10V - 14V 500mA 5W 7W Диммируемый светодиодный драйвер PF меньше 0 9
287,00 ₽
СВЕТОДИОДНЫЙ драйвер с фазовой резкой 12 В 200 Вт
- Категория: >>>
- Поставщик: Guangdong Linkuan Smart Tech Co. Ltd.Guangdong Ltd.
Сохранить в закладки 1601258015595:
Описание и отзывы
Характеристики
Product Description
Linkuan Power - Manufacturer of dimmable LED driver over 10 years
Linkuan Power carries a dynamic selection of dimmable drivers for all of your project needs. We've harnessed the power of electronic dimming technology to give you a variety of flicker-free dimming experiences. If you are planning to install your LED strip lights or LED light bars to an Lutron / Leviton AC Dimmers,you will need to get a dimmable driver.
Product Features
Phase cut led driver cULapproved led driver 12v 200W High Power Factor dimmable led driver for LED fixture Outdoor
3 in 1 dimming series are Constant Voltage Class 2 rated UL Listed LED drivers. The drivers with enclosures have a built-in junction box in one side for both the input and output. These drivers are IP66 rated and are suitable for both indoor and outdoor installations. With universal input voltage ranging from 120 to 277VAC, they are designed for residential, commercial and industrial applications. The dimmers deliver smooth flicker-free dimming down to 1% with most LEDs and compatible with a wide variety of dimmers. As always, a 5-year warranty is a standard on all of Linkuan products.
Our new IC for this series of LED drivers are class 2 rated and designed to operate with most dimming standard of 0-10V, PWM and TRIAC (Phase-cut) dimmers by brands such as Lutron and Leviton, which are commonly used in home and commercial installations, and widely available. Encased in a low profile aluminum enclosure that includes 1 knock-outs to enable easy installation makes it the perfect choice for under cabinet lights, tape lights and various LED fixtures installations. Our electrical specification includes Auto Reset, over current and short circuit protection, and allows the driver to operate at low temperatures. Offered in a variety of wattages in 12V, 24V ,36V and 48V DC models.
Product Paramenters
INPUT | Input Voltage | 120-277VAC | |
Input frequency | 50/60Hz | ||
Power Factor | 0.9 | ||
OUTPUT | DC Voltage | 12V/24V/48VDC | |
Rated Current | 1.67A/8.30A/4.13A | ||
Rated Power | 200W | ||
SETUP Rise Time | <0.5s | ||
PROTECTION | Short circiut | Recovers automatically after fault condition is removed | |
Overload | Overload protected @110-130% above peak rating | ||
Over Temperature | Shut down o/p voltage . re-power on to recover | ||
IP Code | IP20/IP66 | ||
ENVIRONMENT | Working TEMP. | -30-+50℃ (refer to output load derating curve) | |
Storage TEMP. | -40-+80℃ | ||
Safety & EMC | Safety Standards | UL | |
EMC Test Stardands | FCC | ||
DIMENSION | 365x70.5x43.5mm | ||
Details Images
Certifications
Our products have TUV,CE,SAA,UL,FCC,CCC certifictes.
Installation Dimension
Installation Diagram
Related Products
Input voltage:200-240Vac
Output Power: 24WOutput Voltage: 12/24Vdc
Output Current: 2A/1A
Dimming type: Triac Dimming
Input voltage:200-240Vac
Output Power: 50W
Output Voltage: 12/24Vdc
Output Current: 4A/2A
Dimming type: Triac Dimming
Output Power: 50W
Output Voltage: 12/24Vdc
Output Current: 4A/2A
Dimming type: Triac Dimming
Input voltage:200-240Vac
Output Power: 60W
Output Power: 60W
Output Voltage: 12/24Vdc
Output Current: 5A/2.5A
Dimming type: Triac Dimming
Output Current: 5A/2.5A
Dimming type: Triac Dimming
Input voltage:200-240Vac
Output Power: 2100W
Output Power: 2100W
Output Voltage: 12/24Vdc
Output Current: 8A/4A
Dimming type: Triac Dimming
Output Current: 8A/4A
Dimming type: Triac Dimming
Input voltage:200-240Vac
Output Power: 200W
Output Power: 200W
Output Voltage: 12/24Vdc
Output Current: 16.5A/8.3A
Dimming type: Triac Dimming
Output Current: 16.5A/8.3A
Dimming type: Triac Dimming
Company Profile
About Linkuan Power
Guangdong Linkuan Smat Tech Co., LTD. (hereinafter referred to as Linkuan Smart), formerly known as Dongguan Linkuan Semiconductor Lighting Co., Ltd., was founded in 2007. It is located in Dongguancity, a famous manufacturing city in China.The company plant area is about 4500 square meters, the registered capital is 10 million yuan, the staff is about 150 people, inclduing 30 management, engineering and technical persons.The company has 4 automatic production lines, 2 wave soldering machines, 5 sets of automatic constant temperature burning-test equipment, ultrasonic wave equipment and other efficient production equipment.
Factory Show
R&D Ability
Our Team
Delivery
Fast Delivery
Samples orders: 1-3 days
Less than 50pcs should be sample order to us
Less than 50pcs should be sample order to us
OEM orders: 7-10 days
Avaialbe for quantity within 1000pcs and 80W LED drivers
Avaialbe for quantity within 1000pcs and 80W LED drivers
FAQ
1. What are your market reach throughout the region?
Our markets around the world in every corner, we have three years of experience in foreign trade, our customer base has, we have worked with us in every country buyers and producers.
Our markets around the world in every corner, we have three years of experience in foreign trade, our customer base has, we have worked with us in every country buyers and producers.
2. What is your main product line is made?
We mainly produce led Power Supply and led Drivers, including drivers special for MR16 bulbs, tube series, waterproof series, SAA series, TUV series and UL series with both dimmable and non-dimmable. We also have 0-10V dimming and DALI dimming drivers for your option.
We mainly produce led Power Supply and led Drivers, including drivers special for MR16 bulbs, tube series, waterproof series, SAA series, TUV series and UL series with both dimmable and non-dimmable. We also have 0-10V dimming and DALI dimming drivers for your option.
3. Your factory or trading company?
We are a factory, we provide OEM/ODM services.
4. You have the ability to do independent research and development?
Our engineering department has 4-5 people, we have the research and development capabilities. We also collect regularly each customer feedback, product improvement and new product development.
5. If I have a question I would like advice on how to contact you?
You can leave messages directly through major inquiry or send e-mail to consult us.
6. What will you provide services?
If you do not mind, you can tell us the following information, you are factories, wholesalers, purchasing, dealers, consumers or do engineering,design, or home. We can provide a detailed explanation to you. You will also patiently answered every question. We have established a customer complaint side, if you are not satisfied with our service, you can directly tell us via e-mail or telephone. We answer all questions for you.
We are a factory, we provide OEM/ODM services.
4. You have the ability to do independent research and development?
Our engineering department has 4-5 people, we have the research and development capabilities. We also collect regularly each customer feedback, product improvement and new product development.
5. If I have a question I would like advice on how to contact you?
You can leave messages directly through major inquiry or send e-mail to consult us.
6. What will you provide services?
If you do not mind, you can tell us the following information, you are factories, wholesalers, purchasing, dealers, consumers or do engineering,design, or home. We can provide a detailed explanation to you. You will also patiently answered every question. We have established a customer complaint side, if you are not satisfied with our service, you can directly tell us via e-mail or telephone. We answer all questions for you.
You are pleased to contact me directly if need my help
