Order Code | Voltage (V) | Peak Wavelength (nm) | Radiant Power (mW) | Radiant Intensity (mw/sr) | Current (mA) | Half Width (nm) | Angle (0) |
HYQ35E35S810AB-X1 | 2.8-3.2 | 810-820 | 1100-1400 | 611 | 700 | 32 | 60 |
HYQ35E35N850AB-X1 | 1.4-1.8 | 840-860 | 1000-1300 | 561 | 1000 | 35 | 60 |
HYQ35E61N850AB-X1 | 1.3-1.7 | 840-860 | 500-600 | 278 | 700 | 35 | 60 |
HYQ35E42N850AB-X1 | 1.4-1.8 | 840-860 | 1100-1400 | 610 | 1200 | 35 | 60 |
HYQ35E43S850KN-X1 | 2.8-3.2 | 840-860 | 2000-2400 | 1052 | 1500 | 35 | 60 |
HYQ35G42N910AB-X1 | 1.2-1.6 | 900-920 | 1300-1600 | 721 | 1000 | 39 | 60 |
HYQ35E42N940AB-X1 | 1.2-1.6 | 930-950 | 1100-1400 | 611 | 1200 | 45 | 60 |
HYQ35E43S940KN-X1 | 2.8-3.2 | 930-950 | 2000-2500 | 1097 | 1500 | 45 | 60 |
HYQ35L32N940AB-X1 | 1.3-1.7 | 930-950 | 800-1000 | 452 | 1000 | 45 | 60 |
Warm Tip:The above parameters are for reference. Wavelength Angle, PCB can be customized Eccording to requirements
Applications
Our products are widely used in various applications such as medical, life science, industrial Equipment, non-destructive testing, and analytical equipment.
Substance / Matter Analysis//Hyperspectral Imaging
Machine Vision //Sorting Units (by raw material, by colour, etc.)
Detection of Foreign Matter//Blood Oxygen Saturation Analysis
Endoscopic Procedures//Photo Dynamic Therapy
Instrument Diagnostics and Research Execution//Spectroscopy
