Product Description
Product Description:
1. Mirror stainless steel mouth, long-term use will not change color.
2. Imported double insulated ceramic liner, stable performance
3. Vacuum forming polycrystalline mullite fiber furnace, high efficiency insulation.
4. In the double shell, the air sleeve is insulated, and the double guiding air passage.
5.High-precision micro-computer controller and precision sensor are perfectly integrated, and the temperature is accurate.
SX4 model also has the following characteristics:
1.Import time control system and high precise sensor with sensitive, response, high precision and good stability.
2.Adding exhaust devices is beneficial to ashing
2. Imported double insulated ceramic liner, stable performance
3. Vacuum forming polycrystalline mullite fiber furnace, high efficiency insulation.
4. In the double shell, the air sleeve is insulated, and the double guiding air passage.
5.High-precision micro-computer controller and precision sensor are perfectly integrated, and the temperature is accurate.
SX4 model also has the following characteristics:
1.Import time control system and high precise sensor with sensitive, response, high precision and good stability.
2.Adding exhaust devices is beneficial to ashing
Specification
Model Number | SX3-2.5-12 | SX3-5-12 | SX3-8-12 | SX3-10-12 | |||||
SX3-2.5-12B | SX3-5-12B | SX3-8-12B | SX3-10-12B | ||||||
SX4-2-12 | SX4-7-12 | SX4-12-12 | SX4-16-12 | ||||||
SX4-2-12B | SX4-7-12B | SX4-12-12B | SX4-16-12B | ||||||
SX4-2-12P | SX4-7-12P | SX4-12-12P | SX4-16-12P | ||||||
SX4-2-12PB | SX4-7-12PB | SX4-12-12PB | SX4-16-12PB | ||||||
Heating mode | Alloy wire heating in three sides left; right; top side. | ||||||||
Function | Temp.Range | 100-1200℃ | |||||||
Temp.Resolution Ratio | 1℃ | ||||||||
Temp. motion | ±1℃ | ||||||||
Temp.Rising time to max temp | ≤30min | ||||||||
Structure | Chamber material | Ceramic fiber | |||||||
Structure | Outer shell | cold rolling steel electrostatic spraying exterior; B model: stainless steel | |||||||
Insulation layer | Ceramic fiber | ||||||||
Heater | Alloy heating wire | ||||||||
Power rating | 1.5kW | 3.0kW | 4.5kW | ||||||
Exhaust hole | φ30mm(chimney size 80*60mm) | ||||||||
Controller | Temp. control mode | SX3 Type : domestic Xianmen Yudian single-stage temperature controller；SX4 Type: Japaness SHIMAX single-stage temp. controller；SX4-P: Japaness Fuji color LCD 64- segment programmed temperature controller | |||||||
Temp. setting mode | Touch button setting | ||||||||
Temp. display mode | Measuring temperature: LED upper row, setting temperature: the lower row | ||||||||
Timer | SX3: 0-3200min, SX4: Without Timing Function,SX4-P:Timing Function, 99 hours and 59 minutes (With Timing Waiting Function) | ||||||||
Operation function | Fixed temperature operation, timing function, auto stop. | ||||||||
Additional function | Sensor deviation correction, Temperature overshoot self-tuning, Internal parameter locked, Power-off parameter memory | ||||||||
Sensor | SX3:Platinum-rhodium sensor；SX4:High precision K type sensor | ||||||||
Safety device | Manual door security lock, over temperature sound-light alarm, door opening electrical outage, over-temperature protection， thermocouple failure | ||||||||
Specification | Inner Chamber size (W*L*H)(mm) | 120*200*80 | 200*300*120 | 200*300*200 | |||||
Exterior size (W*L*H) (mm) | 450*685*600 | 530*785*640 | 530*785*720 | ||||||
Packing size (W*L*H)(mm) | 580*775*730 | 660*875*770 | 660*875*850 | ||||||
Volume | 2L | 7L | 12L | ||||||
Current rating (50/60HZ) | AC220V/6.6A | AC220V/13.6A | AC220V/20.4A | ||||||
NW/GW (kg） | 33/37 | 45/50 | 62/68 | ||||||
optional type | LCD program temperature control device with USD date storage | ||||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Prosperity Biotech (Shandong) Co., Ltd has always been a supplier of high-quality laboratory general-purpose small instruments and equipment in the industry. For many years, the company has used sophisticated technical solutions to improve product development and manufacturing.
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products, distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments. Used in different environments such as large, medium and small enterprises, scientific research institutions, etc. Among them, the BIOSTELLAR brand is well-known worldwide. As a global production base, Prosperity Biotech also provides ODM/OEM for famous companies in the industry.
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products, distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments. Used in different environments such as large, medium and small enterprises, scientific research institutions, etc. Among them, the BIOSTELLAR brand is well-known worldwide. As a global production base, Prosperity Biotech also provides ODM/OEM for famous companies in the industry.
FAQ
1. who are we?
We are based in Shandong, China, start from 2018,sell to Africa(35.00%),Eastern Asia(20.00%),South America(15.00%),Eastern Europe(15.00%),South Asia(5.00%),North America(5.00%),Mid East(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
OVEN,Incubator,Oxygen Generator,Spectrophotometer,Stirrer
4. why should you buy from us not from other suppliers?
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products, distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
We are based in Shandong, China, start from 2018,sell to Africa(35.00%),Eastern Asia(20.00%),South America(15.00%),Eastern Europe(15.00%),South Asia(5.00%),North America(5.00%),Mid East(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
OVEN,Incubator,Oxygen Generator,Spectrophotometer,Stirrer
4. why should you buy from us not from other suppliers?
In the past two decades, hundreds of products have been developed and produced, covering six categories of pipetting products, distillation products, heating and stirring products, temperature control products, centrifuges and other small instruments.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese
