Overview
Video Description
Product Introduction
Grid type ball mill is a common sand making equipment. It is mainly used for processing and crushing ore raw materials such as feldspar,
quartz, river pebble. To achieve the purpose of making sand. The rod mill type sand making machine is widely used, is a practical
and reliable crushing machine, and is one of the sand and gravel equipment widely used in the sand and gravel industry.
quartz, river pebble. To achieve the purpose of making sand. The rod mill type sand making machine is widely used, is a practical
and reliable crushing machine, and is one of the sand and gravel equipment widely used in the sand and gravel industry.
Advantages
. Save power:
Compared with traditional old equipment, it can save more than 40% of power and increase production capacity by 10-20%. The particle size of the product is more uniform, with less coarse particles and slime. Compared with the particle size characteristics of the rod mill product and the ball mill product, the particle size characteristic curve of the product of the rod mill working in the open circuit is almost the same as that of the ball mill working in the closed circuit.
2. Advanced technology:
Adopt advanced controllable inlet and outlet rod mill sand making machine technology, combined with the actual user's grinding material and use suitable grinding body, changed the surface contact of traditional ball mill to line contact so that the particle size of the rod mill sand making machine More uniform and higher output, suitable for ore with different hardness (Mohs hardness 5.5-12).
Compared with traditional old equipment, it can save more than 40% of power and increase production capacity by 10-20%. The particle size of the product is more uniform, with less coarse particles and slime. Compared with the particle size characteristics of the rod mill product and the ball mill product, the particle size characteristic curve of the product of the rod mill working in the open circuit is almost the same as that of the ball mill working in the closed circuit.
2. Advanced technology:
Adopt advanced controllable inlet and outlet rod mill sand making machine technology, combined with the actual user's grinding material and use suitable grinding body, changed the surface contact of traditional ball mill to line contact so that the particle size of the rod mill sand making machine More uniform and higher output, suitable for ore with different hardness (Mohs hardness 5.5-12).
Working Principle
Grid type Ball mill
a discharge grid plate is installed in the cylinder at the discharge end . There are grid holes of different shapes on the grid plate. When the mill rotates, the slurry flows into the discharge chamber (the space formed by the grid plate and the cylinder end cover) through the grid holes at the discharge end of the cylinder and is discharged from the discharge port. This accelerated discharge effect can keep the slurry surface at the discharge end of the cylinder low, thereby accelerating the flow of slurry in the mill cylinder, reducing over-crushing of materials and improving the production capacity of the mill.
Technical Paramenters
Model | Cylinder Diameter(mm) | Cylinder Length(mm) | Motor Power(kw) | Effective Volume(m³) | Max. Ball Load(t) | Weight(KG) | Size(L*W*H )(mm) |
G0909 | 900 | 900 | 18.5 | 0.45 | 0.96 | 4620 | 4750*2213*2050 |
G0918 | 900 | 1800 | 22 | 0.9 | 1.92 | 5340 | 5000*2280*2050 |
G1212 | 1200 | 1200 | 22 | 1.14 | 2.4 | 11438 | 5788*2994*2540 |
G1224 | 1200 | 2400 | 55 | 2.28 | 3.96 | 13200 | 6094*3300*2766 |
G1515 | 1500 | 1500 | 60 | 2.5 | 5 | 13700 | 7979*3300*2766 |
G1530 | 1500 | 3000 | 95 | 5 | 10 | 18690 | 7750*4839*3794 |
G2122 | 2100 | 2200 | 155 | 6.6 | 15 | 45400 | 8744*4395*3110 |
G2130 | 2100 | 3000 | 210 | 9 | 20 | 45790 | 9728*4856*4018 |
G2430 | 2400 | 3000 | 280 | 12.1 | 22.5 | 67000 | 9300*5500*4500 |
G2721 | 2700 | 2100 | 280 | 10.7 | 24 | 63000 | 9900*5500*4500 |
G2727 | 2700 | 2700 | 310 | 13.8 | 29 | 68530 | 9765*5827*4675 |
G2736 | 2700 | 3600 | 400 | 18.4 | 41 | 98020 | 12750*6750*5153 |
G3231 | 3200 | 3100 | 630 | 22.5 | 45 | 115103 | 14300*6760*5200 |
G3236 | 3200 | 3600 | 630 | 24.8 | 58 | 119012 | 13896*7200*5153 |
Production Process
Contact Us
Raw Materials&Final Products
Before Ball mill
After going through Ball mill machine
Company Profile
Customer Visit
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: 30% advanced payment by T/T, balance paid before shipment.
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: 30% advanced payment by T/T, balance paid before shipment.
