Low voltage input | Rated DC voltage | 12VDC |
Rated current | 2A | |
Current range | 0~2A | |
rated power | 24W | |
Voltage tolerance | 12±0.5V | |
Ripple and noise | 120mVp-p | |
load | ±2% | |
Setting, rise time | 50ms/230VAC | |
residence time | 20ms/230VAC | |
High voltage input | Rated AC voltage | 100~240VAC |
rated power | 500W | |
input | Voltage range | 100~240VAC; |
Frequency range | 50~60Hz | |
Efficiency (typical value) | >81% | |
Leakage current | 0.25mA/240VAC | |
protect | Overcurrent | 110%~150% |
Protection type: Hiccup mode | ||
short circuit | Short circuit protection | |
environment | operation temperature | -25℃~50℃ |
storage temperature | -40℃~80℃ | |
vibrate | 10~500Hz,2G 10min/1 cycle,cycle 60min,Once along the X, Y, and Z axes | |
Working temperature | ±0.03%/℃(0~50℃) | |
electromagnetic compatibility | withstanding voltage | I/P-O/P:3KVAC, I/P-COVER: 3KVAC , O/P-COVER:500VAC |
insulation resistance | I/P-O/P:>100M Ohms/500VDC/25℃/70% RH | |
electromagnetic compatibility | EN55015:2006/A2:2009,EN61000-3-2:2006/A2:2009,EN61000-3-3:2008,EN61547:2009 | |
other | Mean time between failures | 50K hour (25℃) |
Length of outgoing line | Default 200mm,customized |
