Product Name: Reversible Hammer Crusher

Capacity: 25-350t/h

Power: 90-560kw

Max. Material Size: 0-140mm

The reversible hammer crusher is named after the rotor can rotate in both directions. It is one of the crushing equipment for crushing limestone, coal, or other brittle materials below medium hardness in metallurgy, building materials, the chemical industry, hydropower, and other industrial fields.

Application of reversible hammer crusher

Main features of a reversible hammer crusher

1. Large crushing ratio: The crushing ratio of reversible hammer crusher can reach up to 20, which can effectively crush the material to the required particle size.

2. High production capacity: The equipment has efficient production capacity and can meet the needs of large-scale production.

3. Uniform product particle size: The material particle size after crushing by a reversible hammer crusher is uniform and meets production requirements.

4. Advanced structure: Reversible hammer crusher adopts advanced product structure, reliable performance, stable operation and low energy consumption.

5. Reversible crushing: The hammer head uses two sides, and the life span is increased by more than 1 times, which reduces the production cost.

6. Mechanical gap adjustment: It can compensate for the increase of particles caused by wear of wearing parts and maintain the stable operation of the equipment.

7. Impact plate heating system: It can be used to process wet and sticky materials so that drying and crushing can be carried out at the same time, which improves the adaptability of the equipment.

Composition of reversible hammer crusher

Reversible hammer crusher is mainly composed of frame, rotor, screen bar, impact plate, adjustment device, etc. The rotor is the core component of reversible hammer crusher. Its reversibility enables the hammer head to be used on both sides, which prolongs the service life of the hammer head.

The working principle of the reversible hammer crusher is mainly to crush materials by impact.

1. After entering the crusher, it is crushed by the impact of the high-speed rotating hammer.

2. The crushed material obtains kinetic energy from the hammer and rushes to the baffle and screen bar in the frame at high speed. At the same time, the materials collide with each other and are crushed multiple times.

3. The material smaller than the gap between the screen bars is discharged from the gap. Some larger materials are crushed again on the screen bar by the impact, grinding and extrusion of the hammer until the product of the required particle size is obtained.

Perfect after-sales service

Baichy Heavy Industry provides professional on-site guidance for installation, training of workers, and other services to ensure that customers can use the equipment smoothly.

The company has a complete after-sales service system, which can provide customers with timely technical support and equipment maintenance services to ensure the long-term stable operation of the equipment.

To prevent the rights and interests of customers from being infringed, Baichy Heavy Industry reminds customers: please contact our customer service staff through the official website of Baichy Heavy Industry , or add WhatsApp: 15093222637 ; or send an email to: , we will get in touch with you as soon as possible and provide you with the most professional service in the industry.

Henan Baichy Machinery Equipment Co., Ltd is a professional mining machinery manufacturer mainly engaged in producing stone crushers, powder grinding mills, mobile crushing plants, and mineral processing equipment. It covers a total area of 200,000 square meters, including a standardized workshop, modern office building, R&D center, and sales and aftersales center.

Our company has more than 100 middle and senior technicians. Over the years, based on professional technology, a complete scientific and quality management system(CE, ISO9001) , and high-quality products, Baichy Machinery has quickly grown into an important production and export base of China mining machinery. The products have been exported to over 150 countries and are widely used in the global mining and construction industry.

All our products are strictly manufactured according to ISO/CE standards, affordable, and of unmatched quality. We focus on product quality and will take responsibility for any defects. OEM/ODM services are available. We have rich experience in export and project management and can 100% ensure the safety of your order.

About Customer Visits

Baichy Machinery's equipment has been exported to more than 150 countries around the world. This global business layout requires Baichen Heavy Industry to frequently communicate and exchange with customers from all over the world; visiting customers may include potential customers, existing customers, and partners.

Baichy Machinery attaches great importance to customer visits and has formulated a complete reception process and standards for this purpose. The company has a professional reception team responsible for receiving visiting customers, arranging itineraries, and providing explanations and demonstrations.

1. Are you manufacture or trading company?

We are factory, established in 2003.

2. How long is your delivery time?

7-10 days for the stock, 15-30 days for the mass production.

3. What is your payment method?

30% deposit in T/T advance, 70% balance before shipment.

4. How long is the warranty? Does your company supply the spare parts?

One year. Spare parts for you at lowest cost.

5. If I need the complete crushing plant can you help us to build it?

Yes, we can help you set up a complete production line and give you related professional advice. We had already build many mining projects in China & Overseas.
