S5731 S8UM16UN2Q (8*100 м/1/2.5/5/10 г порты 16*100 м/1/2 5 г) 02354VCD 10G сетевой коммутатор
- Категория: >>>
- Поставщик: Chongqing Yujia Technology Co. Ltd.
Сохранить в закладки 1601272270187:
Описание и отзывы
Характеристики
Product Description
CloudEngine S5731-S series switches are HW new-generation multi-rate access switches. They provide GE, 2.5GE, or 10GE electrical ports and fixed 10GE or 40GE optical ports for uplink.
CloudEngine S5731-S series switches are Hua wei's new generation gigabit access switches. Based on HW unified VRP software platform, CloudEngine S5731-S series switches have enhanced Layer 3 features, support MPLS, simple operation and maintenance, intelligent iStack stacking, flexible Ethernet networking, mature IPv6 features, and other features. Widely used in medical, retail, mining, Internet and other industries.
CloudEngine S5731-S series switches are Hua wei's new generation gigabit access switches. Based on HW unified VRP software platform, CloudEngine S5731-S series switches have enhanced Layer 3 features, support MPLS, simple operation and maintenance, intelligent iStack stacking, flexible Ethernet networking, mature IPv6 features, and other features. Widely used in medical, retail, mining, Internet and other industries.
Super power supply
Multi-purpose network
Cooperative security
Multi-purpose network
Cooperative security
Item | Details |
Description | S5731-S8UM16UN2Q (8*100M/1/2.5/5/10G,16*100M/1/2.5G ports, 2*40GE QSFP ports or 12*100M/1/2.5/5/10G,12*100M/1/2.5G ports, 4*10GE SFP+ ports, PoE++, without power module) |
Part Number | 02354VCD |
Model | S5731-S8UM16UN2Q |
First supported version | V200R022C00 |
Details Images
Specification
Item | Specification |
Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) |
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 454.0 mm (1.72 in. x 17.4 in. x 17.87 in.) | |
Dimensions with packaging (H x W x D) [mm(in.)] | 185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.) |
Chassis height [U] | 1 U |
Weight without packaging [kg(lb)] | 6.83 kg (15.06 lb) |
Weight with packaging [kg(lb)] | 9.81 kg (21.63 lb) |
Typical power consumption [W] | 126 W |
Typical heat dissipation [BTU/hour] | 429.93 BTU/hour |
Maximum power consumption [W] | Without PoE: 171 W |
Full PoE load: 2571 W (PoE: 2268 W) | |
Maximum heat dissipation [BTU/hour] | Without PoE: 583.48 |
Full PoE load: 8772.60 | |
MTBF [year] | 54.08 year |
MTTR [hour] | 2.22 hour |
Availability | >0.99999 |
Noise at normal temperature (acoustic power) [dB(A)] | Three 600 W AC PoE power modules with 30% load: 50.50 dBA |
Three 1000 W AC PoE power modules with 30% load: 52.50 dBA | |
Three 1000 W DC PoE power modules with 30% load: 52.50 dBA | |
Noise at normal temperature (acoustic pressure) [dB(A)] | Three 600 W AC PoE power modules with 30% load: 36.82 dBA |
Three 1000 W AC PoE power modules with 30% load: 38.82 dBA | |
Three 1000 W DC PoE power modules with 30% load: 38.82 dBA | |
Number of card slots | 0 |
Number of power slots | 3 |
Number of fans modules | 2 |
Redundant power supply | 1+1+1 |
Pluggable AC and DC power modules can be used together in the same switch. | |
Long-term operating temperature [°C(°F)] | -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
Short-term operating temperature [°C(°F)] | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) |
Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
The device can work for a short period of time when the operating temperature is beyond the normal range, but the following conditions must be met: | |
The operating temperature can exceed 45°C (113°F) for a maximum of 96 consecutive hours in a year. | |
The total time when the operating temperature exceeds 45°C (113°F) in a year is less than or equal to 360 hours. | |
The number of times the operating temperature exceeds 45°C (113°F) is less than or equal to 15 in one year. | |
If any of the preceding conditions is not met, the device may be damaged or an unknown error may occur. | |
Devices cannot start when the temperature is lower than 0°C (32°F). The maximum transmission distance of an optical module used for short-term operation cannot exceed 10 km. | |
Storage temperature [°C(°F)] | -40°C to +70°C (-40°F to +158°F) |
Long-term operating relative humidity [RH] | 5% to 95%, noncondensing |
Long-term operating altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Power supply mode | Pluggable power supply |
Rated input voltage [V] | AC input: 100 V AC to 130 V AC, 200 V AC to 240 V AC; 50/60 Hz |
High-voltage DC input: 240 V DC | |
DC input: –48 V DC to –60 V DC | |
Input voltage range [V] | AC input: 90 V AC to 290 V AC; 45 Hz to 66 Hz |
High-voltage DC input: 190 V DC to 290 V DC | |
DC input: -38.4 V DC to -72 V DC | |
Maximum input current [A] | The current specifications are related to the pluggable power module. For details, see Pluggable Power Modules. |
Memory | 2 GB |
Flash memory | 1 GB in total. To view the available flash memory size, run the display version command. |
Console port | RJ45 |
Eth Management port | RJ45 |
USB | Supported |
RTC | Supported |
RPS input | Not supported |
Service port surge protection [kV] | Common mode: ±7 kV |
Power supply surge protection [kV] | Configured with AC power modules: ±6 kV in differential mode and ±6 kV in common mode |
Configured with DC power modules: ±2 kV in differential mode and ±4 kV in common mode | |
Types of fans | Built-in |
Heat dissipation mode | Heat dissipation with fan, intelligent fan speed adjustment |
Airflow direction | Air intake from the front and left and air exhaust from the rear |
PoE | Supported |
Certification | EMC certification |
Safety certification | |
Manufacturing certification |
