Products Description

Powerful Industrial 3D Crystal Inner Engraver

Heavy-duty design, based on cast aluminum structure, and high-quality optical components guarantee strength and low maintenance.

Technical Specifications

Model	Ki5 inner 3D
Laser technology	UV laser, wavelength 355 nm
Laser power	5w
Frequency	10~150 kHz
Pulse width	12ns@30kHz
Scanner speed	Up to 5 m/s (198 in/s)
Lens quantity	2 pcs
Lens size/Engrave size (mm)	110110mm, 5050mm
Filed lens size (in)	4.34.3 in, 22 in
Communication interfaces	Ethernet
Compatible software	Keyso 3D inner
Laser safety classification	Class 4
Z axis stroke	300 mm
Power consumption rate	480 W without water chiller 840W with water chiller
Rated voltage	110~250 VAC, 50~60 Hz
Operating temperature	10 to 40°C (50 to 104 F)
Humidity level	10-85%
Net weight	30 kg (without water chiller)
Package size	LWH=805045 cm
Package weight	35 kg (without water chiller)

Overall Dimension

Compact design, small size, space saving

Features of KEYSO K fiber Series

3D crystal inner engraver & UV laser marking

1 machine for 2 functions, budget saving for 3D crystal inner engraving and UV laser marking

Extruded aluminum head and case

Integrated design, small size, cut by high accuracy CNC center
Anodized dyeing for durable color

Industrial standard laser source

5W UV laser source, 355 nm wavelength, 15000 hours laser life

A real high-speed scanner

Rated marking speed 5m/s
Rated positioning speed 10m/s
With 2 red light indicator

**Note:
5m/s tested in condition of 2mm front in 150*150mm lens.

Integrated laser path

Small size, fully enclosed laser path

With 2 red light indicator

Double lens

Equipped with 2 field lenses as standard

50mm lens for higer power density

110mm lens for bigger engrave area

Easy maintenance

Fully screw mounted, easy access to all parts, low maintenance cost

Software KeysoCAD 3D inner

KeysoCAD 3D inner software support Windows 7 to windows 11

Support 3D inner engrave

Support UV flat surface laser marking

Exquisite accessory package

CE certified OD6+ grade protective goggles 1 pcs

*Optical density (OD) is used to express the percentage of laser light of a specific wavelength that can pass through laser protective glasses.
*For example: OD1+: indicates that 10% of laser of a specific wavelength can pass through laser protective glasses.
*The same principle is as follows:
OD5+:0.0001%
OD6+:0.00001%
