Product Description


The selection of filter materials should be considered based on the temperature, humidity, and chemical characteristics of the gas, particle size, weight, shape, heaviness, dust concentration, filtration speed, ash removal method, emission concentration, and the working system of the bag filter.
The filter bag is a key component that determines the dust removal efficiency and working temperature of the bag filter, and the cost of replacing the filter bag is the main maintenance cost of the bag filter. Therefore, the service life of the filter bag is related to the operating status and cost of the dust collector, so it is particularly important to choose suitable filter materials and design a reasonable structure.


Specification


Applicable Industries
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Construction works , Energy &
Mining, Steel Plant, Flour Factory, Cement Plant, Industry Plant, Chemical Factory
Application
Industry Dust Collector
Feature
High Efficiency
Production Capacity
100000 Piece/ Per Month
Requirement
1.8mm
Advantage
Eco-friendly




1.Polyester Needle-Punched Filter Bag
The bag has the advantages of high void, good air permeability, high dust collecting efficiency and long service life, which are
peculiar to common felt filter bags. It has modefdate high temperature resistance, and can reach 130"C in an instant. It also has
moderate acid and alkali resistance. and very good wear resistance.
Weight: 500g/ m²
Material: Polyester/Polyester Filament Substrate Thickness: 1.75mm
Permeability: 16 m³/ m²· min
Radial control force:> 1100N/5'20cm Latitudinal control force:> 1400N/5.20cm Radial control force: <25%
Latitudinal control force: <45%
Usage temperature:.; 130"C
Post-treatment: singeing, calendering, heat selling


2. Polyester Antistatic Needle-punched Filter Bag
In the process of producing needle-punched felt, conductive fibers or conductive materials are mixed into chemical fibers. It is
used in industries where flour dust. chemical dust and coal dust may explode in case of electrostatic discharge.
Weight: 500g/ m²
Material: Polyester/Polyester/Polyester Antistatic Substrate Thickness: 1.8mm
Permeability: 15 m³/ m²· min
Radial control force: > 800N/5 x 20cm
Latitudinal control force: > 1200N/5 x 20cm
Radial control force: <35%
Latitudinal control force: <55%
Usage temperature:≤130°C
Post-treatment: singeing, calendering, or Teflon coating

3.Water-repellent and Oil-expellant Polyester Needle-punched Filter Bag
The filter cloth is rolled and impregnated with PTFE (waterproof agent), which is used in occasions with high moisture content.
The filter material is not easy to block the paste bag, the service life of the cloth bag is prolonged, the gas flow rate is
increased, and the maintenance cost is greatly save.
Weight: 500g/m'
Material: Polyester/Polyester Antistatic Substrate Thickness: 1.8mm
Permeability: 15m³/m²· min
Radial control force: > 800N/5 x 20cm
Latitudinal control force: > 1200N/5 x 20cm Radial control force: <35%
Latitudinal control force: <55%
Usage temperature: ≤ 130°C
Post processing: Raw materials with good alkali resistance, wear resistance, and corrosion resistance, such as singeing, calendering, or Teflon coating




4. Polypropylene Needle-punched Filter Bag
With excellent acid and alkali resistance, low softening point, it can be used in flue gas temperature below 100"C and high
acidity and alkalinity occasions or in the field of liquid-solid separation with high acidity and alkalinity.
Weight: 500g/ m²
Material: Acrylic polyester /polypropylene yarn Thickness: 2.1 mm
Permeability: 12.6 m³/ m²· min
Radial control force: > 980N/5 x 20cm Latitudinal control force > 1060N/5 x 20cm Radial control force: <35%
Latitudinal control force: <55%
Usage temperature: ≤88°C
post-treatment: singeing or calendering

5. Fiberglass Needle-Punched Filter Bag
It has the advantages of high temperature resistance, corrosion resistance, dimensional stability, minimal elongation and

shrinkage, high strength. And the tapetum fiber bears single fiber, three-dimensional micro-porous structure, high porosity and
low resistance to gas filtration. It is a kind of high-speed and high­efficiency high-temperature filtering material. It is widely
used in high temperature flue gas filtration of industrial kilns such as chemical industry, iron and steel, smelting, carbon
black, power generation, cement, etc.
Weight: 800g/ m²
Material: Fiberglass
Thickness: 1.8mm
Permeability: 10 m³/ m²· min
Radial control force: > 1 SOON/5 x 20cm Latitudinal control force: > 1 SOON/5 x 20cm Radial control force: < 10%
Latitudinal control force: <10%
Usage temperature: ≤ 280°C
Post-treatment: Teflon treatment

6. Acrylic Medium Temperature Needle-punched Filter Bag
Using non-woven needle-punching technology, the surface of fine fiber cloth with interlaced strong fibers and uniform void
distribution is smoothed by hot rolling and singeing treatment, which is not easy to be blocked by dust. The filter material has
large void, good permeability and strong chemical stability. It can not only filter atmospheric temperature gas, but also medium
temperature gas. It is the ideal choice of filter materials under acid-alkali corrosive gas condition.
Weight: 500g/m²
Material: Acrylic/Acrylic Substrate Thickness: 1.9mm
Permeability: 14m³/ m²· min
Radial control force: > BOON/5 x 20cm Latitudinal control force: > 1300N/5 x 20cm Radial control force: <25%
Latitudinal control force: <45%
Usage temperature: ≤ 130°C
Post-treatment singeing, catendering




7.Metas Needle-punched Filtration Filter Bag at High Temperature
Metas is the generic name of Nomex produced by Dupont Company in the United States and Conex produced by Emperor Company in Japan.
It is widely used in various high temperature flue gas filtration occasions, with excellent and reliable performance, and widely
used in steel, electric power, asphalt mixing industry. The product adopts the optimized process, which improves the physical and
chemical properties of the product and make the application more secure.
Weight: 500g/ m²
Material: Metas / Metas Subslrate
Thickness: 2.2mm
Permeability: 17 m³/ m²· min
Radial control force: > BOON/5 x 20cm
Latitudinal control force: > 1200N/5 x 20cm
Radial control force: <35%
Latitudinal control force: <55%
Usage temperature: ≤ 204°C
Post-treatment: singeing, calendering or Teflon coating


8. High-temperature PPS Needle-punched Filter Bag
PSS fibers have complete strength retention and inherent chemical resistance, which can maintain good filtration performance in
harsh environments and achieve ideal service life It is used to filter coal-fired boilers, garbage incinerators, dust collecting
treatment of fly ash in power plants and pulse cleaning dust collectors.
Weight 500g/ m²
Material PSS Filament Substrate
Thickness 1 8mm
Permeability 15 m³/ m²· min
Radial control force > 1200N/5 x 20cm
Latitudinal control force > 1300N/S x 20cm
Radial control force <30%
Latitudinal control force. <30%
Usage temperature ≤ 190°C
Post-treatment high temperature hot pressing and singeing

9. Flumex (FMS) High Temperature Resistant Needle-punchedFilter Bag
Compared with fiberglass cloth bags, its wear resistance, flexural resistance and peeling strength are obviously improved. The
filtration speed can reach more than 1.0m/min and the running resistance is low. It is widely used in steel, non-ferrous smelting,
chemical industry, carbon black, building materials, electric power and other industries.
Weight: 800g/ m²
Material: Aramid. fiberglass/ fiberglass substrate Thickness: 2.5mm
Permeability: 10 m³/ m²· min
Radial control force: > 2000N/5 x 20cm Latitudinal control force: > 2000N/5 x 20cm Radial control force: < I 0%
Latitudinal control force: < 10%
Usage temperature: ≤ 260°C
Post-treatment: PTEF treatment, calendering




10. P84 High Temperature Resistant Needle-punched Filter Bag
It has remarkable temperature resistance and good chemical resistance It has certain advantages in filtration of acid waste gas
and alkaline dust It has low backwash pressure and high sludge cake efficiency It is used in asphalt plants. cement plants, waste
incinerators. liquid bed boilers and coal-fired boilers.
Weight 500g/ m²
Material P84/P84 substrate
Thickness 2 3mm
Permeability 15 m³/ m²· min
Radial control force > 700N/5 x 20cm
Latitudinal control force > 1300N/5 x 20cm
Radial control force <35%
Latitudinal control force <55%
Usage temperatures≤ 260°C
Post-treatment high temperature hot pressing and singeing

11.Three-proof Polyester Needle-punched Filter Bag (waterproof, antistatic, oil-proof)
In the process of producing needle-punched felt, conductive fibers or conductive materials are mixed into chemical fibers. The
filter cloth is rolled and impregnated with PTFE (waterproof agent), which is used in occasions with high moisture content. The
filter material is not easy to block the paste bag, the service life of the cloth bag is prolonged, the gas flow rate is
increased, and the maintenance cost is greatly saved
Weight: 500g/ m²
Material: Polyester/Polyester Antistatic Substrate Thickness: 1.8mm
Permeability: 11 m³/ m²· min
Radial control force: > 1100N/5 x 20cm
Latitudinal control force: > 1300N/5 x 20cm
Radial control force: <35%
Latitudinal control force: <45%
Usage temperature: ≤ 130°C
Post-treatment: singeing, calendering or Teflon coating



Packing & Delivery




FAQ


Q1. Are you manufacturer or trade company ?
We are professional manufacturer in China , and have in this line almost 10 years .
Q2. Would it be possible for us to visit your factory ?
Sure, welcome you at any time !
Q3 . Will your company supply samples ?
Yes ,we do .
Q4. How can we get the quotation ?
Please let us know the specifications , such as the material ,micron ,apply in which industry etc .
Q5.what's the lead time ?
Usually is 5-15 days after we received your payment .
Q6 . what is the packaging ?
Inner packing -poly bags .Outer packing -Export cartons .
Q7. Can I get your products with our logo and design ?
Yes ,you can . Most of our products can be customized according to your requirements .
Q8. Which payment terms are you accept ?
T/T , L/C .Western Union , Money gram are available for us . we accept 30% T/T in advance , the balance should be paid before
shipping
