Тренажерный зал 20 современная вилла контейнерный дом импортер с раковиной Geelong
109 987,99 ₽ - 219 314,72 ₽
Фабричный 20ft 40ft передвижной дом складной сборный временное офисное общежитие модульный контейнерный
- Категория: >>>
- Поставщик: Zhengzhou Dieye Trading Co. Ltd.
Сохранить в закладки 1601249841387:
Описание и отзывы
Характеристики
Container House Parameters | ||||
Size | 20FT/40FT Customized | |||
Life span | More than 35 years | |||
Steel Frame | Main Beam For Floor And Bottom | Galvanized formed beam | ||
Thickness:3.0mm,2.5mm,2.3mm | ||||
Top Frame | C shape steel:C80*1.3mm,galvanized | |||
Square tube: 20*20*1.0mm,galvanized | ||||
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³ | ||||
Bottom Frame | Square tube: 50*100*1.2mm,galvanized | |||
Insulation:75mm fiber glass wool with sliver paper,density:14kg/m³ | ||||
Column | Galvanized steel Column | |||
Corner fitting | Galvanized steel | |||
Wall system | 75mm Sandwich Panel | 75mm rock wool board,density≥80kg/m3 | ||
Floor | Fiber Cement Board | Thickness :18mm | ||
Vinyl flooring | Thickness:1.6mm/2.0mm | |||
Roof | Ceiling | V-831 type,0.4mm Integrated Color Steel Sheet | ||
Window | Sliding Window | 925mm*1100mm | ||
Door | Steel Security Door | 840mm*2035mm | ||
Electrical Device | 100V- 250V, 2P63A, Using IP44 standard power distribution box. main power cable is 6m², AC cable is 4m², socket cable is 2.5m²,lighting & switch cable is 1.5m². Four sockets, 1pc AC socket of three holes 16A, 3pcs socket of five holes 10A. 1pc single connection switch, 2pcs LED light,2*15W.ADAPTS power supply according to different countries and regions | |||
Accessories | Screw ,Blot, Silicon sealant,etc | |||
Product Display
All visible parts of the house can be customized，including doors, windows, interior and exterior walls, roof, interior layout，etc. Color,material, version, thickness, etc. can be customized according to customer needs.
Products Description
1.The internal flooring of our houses features a 20mm calcium silicate board and anti-corrosive multi-layer bamboo-wood composite board. Our composite board undergoes special treatment, with a coated surface using a process that is waterproof, moisture-resistant, and anti-corrosive.
2.The house walls are constructed with fire-resistant and flame-retardant 75mm EPS sandwich panel, coupled with a lightweight steel frame design. This ensures strong structural waterproofing, seismic resistance, excellent thermal insulation, and robust resistance to moisture and termite damage.
3.We use polyurethane adhesive sealant instead of traditional oil-based sealants. The polyurethane sealant provides superior sealing, meeting your requirements without causing any issues such as leakage.
4.All doors and windows are crafted using aluminum alloy materials and double-layer insulated glass, offering effective thermal and sound insulation with heightened security.
5.We take care of the installation of plumbing and electrical systems, ensuring compliance with your country's electrical safety standards.
20FT Prefabricated Expandable Container House Prefab Villa
External Dimensions (mm) W 6320*L 5900*H 2480
(Inches)W 249*L 232*H 98
Internal Dimensions (mm) W 6160*L 5450*H 2240
(Inches)W 243*L 215*H 88
Folding state (mm) W 2200*L 5900*H 2480
(Inches)W 87*L 232*H 98
20FT Expandable house The house is 12㎡ before folding, and occupies an area of 37㎡ after opening
(Inches)W 249*L 232*H 98
Internal Dimensions (mm) W 6160*L 5450*H 2240
(Inches)W 243*L 215*H 88
Folding state (mm) W 2200*L 5900*H 2480
(Inches)W 87*L 232*H 98
20FT Expandable house The house is 12㎡ before folding, and occupies an area of 37㎡ after opening
The basic layout of the 20ft house includes two bedrooms, a kitchen, a living room, and a bathroom. The kitchen will be equipped with cabinets and a sink, while the bathroom will have facilities such as a shower, a bathroom cabinet, and a toilet. All doors,windows, flooring, internal wiring, switches, sockets, and drainage pipes will be installed within the house for convenient use.Moreover, we will provide sockets and switches that comply with the standards of your country.
40FT Prefabricated Expandable Container House Prefab Villa
40 ft standard internal configuration: 3 bedrooms, kitchen, bathroom and living room. (Covering an area of 74 ㎡) 3 bedroom layout
1) Opening Size: 11800mm * 6240mm * 2480mm closing size: 11800mm * 2200mm * 2480mm
1) Opening Size: 11800mm * 6240mm * 2480mm closing size: 11800mm * 2200mm * 2480mm
2)75mm and 50mm eps sandwich panels for walls and roofs
3)18mm reinforced MGO board +2.0mm pvc floor tile
4) equipped with one aluminum double glass hinge door (W1900 * H 2230mm), 12 aluminum double glass push-pull windows (930 * 930mm), and one quick water heater;
5) live, DB CTN, switch, socket, air conditioning socket, wire, etc;
6) with bathroom (shower, shower plate, toilet, washbasin, pipe) It has three bedrooms 7) kitchen 2 M +2.2 m long
Exhibition
Packaging and Shipping
Folding container house saving the space and transportation costs greatly.
Company Profile
Zhengzhou Dieye Trading Co., Ltd.
Dieye is a large-scale modern modular house producing company that integrates research and development, design, production, sales, and installation. Founded in 2019, the company has a total investment of 80 million yuan .
The company mainly produces prefabricated box house series, light steel house series, and large steel structure product series; The company's products are widely used in new urban construction, tourist attractions, industrial factories, and temporary housing for various small and medium-sized construction enterprises.
FAQ
1. Do you provide on-site installation service?
We provide very detailed installation instruction drawings and videos for every project. For large projects, we will have both installation workers and supervisors on site. The fee for the on-site service should be negotiated with clients.
2.What's your delivery time?
Normally, delivery time is 7-10 days after deposit received. For large order, the delivery time should be negotiated.
3.How to control the quality of your product?
1. quality of the design: think about possible problems in advance and provide a high-quality design solution.
2. quality of the raw material: choose the qualified raw material
3. quality of the production: precise manufacturing technique, experienced workers, strict quality inspection.
4. How to deal with quality problems?
Warranty is 2 years. Within the warranty period, Dieye will responsible for all quality problems caused by our production.
5. If there is a clear service life of your products? If have, how long?
Under conventional climate and environment, the service life of container house steel frame is 20 years
6. What designs do you have in different climates (How can the products adopt to different climates)?
Strong wind region: improve the wind-resisting ability of the internal structure. Cold region: increase the thickness of the wall,or use good insulation material, improve anti-pressure ability of the structure. High corrosion region: use corrosion resistant material, or paint anti-corrosive coating.
We provide very detailed installation instruction drawings and videos for every project. For large projects, we will have both installation workers and supervisors on site. The fee for the on-site service should be negotiated with clients.
2.What's your delivery time?
Normally, delivery time is 7-10 days after deposit received. For large order, the delivery time should be negotiated.
3.How to control the quality of your product?
1. quality of the design: think about possible problems in advance and provide a high-quality design solution.
2. quality of the raw material: choose the qualified raw material
3. quality of the production: precise manufacturing technique, experienced workers, strict quality inspection.
4. How to deal with quality problems?
Warranty is 2 years. Within the warranty period, Dieye will responsible for all quality problems caused by our production.
5. If there is a clear service life of your products? If have, how long?
Under conventional climate and environment, the service life of container house steel frame is 20 years
6. What designs do you have in different climates (How can the products adopt to different climates)?
Strong wind region: improve the wind-resisting ability of the internal structure. Cold region: increase the thickness of the wall,or use good insulation material, improve anti-pressure ability of the structure. High corrosion region: use corrosion resistant material, or paint anti-corrosive coating.
