Product Description
XR280DII drilling machine rotary drilling rig
1, Hydraulic pilot control, provide comfortable operating performance and flexible regulation, first-class brand of hydraulic components to ensure the reliability of the machine hydraulic system.
2, Carriage and clamp using double floating patented technology can greatly protect the drill pipe thread, increase the service life of the drill pipe.
3, High-speed sliding systems, piston motor to achieve high and low sliding speed of carriage, increasing the ability to adapt the machine working conditions, promote construction efficiency.
4, Optional full-automatic pipe loader, drilling box can accommodate 40 piece of drill pipes(φ73), ensure one time reached 120 meters, efficient automation construction, reduce construction costs and labor intensity.
5, Support the diverse needs of customers, the machine can option configuration with the automatic (semi automatic) full-automatic pipe loader, automatic anchoring system, cab, air conditioning wind, cold start, freezing mud, mud washing, mud throttling and other devices.
2, Carriage and clamp using double floating patented technology can greatly protect the drill pipe thread, increase the service life of the drill pipe.
3, High-speed sliding systems, piston motor to achieve high and low sliding speed of carriage, increasing the ability to adapt the machine working conditions, promote construction efficiency.
4, Optional full-automatic pipe loader, drilling box can accommodate 40 piece of drill pipes(φ73), ensure one time reached 120 meters, efficient automation construction, reduce construction costs and labor intensity.
5, Support the diverse needs of customers, the machine can option configuration with the automatic (semi automatic) full-automatic pipe loader, automatic anchoring system, cab, air conditioning wind, cold start, freezing mud, mud washing, mud throttling and other devices.
Description | Unit | Parameter value | ||
Max. drilling diameter | mm | 2200 | ||
Max. drilling depth | m | 88 | ||
Allowable luffing scope (from center of drill rod to slewing center) | mm | 4410~4950 | ||
Drilling rig dimension in working condition (L × W × H) | mm | 10770×4800×23550 | ||
Drilling rig dimension in transport condition (L × W × H) | mm | 17410×3500×3815 | ||
Weight of overall unit (standard configuration, excluding drilling tool) | t | 96 | ||
Engine | Model | CUMMINS QSM11-C400 | ||
Rated power/speed | kW | 298/(2100r/min) | ||
Hydraulic system | Max. working pressure of main pump | Mpa | 35 | |
Max. working pressure of auxiliary pump | Mpa | 30 | ||
Rotary drive | Max. torque | kN •m | 280 | |
Rotational speed | r/min | 6~22 | ||
Crowd cylinder | Max. Pushing force | kN | 300 | |
Max. Pulling force | kN | 300 | ||
Max.stroke | mm | 16000 | ||
Main winch | Max.pulling force | kN | 260 | |
Max. single-rope speed | m/min | 60 | ||
Auxiliary winch | Max.pulling force | kN | 80 | |
Max. single-rope speed | m/min | 65 | ||
Drilling mast | Left/right inclination of mast | ° | ||
Front/back inclination of mast | ° | |||
Rotary table slewing angle | ° | 360 | ||
Traveling | Max. traveling speed of the overall unit | km/h | 1.5 | |
Max. climbable gradient of the overall unit | % | 35 | ||
Crawler | Width of crawler plate | mm | 800 | |
External width of crawler (min.-max.) | mm | 3500~4800 | ||
Center distance between two longitudinal wheels of crawler | mm | 5175 | ||
Details Images
