Soloport бренд SP40/5 1AW солнечная панель системы автомобильного порта включает настенные солнечные панели и шкаф управления
- Категория: >>>
- Поставщик: Soloport GmbH
Сохранить в закладки 1601268372109:
Описание и отзывы
Характеристики
Specification
Custom Description | The roof of the carport consists of 12 high-performance solar modules. With a power generation of 420 Wp per module, they ensure a maximum power generation capacity of 5 kWp. The electricity generated by the solar modules is transferred to the control cabinet included in the scope of delivery, which also contains a 40 kWh high-performance battery storage unit. The maximum usable capacity is 30 kWh, as an internal mechanism is integrated to protect the battery from deep discharge. The solar carport allows you to charge your electric car easily both during the day and at night or in unfavourable weather conditions. All technical components are also integrated in the control cabinet, including an inverter and a fuse box. These elements are responsible for controlling and networking the carport and ensure virtually maintenance-free operation. |
Product Description
Company Profile
FAQ
Q1: How quick will I get a quote?
A1: We usually quote within 24 hours after we get your inquiry.
Q2 : Do you offer worldwide shipping and how much will it cost?
A2: Yes, we offer worldwide shipping. Due to the dimensions and weight, the shipping costs vary. Our sales team will be happy to provide you with a non-binding offer. If you are able to collect from one of our warehouses yourself, we will offer you a discount.
Q3 : Can the solar carport be used with all kinds of electric vehicles?
A3: Absolutely, the SoloPort solar carport is designed to be compatible with all common electric vehicles equipped with lithium-ion batteries, and it is adaptable for use with any brand or model.
Q4 : Do the carports come in adjustable sizes or are they fixed?
A4: The carports we provide come in standard sizes that are not subject to modification. The measurements provided in the technical specifications are final and cannot be altered. Additionally, the options for frame materials are limited to those currently displayed.
Q5 : What are the space requirements for installing the carport?
A5: To set up the SoloPort solar carport, you'll need a flat space measuring at least 4 by 7.5 meters (157.5 by 295.3 inches), with the carport itself having dimensions of 3.9 meters in width (153.5 inches) and 7.1 meters in length (279.5 inches). For the structure to remain firm and secure, it should be constructed on a robust surface such as asphalt, stone, or concrete.
Q6 : What is the energy output capability of the solar carport?
A6: The SoloPort solar carport is equipped with twelve high-efficiency solar panels, each capable of producing 420 Watts peak (Wp), enabling the system to reach a peak power generation capacity of 5 kilowatts (kW).
Q7: Is it possible to use the solar carport during adverse weather conditions or nighttime?
A7: Absolutely, the solar carport is designed for use in various conditions including bad weather and at night. It incorporates a battery storage system that accumulates energy during daylight hours. This stored energy can be utilized to charge an electric vehicle even when solar energy production is not possible, such as during the night or on overcast days. However, it is important to note that the efficiency of solar panels can decrease during poor weather conditions or in the winter season, potentially impacting the duration required to charge the vehicle.
Q8: What are the load capacities (roof load, snow load, wind load) of the carport?
A8: The carport has a roof/snow load capacity of 540 kg/m², which is equivalent to approximately 110.23 pounds per square foot. This capacity applies whether it is a carport for cars or motor homes. Add-on bays can bear the same loads. The wind load capacity is 108 km/h, which converts to about 67.11 miles per hour. Therefore, the carport is also built to withstand adverse weather conditions.
Q9: What type of batteries are installed and how many charging cycles do they support?
A9: The installed batteries are lead-gel type with a capacity of 250 Ah. They support a minimum of 800 to 1000 charging cycles. It should be noted that the actual number of charging cycles may vary based on several factors, meaning it could be higher or lower than the stated range.
A1: We usually quote within 24 hours after we get your inquiry.
Q2 : Do you offer worldwide shipping and how much will it cost?
A2: Yes, we offer worldwide shipping. Due to the dimensions and weight, the shipping costs vary. Our sales team will be happy to provide you with a non-binding offer. If you are able to collect from one of our warehouses yourself, we will offer you a discount.
Q3 : Can the solar carport be used with all kinds of electric vehicles?
A3: Absolutely, the SoloPort solar carport is designed to be compatible with all common electric vehicles equipped with lithium-ion batteries, and it is adaptable for use with any brand or model.
Q4 : Do the carports come in adjustable sizes or are they fixed?
A4: The carports we provide come in standard sizes that are not subject to modification. The measurements provided in the technical specifications are final and cannot be altered. Additionally, the options for frame materials are limited to those currently displayed.
Q5 : What are the space requirements for installing the carport?
A5: To set up the SoloPort solar carport, you'll need a flat space measuring at least 4 by 7.5 meters (157.5 by 295.3 inches), with the carport itself having dimensions of 3.9 meters in width (153.5 inches) and 7.1 meters in length (279.5 inches). For the structure to remain firm and secure, it should be constructed on a robust surface such as asphalt, stone, or concrete.
Q6 : What is the energy output capability of the solar carport?
A6: The SoloPort solar carport is equipped with twelve high-efficiency solar panels, each capable of producing 420 Watts peak (Wp), enabling the system to reach a peak power generation capacity of 5 kilowatts (kW).
Q7: Is it possible to use the solar carport during adverse weather conditions or nighttime?
A7: Absolutely, the solar carport is designed for use in various conditions including bad weather and at night. It incorporates a battery storage system that accumulates energy during daylight hours. This stored energy can be utilized to charge an electric vehicle even when solar energy production is not possible, such as during the night or on overcast days. However, it is important to note that the efficiency of solar panels can decrease during poor weather conditions or in the winter season, potentially impacting the duration required to charge the vehicle.
Q8: What are the load capacities (roof load, snow load, wind load) of the carport?
A8: The carport has a roof/snow load capacity of 540 kg/m², which is equivalent to approximately 110.23 pounds per square foot. This capacity applies whether it is a carport for cars or motor homes. Add-on bays can bear the same loads. The wind load capacity is 108 km/h, which converts to about 67.11 miles per hour. Therefore, the carport is also built to withstand adverse weather conditions.
Q9: What type of batteries are installed and how many charging cycles do they support?
A9: The installed batteries are lead-gel type with a capacity of 250 Ah. They support a minimum of 800 to 1000 charging cycles. It should be noted that the actual number of charging cycles may vary based on several factors, meaning it could be higher or lower than the stated range.
