Forged Steel Flange
Henan Sheng He Pipe Industry Co., Ltd., have an experience spanning for over ten years, producing and supplying best-in-class products, minimize cost by getting manufacturing processes under one roof and delivering consignments on a daily basis only because of a diligent and dedicated team. We are manufacturers, suppliers and exporters of Forged Steel Flanges.




Product Description





Forged Steel Flange Type




Forged Flanges Specifications



Type
Forged Flange
Size
½” (15 NB) to 48″ (1200NB)
Class
150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
Dimensions
ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standard
ANSI B16.5, ANSI B16.47, ANSI B16.36, ANSI B16.48, BS 4504, EN1092, UNI 2277/2278, DIN, JIS, SABS1123, GOST-12820
BS
BS4504 , BS4504, BS1560, BS10
DIN
DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633,
DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
Coating / Surface Treatment
Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized
In Form
SORF, WNRF, BLRF, SWRF, LAP Joint, Threaded, Reducing, Spectacle, etc
Flange Face Type
Flat Face (FF), Raise Face (RF), Ring Joint (RJT)
Connection Type
Ring Type Joint, Lap-Joint Face, Raised Face, Flat Face, Large Male-Female, Small Male-Female, Large Tongue & Groove, Small Tongue
& Groove
Usage
Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects etc.
Packing
No Fumigate or Fumigate Plywood/Wood Pallet or Case


What are Forged Flanges?
Forged Flanges are a type of flange that is commonly used in high-pressure piping systems. These flanges are designed to be welded or bolted onto the end of a pipe and are typically made from forged steel. They are available in various sizes, pressure ratings & materials and connect pipes, valves, and other equipment in a piping system.


What are the advantages of using Forged Flanges?
Forged Flanges have several advantages, including high durability, resistance to corrosion and erosion, excellent performance under high-pressure and high-temperature environments, ease of installation and maintenance & availability in various sizes and materials to meet specific application requirements.


How are Forged Flanges installed in piping systems?
Forged Flanges are typically installed by bolting them to the piping system using bolts, nuts & gaskets. The flanges are aligned, and the bolts are tightened to create a secure, leak-proof joint. The installation process may vary depending on the specific type of flange and piping system being used. It is important to follow proper installation procedures to ensure the flanges are properly aligned and tightened for optimal performance.


Forged Flanges Manufacturing Standards


ASME Standard
ANSI B16.5, ANSI B16.47, ANSI B16.36, ANSI B16.48, BS 4504, UNI 2277/2278,, JIS, SABS1123, GOST-12820
DIN Standard
DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633,
DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
EN Standard
EN1092
ASTM A182 – ASME SA182
Standard Specification for Wrought Austenitic SS Pipe Flanges
MSS SP-44
Forged Flange


Forged Flanges Dimensions Tolerance


Outside Diameter:
≤ 24 = 1.6 mm | > 24 = ± 3.2 mm
Inside Diameter:
not applicable
Diameter of Contact Face:
1.6 mm Raised Face = ± 0.8 mm6.35 mm Raised Face, Tongue & Groove / Male-Female = ± 0.4 mm
Outside Diameter of Hub:
≤ 12 = + 2.4 mm / – 1.6 mm | ≥ 14 = ± 3.2 mm
Diameter of Counterbore:
not applicable
Drilling:
Bolt Circle = 1.6 mm | Bolt Hole Spacing = ± 0.8 mmEccentricity of Bolt Circle with Respect to Facing≤ 2½ = 0.8 mm max. | ≥ 3 =
1.6 mm max.
Thickness:
≤ 18 = + 3.2 mm / – 0 | ≥ 20 = + 4.8 mm / – 0
Length thru Hub:
≤ 18 = + 3.2 mm / – 0.8 mm | ≥ 20 = + 4.8 mm / – 1.6 mm


Forged Flanges Materials and Grades



Nickel Alloy Steel
ASTM/ASME B/SB 564 UNS N02200(NICKEL 200), UNS N04400, (MONEL 400),
UNS N08825( INCOLOY 825), UNS N06600(INCONEL 600), UNS N06601(INCONEL 601),
UNS N06625(INCONEL 625), UNS N10276(HASTELLOY C276)
ASTM/ASME B/SB160 UNS N02201(NICKEL 201), ASTM B/SB472 UNS N08020(Alloy 20)
Stainless Steel
ASTM/ASME A/SA 182 F304, 304L, 304H, 310H, 316, 316H, 316L,
316Ti, 317, 317L, 321, 321H, 347, 347H, 904L
Duplex and
Super Duplex
ASTM/ASME A/SA 182 F44, F45, F51, F53, F55, F60, F61,
S31803, S32205, S32550, S31254, SMO254, S32750, S32760, S32950
Carbon Steel
ASTM/ASME A/SA 105(N)
Low Temp Carbon Steel
ASTM/ASME A/SA350 LF2
High Yield Carbon Steel
ASTM/ASME A/SA694 F52, F56, F60, F65, F70
Alloy Steel
ASTM/ASME A/SA182 GR F5, F9, F11, F12, F22, F91




Company Profile




Henan Shenghe Pipe Industry Co., Ltd., have an experience spanning for over ten years, producing and supplying best-in-class products, minimize cost by getting manufacturing processes under one roof and delivering consignments on a daily basis only because of a diligent and dedicated team. We are manufacturers, suppliers and exporters of 30°, 45°, 90°, 180° Butt Weld Elbows.

Shenghe Provide Wide Piping Product Varieties from standard configurations to specialized products, we offer a diverse range of sizes, materials, and designs to ensure that our customers have ample options to choose from.

We employ high-quality materials and advanced manufacturing techniques to ensure that our products meet and exceed industry standards, including but not limited to ASTM, EN, DIN, JIS, BS/BSP, ASME, AISI, ACME, etc.

We takes great pride in maintaining a large stock of pipe fittings, branch connections, flanges, fasteners, steel pipe tubes, and bars. Our extensive inventory allows us to meet the diverse needs of our customers promptly and efficiently. Whether you require standard sizes or customized solutions, we have a wide range of products available for immediate sale.


Qualification Certificate




Customer Visit






Test high-quality products










Packing and Delivery
Fast and Safe










FAQ
1. who are we?
We are based in Henan, China, start from 2013,sell to Southeast Asia, Europe and America, the Middle East, Africa, etc. There are about 30 people in our office and factory in total.

2. how can we guarantee quality?
Always a pre-production sample before mass production;Always final Inspection before shipment;

3.what can you buy from us?
Flange, Pipe Fittings, Pipe,Tube, Round Bar, Bolt Nut and Sheet

4. why should you buy from us not from other suppliers?
The company has strong technical force, complete production equipment and perfect testing means.It is mainly engaged in processing and manufacturing pipe fittings, flange, pipe, bars, sheet plate of piping product filed.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English, Chinese,Spanish, Japanese, Portuguese, German, Arabic, French,Russian,Korean,Hindi,Italian。
