Дизельная машина для подземных горных работ Jinwang с двигателем 56,5 кВт
3 220 546,23 ₽ - 3 231 389,82 ₽
Jinwang WJ 1 4 колеса шахты подземный Lhd/Scooptram дизельный двигатель Scooptram погрузчик туннель
- Категория: >>>
- Поставщик: Gongyi Xiaoyi Jinwang Machinery Factory
Сохранить в закладки 1601238840552:
Описание и отзывы
Характеристики
Product Description
Product Description
1. Jinwang Underground loader is a low-profile, centrally articulated, front-loading combined loading, transporting and unloading equipment specially designed for underground operations.
2. It can be used to remove ore and slag from the mining site, unload ore into low-level chutes, unload ore into higher transport vehicles or trucks, and can also use buckets to transport equipment, auxiliary materials, and repair and pave roads.
Main technical parameters
WJ-1 Internal Combustion Tire Scraper Load capacity | ||||||
Load capacity | 1 m3 | Radius of turning circle | 2000 mm | |||
Radius of turning circle | 4500 mm | Gap from the ground | 200 mm | |||
Angle of steering lock | 38° | Rated load | 2T | |||
Wheel base | 2200 mm | Maximun drawbar pull | 58 KN | |||
Peak pullout load | 48 KN | Total motor power | 56.5 KW | |||
Dumping reach | 860 mm | Shape Size | 6300x1300x2000mm | |||
Unload Height | 1100 mm | ≤8° | ||||
Climbing ability | ≤14° | machine quality | 6800kg | |||
Walking speed | 0-8km/h | Operation Mode | Forerunner | |||
The way of walking | Tire travel, puncture-proof smooth tire | |||||
Braking system | Centralized braking and parking braking in one, Central fully enclosed hydraulic multi-disc brake | |||||
Details Images
Slick tires is 10.00-20. It adopts smooth mining cut-resistant engineering tires, which have large load-carrying capacity, low ground pressure, strong wear resistance, puncture resistance, and long service life.
Hydraulic steering
Pilot control, fully hydraulic steering, easy and flexible operation.
Diesel engine Total motor power: 56.5 KW
Fuel tank stores the fuel that powers this loader.
Mining scraper operation area
Oil pressure gauge and air pressure gauge are clear at a glance
Scraper bucket
Using national standard 15mm thick wear-resistant steel plateFuel Filter
Prevents unwanted materials from entering the oil supply system
Filter
Comfortable seats
The left one is the throttle, the right one is high and low speed
