OEM BGA станция для переделок инфракрасная сварочная машина SMD продается Автоматическая переделка цена Китай
551 056,50 ₽ - 661 267,80 ₽
Подгонянная станция для переоборудования BGA нижняя SMD паяльная переделочная машина SMT
- Категория: >>>
- Поставщик: Dongguan ICT Technology Co. Ltd.
Сохранить в закладки 1601244463615:
Описание и отзывы
Характеристики
Customized BGA Rework Station Bottom SMD BGA Rework Soldering Station Rework Station SMT Machine
Products Description
I.C.T BGA Rework Station BR120
Features:
A. Independent 3 heating zones temperature control system
1.The upper and lower hot air heating,which can heat up at the same time from the top of he component to the bottom of
the PCB;bottom IR heating,temperature precision control within ±1℃.8 segment temperature control independently.
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and
combine freely the energy of up and lower heating element.
1.The upper and lower hot air heating,which can heat up at the same time from the top of he component to the bottom of
the PCB;bottom IR heating,temperature precision control within ±1℃.8 segment temperature control independently.
2.Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and
combine freely the energy of up and lower heating element.
B. Precision optical alignment system
Using high definition and adjustable CCD color optical alignment system,beam split、amplification、lessening、fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.
Using high definition and adjustable CCD color optical alignment system,beam split、amplification、lessening、fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast;equipped with 15 ” high definition LCD monitor.
C. Multi-functional and humanized operation system
Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many
kinds of titanium alloy BGA nozzle can be rotated in 360 degree for easy installation and replacement.
X、Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.
Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many
kinds of titanium alloy BGA nozzle can be rotated in 360 degree for easy installation and replacement.
X、Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.
D. Superior safety protection function
With the alarm function, after the BGA welding the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password
protection to prevent any modification.
With the alarm function, after the BGA welding the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password
protection to prevent any modification.
Specification :
Power supply | AC 220V±10％ 50/60Hz |
Total power | Max 5300W |
Heater power | Upper temp.zone 1200W,second temp.zone 1200W,IR temp.zone 2700W |
Electrical material | Driving motor+PLC smart temp.controller+color touch screen |
Temperature controlling | high precision K-sensor,Closed Loop,independent temp.controller,the precision can reach ±1℃ |
Locating way | V shape slot,PCB support jigs can adjust,laser light do fast centering and position |
PCB size | Min 10×10 mm--Max 450×390mm |
Applicable chips | Min 1×1 mm--Max 80×80mm |
Overall dimension | L650×W630×H850mm |
Temperature Interface | 1 pcs |
Weight of machine | 65KG |
Color | Red ( optional: white/blue) |
Certifications
Packing & Delivery
※ Standard Wooden Case with Vacuum Package
Shipping Way:
※ By air, for sample and small package, international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.
Delivery Time:
※ Within 35 Days.
※ By air, for sample and small package, international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.
Delivery Time:
※ Within 35 Days.
Our Company
About I.C.T：
I.C.T is a leading provider of factory planning solution. We have 3 wholly-owned factories, providing professional consultation and services for global customers. We have more than 22 years of electronic industry experience, through our superior resources in China to provide global customers with systematic overall solutions. We not only provide a complete set of equipment, but also provide full range of technical support and services, and give customers more reasonable professional advice. We help many customers to set up factories in LED, TV, mobile phone, DVB, EMS and other industries all over the world. We are trustworthy.
Exhibition
Customers' Feedback
FAQ
Q: What we can do for you? A: One-stop SMT Solution Supplier; Reliable SMT Partner |
Q: Are you a trade company or manufacturer? A: Full SMT machines maufacturer for smt line in China; OEM & ODM service are available. |
Q: What is your delivery date? A: About 35 days after receipt of payment. |
Q: What is your payment terms? A: 30% deposit in advance and 70% balance before shipment. |
Q: What your main customers? A: Huawei, Foxconn, Vtech, Sumida, Kemet, Vishay, Bosch, Canon, Jabil etc. |
Q: Why choose you? A: Leading SMT Supplier in China; Professional Supplier on Alibaba; Trade assurance to USD 560,000+; Professional after-sales service team. |
