Model | BDM300 | BDM500 | BDM600 | BDM800 | |||
Recommended Max PV Power | 450w | 750w | 450w*2 | 600w*2 | |||
Max DC Input Current | 14A | 15.5A | 14A*2 | 17A*2 | |||
MPPT Tracking Accuracy | >99.5% | ||||||
MPPT Tracking Range | 22-55V | 35-55V | 22-55V | 22-55V | |||
Isc PV (absolute maximum) | 18A | 14A | 18A*2 | 20A*2 | |||
Rated AC Output Power | 300W | 500W | 500W | 800W | |||
Nominal Power Grid Voltage | 240V/208V/230V | ||||||
Allowable Power Grid Voltage | 211-264*/ 183-228*/ Configurable | ||||||
THD | <3% (at rated power) | ||||||
Nominal Frequency (Hz) | 50HZ/60HZ | ||||||
Protection Degree | NEMA-6 / IP-66 / IP-67 | ||||||
Ambient Temperature | -40°F to +149°F (-40°C to +65°C) | ||||||
Display | LED LIGHT | ||||||
Comunications | Power Line | ||||||
Dimension (W-H-D) | 180x186x25 mm | 277x132x50 mm | 277x132x50 mm | 268x250x42 mm | |||
Weight (including AC cable) | 3.3 lbs. (1.5 kg) | 8.8 Ibs. (4.0 kg) | 6.4 Ibs. (2.9 kg) | 6.4 Ibs. (2.9 kg | |||
Pollution Degree | PD3 | ||||||
Overvoltage Category | II(PV), III (AC MAINS) |
