Новый SmartAX MA5616 PDIA H831PDIA 03020CKS блок питания постоянного

Новый SmartAX MA5616 PDIA H831PDIA 03020CKS блок питания постоянного

Категория: >>>
Поставщик: Wentop Tech Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Whatsapp: +86 135 9042 0625
Email: sales@wentoptel.com
Skype: xiang_ds

Product Description

The SmartAX MA5616 (the MA5616 for short) is an industry-leading remote multi dwelling unit (MDU) launched by Huawei, which supports flexible configurations and provides broadband services on Fiber To The Building (FTTB) and Fiber To The Curb (FTTC) networks.

The MA5616 is a box-type device measuring 2-U high and 19-inch wide and providing two GPON or GE uplink ports and ADSL2+, VDSL2, SHDSL, POTS, ISDN, FE and GE ports. The MA5616 features a high access density, high processing capability, high reliability, easy maintenance, environment-friendlily and energy conservation, and future-oriented architecture design and can be used in corridors, cabinets, indoor, and outdoor usage scenarios.

Specification

Specification	CCUB control board	CCUC control board
Network-side port	The MA5616 supports the following configurations: •• 1GPON + 1GE •• 2*GE	The MA5616 supports the following configurations: •• 1GPON + 1GE •• 2*GE
User-side port	The MA5616 provides four slots and the following 10 service boards: • 24-channel VDSL2 board (17a, over POTS, built-in SPL) •24-channel VDSL2 board (17a, over POTS, external SPL) •24-channel VDSL2 board (17a, over ISDN, external SPL) •16-channel VDSL2 board (30a, over POTS, built-in SPL) • 32-channel ADSL2+ board (built-in SPL) • 32-channel combo board (32 × POTS + 32 × ADSL2+) • 64-channel POTS board • 32-channel POTS board • 8-channel ISDN board • 16-channel G.SHDSL board (supporting ATM and PTM)	The MA5616 provides four slots and the following 13 service boards: • 24-channel VDSL2 board (17a, over POTS, built-in SPL) •24-channel VDSL2 board (17a, over POTS, external SPL) • 24-channel VDSL2 board (17a, over ISDN, external SPL) • 16-channel VDSL2 board (30a, over POTS, built-in SPL) • 32-channel ADSL2+ board (built-in SPL) •• 32-channel combo board (32 × POTS + 32 × ADSL2+) • 64-channel POTS board • 32-channel POTS board • 8-channel ISDN board • 16-channel G.SHDSL board (supporting ATM and PTM) •16-channel FE (electrical) board • P2P board with 4 GE (combo of optical port and electrical port) + 4 FE (optical port) •48-channel VDSL2 board (17a, over POTS, external SPL, supporting MELT) Specifications
Power supply	AC: 220 V/110 V DC: -48 V	AC: 220 V/110 V DC: -48 V
Weight	4.8 kg (empty chassis) 7.2 kg (full configuration)	4.8 kg (empty chassis) 7.2 kg (full configuration)
