3000 Вт лазерная машина для резки металла ультра Точная Нержавеющая сталь алюминиевая медь экономичная Лазерная резка
- Категория: >>>
- Поставщик: Hg Star Technology Co. Ltd.
Сохранить в закладки 1601272839749:
Описание и отзывы
Характеристики
Product Description
Adopting World Famous Germany Fiber laser source and USA Laser Mech cutting head & Dynamic Focus System, it can cut and punch different kind of metal material with high precision and high speed.
Since laser is transmitted by fiber, it is no need to maintenance or adjusts the laser optical path. It greatly reduces the machines fault rate and prolongs the working life.
| Laser Type | Imported Fiber Laser | |
| Laser Technology | Germany Technology | |
| Working area | 3000*1500 mm | |
| X axis Stroke | 3050 mm | |
| Y axis Stroke | 1500 mm | |
| Z axis Stroke | 150 mm | |
| Transmission way | Imported ball screw | |
| Table-driven system | Japanese Panasonic Servo motor & Driver | |
| Focus Method | Dynamic Following and Automatic Adjust Focus | |
| Location precision | ≤±0.05 mm | |
| Re-location precision | ±0.02 mm | |
| Max. moving speed | 100m/min | |
| Laser wavelength | 1070nm | |
| Minimum line width | ≤0.1mm | |
| Supporting Format | PLT, DXF, BMP, AI | |
| Power demand | 380V/50HZ | |
Laser Cuting Product features:
1.Whole Machine welded bed structure,Stable performance,could ensure the stable operation of equipment
2.After high temperature heat treatment Machine bed, adopt large Gantry milling accuracy process, ensure machine bed
stability and smoothness.
3.Operating system, man-machine interface, easy to operate
4.High quality, high efficiency fiber laser producer. low processing cost and energy conservation and environment protection
5.Servo drive,The structure of the machine tool adopts rack and pinion drive,Ensure equipment high speed , high accuracy, and high reliability.
6. Fast delivery 1kw high power CNC metal sheet pipe fiber laser cutting machine , 1000W, 1500W, 2000W, 3000W,6000W, 8000W fiber laser power available
7. laser cutting machine adopts IPG,RAYCUS fiber laser source brand available
8. High speed, high accuracy, stable performance, best quality
9. Support Factory Inspection
Laser Cutting Application:
Used for cutting a variety of metal plates, mainly used in stainless steel, carbon steel, galvanized sheet, electrolytic plate,brass, aluminum, various alloy plate, rare metal and other metal materials.
HGSTAR fiber laser cutting machine can carry up to 8000W laser power, so cutting some thick plate, it is a very good choice. For example, agricultural machinery, textile machinery, food machinery and construction machinery and other large machinery and equipment manufacturing, usually use high power fiber laser cutting machine for processing.
Suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, aluminum-plating,zinc plate, copper and other metals.In addition, it possesses high brightness levels and lower reflectivity as well as solid glass panel sturdiness and durability.
Company Information
ABOUT HGTECH
Founded in 1999, HGTECH was launched to the public in Shenzhen Stock Exchange in 2000. It was the first laser based high-tech company to be introduced in China, also a leader in the laser industry and one of the top 100 electronic information companies domestically. With laser technology and applications in mind as its main business, in light of the growing global trend of remanufacturing, the company is pooling premium resources in order to develop smart manufacturing products and solutions based on shaping industrial planning of laser manufacturing equipment, optical communication devices, 3D laser counterfeiting and sensors Tracking information.
HGTECH owns several technology companies such as HGLASER, HG-FARLEY, HGGAOLI, HGIMAGE,HGSTAR and HGCYBER with a large share in the Chinese market. HGTECH is committed to providing the highest quality and cost-effective products and services to our customers around the world, and since 1977, HGFARLEY Laboratories has devoted research to laser technology. The latest laser cutting machines offer 12000 watts of power, achieving 1256 holes per minute, which means 21 holes per second with Raycus Laser source with
a 5-year warranty. And our company has established good cooperative relationships with many top 500 companies in the world such as Samsung, Microsoft, Carrier, Alcatel-Lucent, Tesla, IBM, APPLE and many more.
FAQ
Q1. Before send me an inquiry on our cnc laser, it is better for you to provide me the following information:
1) Your metal or non-metal material size. Because in our factory, we have different models according to working area.
2) Your materials. Metal/Acrylic/Plywood/MDF?
)You want to engrave or marking? If cut,could you tell me your marking material? Because different material needs different laser sorace power and laser power supplier.
Q2. If we don't know how to use the machine, can you teach us?
Yes. We will send you manual and guide vedio in English, it can teach you how to operate the machine. If you still can not learn how to use it, we can help you by "Teamviewer" online help software. Or we can talk by phone,email or skype.
Q3. How long is the delivery time?
For standard machines, it would be 3-15 days; For non-standard machines and customized machines according to client's specific requirements, it would be 7 to 30 days.
Q4. Quality Control:
The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before leaving out of factory. Our machine passed CE Certificate, meet European and American standard, were exported to more than 60 Countries.
Q5. Do you arrange shipment for the machines?
Yes. For FOB or CIF price,we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
