GS серии Dc/Ac инверторы оптом Гибридные солнечные 10 кВА 48 В
450,00-488,00 $
Двойной выход переменного тока чистый синусоидальный инвертор 4 2 кВт 24 В 220 гибридный солнечный зарядное устройство встроенное 120 А MPPT с Wi Fi
- Категория: >>>
- Поставщик: Shenzhen Jieyin New Energy Technology Industry Co. Ltd.Shenzhen Ltd.
Сохранить в закладки 1601260490384:
Описание и отзывы
Характеристики
Product Description
High Frequency 6.2KW 48V 220V Inverter Charger Built-in 120A MPPT Charge Controller Pure Sine Wave 6200W Hybrid Solar Inverter
Inverter Main Spec:
PF=1.0, 6.2KW Rated Power, Dual AC Output
6500W PV Array Power
220/230VAC Output, 50/60Hz Auto
48VDC Battery System, ONLY Support PACE BMS Communication
Built in 120A MPPT, MPPT Voc 500Vdc
Warranty 1 Year
6500W PV Array Power
220/230VAC Output, 50/60Hz Auto
48VDC Battery System, ONLY Support PACE BMS Communication
Built in 120A MPPT, MPPT Voc 500Vdc
Warranty 1 Year
This is a multi-function inverter/charger, combining functions of inverter, solar charger, and battery charger to offer uninterruptible power support with portable size.
Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
The solar charging module applies the latest optimized MPPT technology to quickly track the maximum power point of the PV array in any environment and obtain the maximum energy of the solar panel in real time and output pure sine wave to convert DC into AC.
It can be widely used in DC to AC areas, such as solar AC power system, vehicle system, RV power supply, security monitoring system, emergency lighting system, field power system, household power system, etc.
Features
•Pure sine wave inverter
•Configurable input voltage range for home appliances and personal computers via LCD setting
•Configurable battery charging current based on applications via LCD setting
•Configurable AC/Solar Charger priority vía LCD setting
•Compatible to mains voltage or generator power
•Auto restart while AC is recovering
• Overload/ Over temperature/ short circuit protection
•Smart battery charger design for optimized battery performance
•Cold start function
•Configurable input voltage range for home appliances and personal computers via LCD setting
•Configurable battery charging current based on applications via LCD setting
•Configurable AC/Solar Charger priority vía LCD setting
•Compatible to mains voltage or generator power
•Auto restart while AC is recovering
• Overload/ Over temperature/ short circuit protection
•Smart battery charger design for optimized battery performance
•Cold start function
Specification
Model Name | MPS-VIII ECO 4.2KW | MPS-VIII ECO 6.2KW | ||
Inverter Output | ||||
Rated Output Power | 4200W | 6200W | ||
Max Peak Power | 8400VA | 10,000VA | ||
Rated Output Voltage | Single Phase 230Vac | |||
Rated AC Frequency | 50/60Hz | |||
Waveform | Pure Sine Wave | |||
Switch Time | 10ms(for personal computer), 20ms(for home appliances) | |||
Battery | ||||
Battery Type | Li-ion/Lead-Acid / User Defined | |||
Rated Battery Voltage | 24Vdc | 48Vdc | ||
Floating Charge Voltage | 27Vdc | 54Vdc | ||
Over Charge Protection | 31Vdc | 61Vdc | ||
Max MPPT Charging Current | 100A | 100A | ||
Max Mains/Generator Charging Current | 40A | 50A | ||
Max Hybrid Charging Current | 120A | |||
PV INPUT | ||||
Nr. of MPPT Trackers | 1 | |||
Max PV Array Power | 6200W | 6500W | ||
Open Circuit Voltage | 500Vdc | |||
MPPT Voltage Range | 90-450Vdc | |||
MAINS/GENERATOR INPUT | ||||
Input Voltage Range | 90~280Vac or 170~280Vac | |||
Frequency Range | 50/60Hz | |||
EFFICIENCY | ||||
Max Inverter Efficiency | 98% | |||
GENERAL | ||||
Dimension | 405X286X98mm | 423X290X100mm | ||
Net Weight | 10.5KG | 11KG | ||
Protection Degree | IP20, Indoor Use Only | |||
Operating Temperature Range | -10-55℃ | |||
Noise | ≤60dB | |||
Cooling Method | Fan Cooling | |||
Warranty | 12 Months | |||
COMMUNICATION | ||||
Embedded Interface | RS485/RS232 | |||
External Module(Optional) | Wifi | |||
CERTIFICATION | ||||
Safety | IEC62109-1, IEC62109-2 | |||
EMC | EN61000 | |||
