Машина для перекачки бетона 100 м3/ч SY5143THBE-10023C-10S гидравлический насос с износостойким обслуживанием деталей
6 433 795,00 ₽ - 6 655 650,00 ₽
Большой китайский завод 30 м 38 52 58 62 70
- Категория: >>>
- Поставщик: Qingdao Jiuhe Heavy Industry Machinery Co. Ltd.
Сохранить в закладки 1601265405644:
Описание и отзывы
Характеристики
Factory Overviews
JIUHE CONCRETE PUMP TRUCK Jib structure system
Jib structure system is based on the finite element analysis, dynamic analysis and test, and the accurate data support. Material adopt high strength Alloy Steel Plate, all materials and welding line by 100% non-destructive technology ensure the jib structure reasonable and highly reliable. "M" type arms withspeed stepless adjustment, pressure compensation and load sensing proportion control system ensure the arm running freely and excellent operating performance.
Products Description
Professional manufacturer 30m 38m 52m 58m 62m concrete pump truck truck mounted concrete pumps concrete truck boom pump for sale
Chassis | ||
Chassis | SINOTRUK HOWO 6x4 | |
Engine model | MC07H.35-60 | |
Engine power | 350HP | |
Wheelbase | 4400+1400 | |
Tire | 315/80R22.5 | |
Emission standards | Euro-II | |
Cab | Left/Right cab | |
Boom system | ||
Maximum vertical height of boom (M) | 38 | |
Horizontal distribution radius of boom (M) | 34 | |
Boom arm number | 5 sections | |
Depth of distribution (M) | 25.7 | |
Rotating angle of each arm | 90°/180°/180°/235°/235° | |
First arm length(MM) | 7800 | |
Second arm length(MM) | 6500 | |
Third arm length(MM) | 6250 | |
Forth arm length(MM) | 6700 | |
Fifth arm length(MM) | 6700 | |
Electric Control System | ||
Working voltage: | 24 | |
Power Supply | 24 | |
Hydraulic transmission system | ||
Type of hydraulic system | Open type | |
System working pressure (Mpa) | 31.5 | |
Hydraulic fuel tank capacity (l) | 420 | |
Cooling mode of hydraulic oil | Forced-air Cooling | |
DIMENSIONS&WEIGHT | ||
Total length (MM) | 10695 | |
Total width (MM) | 2550 | |
Total height (MM) | 3990 | |
Total weight (T) | 27.7 | |
Pumping system | ||
Max.Theoretical Output | 100 | |
Form of concrete distribution valve | S valve | |
Dimension of allowable maximum aggregate (MM) | 40 | |
Lubricating method | Centralized lubrication | |
Product Applications
Recommend Products
Company Profile
Qingdao Jiuhe Heavy Industry Machinery Co., Ltd
JIUHE is specialized in researching, manufacturing, and selling concrete machines such as concrete mixing machine, concrete pumping machine, concrete placing machine and other Heavy Industry machinery. We are New High-Tech Enterprise with more than 20 Patents. Choose us, you can absolutely feel free on after-sale service. Customer Satisfaction is our pursuit, Long-term cooperation is our goal, Mutual benefit and win-win result is our principle. Any products interest you, Kindly contact us, Quality machine together with Warm and attentive service are waiting for you!
Main Products
Product packaging
FAQ
Q: OEM OR ODM IS AVAILABLE?
A: Yes, we can produce with your logo.
Q: HOW IS YOUR DELIVERY TIME?
A: If standard machine, the delivery time will be 7-15 days, if customized version, that depends on the customized configuration time.
Q: WHICH PAYMENT TERMS CAN YOU ACCEPT?
A: Normally we can work on TT or LC.
(1)T/T: 30% prepayment to start production and 70% balance shall be paid before shipment;
(2)L/C: 100% irrevocable LC at sight without "soft clauses" from an international recognized bank can be accepted.
Q: WHICH INCOTERMS 2010 TERMS CAN YOU DO?
A: As per client's requirement, we can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as FOB.CFR.CIF.CIP.DAP.
Q: WHAT LOGISTICS WAYS YOU CAN WORK FOR SHIPMENT?
A: We can ship machinery by various transportation ways:
(1)Mostly, the machine will go by sea such as container ship (include special container flat rack) or Ro-Ro / Bulk ship;
(2)For inland neighborhood countries of China can send by road or railway;
(3)For the spare parts in urgent requirement we can send it by international courier service such as DHL. FEDEX, TNT Or UPS.
A: Yes, we can produce with your logo.
Q: HOW IS YOUR DELIVERY TIME?
A: If standard machine, the delivery time will be 7-15 days, if customized version, that depends on the customized configuration time.
Q: WHICH PAYMENT TERMS CAN YOU ACCEPT?
A: Normally we can work on TT or LC.
(1)T/T: 30% prepayment to start production and 70% balance shall be paid before shipment;
(2)L/C: 100% irrevocable LC at sight without "soft clauses" from an international recognized bank can be accepted.
Q: WHICH INCOTERMS 2010 TERMS CAN YOU DO?
A: As per client's requirement, we can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as FOB.CFR.CIF.CIP.DAP.
Q: WHAT LOGISTICS WAYS YOU CAN WORK FOR SHIPMENT?
A: We can ship machinery by various transportation ways:
(1)Mostly, the machine will go by sea such as container ship (include special container flat rack) or Ro-Ro / Bulk ship;
(2)For inland neighborhood countries of China can send by road or railway;
(3)For the spare parts in urgent requirement we can send it by international courier service such as DHL. FEDEX, TNT Or UPS.
