Инверторы синусоидальной волны 3000 Вт 12 В 24 48 110 220

Сохранить в закладки 1601261570378:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description




Product Paramenters




Model
AEP-3K-12V
AEP-3K-24V
AEP-3K-48V
Output Power
3000W
Peak Power
6000W
Input Voltage(Range)
DC12V(9-15.5V)
DC24V(18-31V)
DC48V(38-61V)
Output Voltage(Optional)
(100VAC/110VAC/120VAC/220VAC/230VAC/240VAC)±5%
No-load Current
≤0.9A
≤0.4A
≤0.2A
Output Frequency(Optional)
50Hz/60Hz
Output Waveform
Pure Sine Wave
THD
≤3% Resistive Load
USB
18W Fast Charging
/
Max. Output Efficiency
88%
90%
92%
Undervoltage Protection
Alarm first (alarm sound once), LED red light flashes, voltage continues to decrease and shuts down
Overvoltage Protection
Alarm (alarm sounds twice) LED red light flashes and turns off
Overload Protection
Continuous alarm, LED flashes red, and turns off
Over Temperature Protection
First alarm (three alarm sounds), the temperature continues to rise and the LED red light flashes and turns off
Short Circuit Protection
There is short circuit protection to protect the circuit
Reverse Connection Protection
Fuse
Undervoltage Alarm Range
10.5±0.5V
21±0.5V
42±1V
Undervoltage Protection Range
9.5±0.5V
19±0.5V
38±1V
Overvoltage Protection Range
15.5±0.5V
31±0.5V
61±1V
Undervoltage Recovery Range
13±0.5V
24±0.5V
48±1V
Overvoltage Recovery Range
14.5V±0.5V
29V±0.5V
58V±1V
Working Temperature
-20℃ - +50℃
Product Dimensions(MM)
435*205*85
Installation Dimensions(MM)
405*130
NW/GW(KGS)
5.75/6.7
Carton Weight(KGS)
21.4
Warranty
2 Years
Cabling Configuration(MM²)
35
16
6
Cooling
Intelligent Air Cooling
