current: | 16.4A/22.7A | Output Frequency: | 50/60Hz(Optional) | |||
Output Type: | Single | Size: | 330*580*232mm | |||
Type: | DC/AC Inverter | Inverter Efficiency: | 97.6% | |||
Certificate: | CE/TUV | Warranty: | 5 Years | |||
Weight: | 20.5kg | Product Name: | Deye Single Phase Hybrid Inverter 3.6/5/6KW | |||
Application: | Hybrid Solar Power System | Inverter Type: | Single Phase Hybrid Inverter | |||
Cooling: | Smart Cooling | Battery Type: | Lead Acid/Li-ion | |||
Interface: | RS485/CAN | Noise Emission: | <30dB | |||
Protection: | IP65 | Ambient Temperature: | -20~60℃ | |||
Supply Ability | ||
Supply Ability | 10000 Piece/Pieces per Week Solar Inverter | |
Packing & Delivery | ||
Packing Details | Deye Single Phase Hybrid Inverter 3.6KW 5KW Solar Inverter With Battery 1. Individual box packaging 2. Large quantities can be packed in wooden pallets or cartons 3. Packing can be customized according to customer needs | |
Port of Shipping | Shanghai port | |
Product Description
Single Phase Hybrid Inverter
SUN- 3.6K/5K - SG03LP1-EU
Model | SUN- 3.6K - SG03LP1-EU | SUN- 5K - SG03LP1-EU | ||
Battery Input Data | ||||
Battery Type | Lead-acid or Li-lon | |||
Battery Type | 40~60 | |||
Max. Charging Current (A) | 90 | 120 | ||
Max. Discharging Current (A) | 90 | 120 | ||
External Temperature Sensor | Yes | |||
Charging Curve | 3 Stages / Equalization | |||
Charging Strategy for Li-Ion Battery | Self-adaption to BMS | |||
PV String Input Data | ||||
Max. DC Input Power (W) | 4680 | 6500 | ||
Rated PV Input Voltage (V) | 370 (125~500) | |||
Start-up Voltage (V) | 125 | |||
MPPT Voltage Range (V | 150-425 | |||
Full Load DC Voltage Range (V) | 300-425 | |||
PV Input Current (A) | 13+13 | |||
Max. PV I (A) | 17+17 | |||
No.of MPP Trackers | 2 | |||
No.of Strings per MPP Tracker | 1 | |||
AC Output Data | ||||
Rated AC Output and UPS Power (W) | 3600 | 5000 | ||
Max. AC Output Power (W | 3690 | 5500 | ||
AC Output Rated Current (A) | 16.4 | 22.7 | ||
Max. AC Current (A) | 18 | 25 | ||
Max. Continuous AC Passthrough (A) | 35 | |||
Peak Power (off grid) | 2 time of rated power, 10 S | |||
Power Factor | 0.8 leading to 0.8 lagging | |||
Output Frequency and Voltage | 50/60Hz; L/N/PE 220/230Vac (single phase) | |||
Grid Type | Single Phase | |||
DC injection current (mA) | THD | |||
Efficiency | ||||
Max. Efficiency | 97.60% | |||
Euro Efficiency | 96.50% | |||
MPPT Efficiency | 99.90% | |||
Protection | ||||
Integrated | PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge protection | |||
Output Over Voltage Protection | DC Type II/AC Type III | |||
Certifications and Standards | ||||
Grid Regulation | CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 0126-1-1, RD 1699, C10-11 | |||
Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||
General Data | ||||
Operating Temperature Range (℃) | -45~60℃, >45℃ derating | |||
Cooling | Natural cooling | |||
Noise (dB) | <30 dB | |||
Communication with BMS | RS485; CAN | |||
Weight (kg) | 20.5 | |||
Size (mm) | 330W x 580H x232D | |||
Protection Degree | 330W x 580H x232D | |||
Installation Style | Wall-mounted | |||
Warranty | 5 years | |||
Project Cases
In US
In Pakistan
In England
In China
In Russia
In Germany
Certificate
Company Profile
Packing&Shipping
FAQ
Q: Are you manufacturer ?
A: Yes,we have our own R&D team and sales team,We provide you one-stop service.
Q: Do you have CE,ROHS,ISO?
A: Yes,our products are approved by CE,ROHS,ISO
Q: Is OEM &ODM available in your factory ?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2.All of the productions are inspected carfully by QC before delivery.
Q: What is your Delivery time?
A: Usually, we make merchandise inventory, if we have the products in stock,The delivery time is 5-10 days after receiving the deposit; If we don’t have the products in stock, we will arrange the production right now, the delivery time will be 10-30days,It depends on the quantity of order
Q: What is your Min.order?
A: There's no minimum quantity
A: Yes,we have our own R&D team and sales team,We provide you one-stop service.
Q: Do you have CE,ROHS,ISO?
A: Yes,our products are approved by CE,ROHS,ISO
Q: Is OEM &ODM available in your factory ?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2.All of the productions are inspected carfully by QC before delivery.
Q: What is your Delivery time?
A: Usually, we make merchandise inventory, if we have the products in stock,The delivery time is 5-10 days after receiving the deposit; If we don’t have the products in stock, we will arrange the production right now, the delivery time will be 10-30days,It depends on the quantity of order
Q: What is your Min.order?
A: There's no minimum quantity
Q:Why choose us?
A: 1. Ready To Ship 2. Sample Available
3. One-Stop Service 4. Online customization
5. Many years' experiences of manufacturing and service available in 24hours
A: 1. Ready To Ship 2. Sample Available
3. One-Stop Service 4. Online customization
5. Many years' experiences of manufacturing and service available in 24hours
Our Payment Term | ||||||||
Payment term | TT | EXW | ||||||
FOB/FCA | ||||||||
CNF CFR | ||||||||
CIF | ||||||||
DDU/DAP | ||||||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | |||||||
West union | Amount lower than 5000usd | |||||||
Delivery Time | 3~5days after receiving the payment | |||||||
Other payment | To be negotiable | |||||||
