Лучшая цена EPS цементная сэндвич-стеновая панель для легкой установки на крыше склад здание внешняя теплоизоляционная мастерская
761,79 ₽ - 1 313,81 ₽
Лучшая цена Современная цементная сэндвич стенка на крыше склад гостиничная мастерская внешняя теплоизоляция легкая установка металлический PIR
- Категория: >>>
- Поставщик: Xiamen Zhongjingtai Building Materials Co. Ltd.
Сохранить в закладки 1601273544977:
Описание и отзывы
Характеристики
Product Description
A color steel wall panel is a metal panel that is coated with a layer of colored steel for both aesthetic and functional purposes. These panels are commonly used as exterior wall claddings for buildings as they provide durable protection against weather conditions and enhance the overall appearance of the building. The color steel wall panel is typically lightweight, easy to install, and requires little maintenance. The range of colors and finishes available makes it a popular choice for architectural projects, particularly in the commercial and industrial sectors.
Specification
Name | EPS | XPS | PU | PIR | PF | RW/SW | GW |
Thickness(mm) | 50/75/100/150/200 | 50/75/100 | 50/75/100 | 50/75/100 | 20-200 | 50/80/100/120/200 | 50/80/100/120/150 |
Application | wall/roof | roof | wall/roof | wall/roof | wall/roof | wall | wall |
Density(kg/m3) | ≥18 | ≥35 | ≥38 | ≥45 | ≥60 | ≥100 | ≥64 |
Heat Conductivity(W/m2.k) | 0.68 | 0.63 | 0.45 | 0.5 | 0.063 | 0.85 | 0.9 |
Thermal Conductivity(W/m.k) | ≤0.041 | ≤0.03 | 0.024 | 0.02 | 0.035 | 0.045 | 0.042 |
Oxygen Index(%) | 30 | 30 | 28 | 32 | 43 | 32 | 32 |
Water Absorption | 6 | 2 | 3 | 2 | 7.5 | 5 | 5 |
Fire Resistance Rating | - | - | - | - | 1min | ≥30min | - |
Applicable Temperature | ≥75 | ≥75 | 120 | 160 | 180 | 600 | 400 |
Combustion Performance | B2 | B2 | B1 | B1 | B1 | A | A |
Compresion Strength | 120kPa | 200kPa | 150kPa | 220kPa | 100kPa |
Width: | Wall panel: 950mm 1150mm 1200mm; Roof panel: 950mm 980mm |
Length: | According to customer' s request |
Material: | Polystyrene foam board(EPS), Color steel sheet |
Structure: | Upper and lower layer: Color steel sheet |
Core material: polystyrene foam board or polyurethane foam board | |
Treatment: | Pressing |
Thickness: | Color steel sheet: 0.3-0.8mm Polystyrene foam board: 50mm 75mm 100mm 150mm 200mm |
Density: | 8-20kg/m3 Polystyrene |
Life Period: | 15-20 years |
Package: | PVC foil |
Usage: | various roofs and walls referring to the large size industry factory, storages, exhibition halls, gymnasiums, outdoor shelter etc. |
Color
Color steel panels can be produced in multiple colors by using a process called color coating. This involves applying a layer of paint or pigment to the surface of the steel sheet before it is shaped into the desired form. The color options are almost limitless and can be tailored to suit specific aesthetic requirements. The color-coated steel sheets are not only visually appealing but also offer excellent protective properties against corrosion and other forms of damage. This versatility of color steel sheets makes them a popular choice for a wide range of applications, including roofing, cladding and so on.
Roof and wall application
Supplying the most advanced & innovative high quality products & services
Color steel plate is a type of versatile building material made of high-quality steel sheets coated with various colors of paint.
It has been widely used in various fields due to its outstanding advantages such as strong durability, high weather resistance,
and easy maintenance. In the construction industry, color steel plates are commonly used for roofing, wall cladding, and partition
walls. They are ideal roofing materials for industrial buildings, warehouses, workshop factories, and high-rise buildings due to
their lightweight and high load-bearing capacity. In addition, color steel plates are also popular in the residential construction
field as they can be used for fences, garages, or even as decorative elements on doors and windows.
It has been widely used in various fields due to its outstanding advantages such as strong durability, high weather resistance,
and easy maintenance. In the construction industry, color steel plates are commonly used for roofing, wall cladding, and partition
walls. They are ideal roofing materials for industrial buildings, warehouses, workshop factories, and high-rise buildings due to
their lightweight and high load-bearing capacity. In addition, color steel plates are also popular in the residential construction
field as they can be used for fences, garages, or even as decorative elements on doors and windows.
Packing & Delivery
The plates are typically transported via truck or shipping container, with proper precautions taken to ensure safe and secure transportation. This may include using specialized equipment such as forklifts or cranes to load and unload the plates, as well as securing the plates in place within the transportation vehicle to prevent movement during transit.
Additionally, adequate labeling and documentation may be required to ensure proper handling and delivery of the color steel plates to their final destination. This may include providing information on the size, weight, and quantity of plates, as well as any special handling or storage requirements. Overall, proper packaging and transportation are critical aspects of ensuring the safe and efficient delivery of color steel plates to their intended destination.
FAQ
Q. What is a color steel plate?
A: A color steel plate is a kind of steel plate that is coated with a layer of colored paint or polymer film. The coating helps protect the steel from rust and weathering, and also enhances its aesthetic appeal.
Q.What are the benefits of using color steel plates?
A: Color steel plates have several benefits, including durability, resistance to corrosion and weathering, lightweight, versatility, and easy installation. They are widely used in construction projects, such as roofing, walls, and fencing.
Q. What types of coatings are used for color steel plates?
A: There are various types of coatings used for color steel plates, including polyester, fluorocarbon, silicone, and plastisol. Each has its own unique properties and applications, and the choice of coating depends on the preferences and requirements of the user.
Q.How are color steel plates installed?
A: Color steel plates are typically installed using screws or nails, and they can be cut to size and shaped as needed. They can also be installed over existing materials, such as wood or concrete, to create a new surface.
Q.How long do color steel plates last?
A: The lifespan of color steel plates depends on various factors, such as the quality of the materials, the type of coating, and the environmental conditions. Generally, they can last anywhere from 20 to 50 years or more with proper maintenance and care.
Q.What maintenance is required for color steel plates?
A: Color steel plates require minimal maintenance, such as periodic cleaning to remove dirt and debris. The coating may need to be repainted or repaired over time to ensure its continued protection and aesthetic appeal.
Q.What are the environmental benefits of using color steel plates?
A: Color steel plates are 100% recyclable and can be reused in other construction projects. They also require less energy and resources to produce compared to other building materials, making them a more sustainable choice.
A: A color steel plate is a kind of steel plate that is coated with a layer of colored paint or polymer film. The coating helps protect the steel from rust and weathering, and also enhances its aesthetic appeal.
Q.What are the benefits of using color steel plates?
A: Color steel plates have several benefits, including durability, resistance to corrosion and weathering, lightweight, versatility, and easy installation. They are widely used in construction projects, such as roofing, walls, and fencing.
Q. What types of coatings are used for color steel plates?
A: There are various types of coatings used for color steel plates, including polyester, fluorocarbon, silicone, and plastisol. Each has its own unique properties and applications, and the choice of coating depends on the preferences and requirements of the user.
Q.How are color steel plates installed?
A: Color steel plates are typically installed using screws or nails, and they can be cut to size and shaped as needed. They can also be installed over existing materials, such as wood or concrete, to create a new surface.
Q.How long do color steel plates last?
A: The lifespan of color steel plates depends on various factors, such as the quality of the materials, the type of coating, and the environmental conditions. Generally, they can last anywhere from 20 to 50 years or more with proper maintenance and care.
Q.What maintenance is required for color steel plates?
A: Color steel plates require minimal maintenance, such as periodic cleaning to remove dirt and debris. The coating may need to be repainted or repaired over time to ensure its continued protection and aesthetic appeal.
Q.What are the environmental benefits of using color steel plates?
A: Color steel plates are 100% recyclable and can be reused in other construction projects. They also require less energy and resources to produce compared to other building materials, making them a more sustainable choice.
Contact information
Brittany wang
Add: 403B,10th floor Guanyinshan International Business Center , Xiamen,Fujian, China
Tex: +86-592-5216902 Fax: +86-592-5216317
Mobile/Whatsapp/Wechat: +8618050013929
Website: www.zhongjingtai.com
Add: 403B,10th floor Guanyinshan International Business Center , Xiamen,Fujian, China
Tex: +86-592-5216902 Fax: +86-592-5216317
Mobile/Whatsapp/Wechat: +8618050013929
Website: www.zhongjingtai.com
Email: sales10@zhongjingtai.com
