Мини безвентиляторный с I5-1135U процессором 11-го поколения 8 ГБ оперативной памяти 256 SSD M.2 4 USB 3 0 и 2 порта LAN промышленный компьютер
38 684,17 ₽
Новинка i5 8265U виски озера 3 5 дюймов i5 10210U промышленный мини ПК с 1 LAN i219V 4096/3840*2160 @ 30 Гц компьютерный ПК для IOT Industry
- Категория: >>>
- Поставщик: Shenzhen Haohaisheng Technology Co. Ltd.
Сохранить в закладки 1601281771566:
Описание и отзывы
Характеристики
Product Paramenters
Products Description
Price notice:
Price notice:
1) Prices are for barebone Mini PCs (motherboard + CPU+ case + fan( or without FAN) + discrete graphics).If you need OPS card, memory, storage,
WIFI, OS license, 3G/4G/5G, GPS, power adapter, etc., contact us for prices.2) Prices vary by configuration. We'll quote as per
your request.
3) For large - quantity purchases or info on promotions/clearance, contact us for the best price.
4) Product - link prices are for reference only. For the latest price, contact us.
5) Notice:Prices may change with exchange rates and material costs. All pricesand specs are subject to change without notice.
Thank you! Contact Sophia
1) Prices are for barebone Mini PCs (motherboard + CPU+ case + fan( or without FAN) + discrete graphics).If you need OPS card, memory, storage,
WIFI, OS license, 3G/4G/5G, GPS, power adapter, etc., contact us for prices.2) Prices vary by configuration. We'll quote as per
your request.
3) For large - quantity purchases or info on promotions/clearance, contact us for the best price.
4) Product - link prices are for reference only. For the latest price, contact us.
5) Notice:Prices may change with exchange rates and material costs. All pricesand specs are subject to change without notice.
Thank you! Contact Sophia
Most Important：
1)Power supply interface:
The motherboard DC interface specification is 5.5*2.5, and can be changed to 4Pin ATX interface for power supply;
The motherboard only supports 12V power supply; the full load power consumption is about 60W, and it is recommended to use a 12V7A or above power supply;
2)Display interface:
1. The motherboard VGA, HD, LVDS/EDP support single display, dual display/triple display copy, dual display/triple display expansion, and single display under DOS;
2. The motherboard supports vertical 1.4 HD interface, supports 4K output; supports resolution 4096/3840*2160@30Hz;
3. The motherboard LVDS and EDP signals are selected one by one, LVDS is supported by default, and EDP can be supported, the pins are shared, and EDP uses EDP-B screen cable (20Pin backlight is separated and independent);
3) Mini-PCIE:
Motherboard MSATA interface The default SATA signal supports MSATA disks; there is no USB signal and it cannot be changed to coexist with USB signal. The SATA signal can be changed to PCIE signal, and the WiFi module is supported after the change;
The default PCIE signal of the motherboard Mini-PCIE interface is PCIE signal, there is no USB signal, and it only supports WIFI module by default; it can be changed to coexist with USB signal, and it supports 4G/Bluetooth/WIFI module after the change. After the change, the 2nd/4th/6th/8th/10th pins of F_USB2 pins have no signal, and the Mini-PCIE interface cannot be changed to SATA signal;
The motherboard DC interface specification is 5.5*2.5, and can be changed to 4Pin ATX interface for power supply;
The motherboard only supports 12V power supply; the full load power consumption is about 60W, and it is recommended to use a 12V7A or above power supply;
2)Display interface:
1. The motherboard VGA, HD, LVDS/EDP support single display, dual display/triple display copy, dual display/triple display expansion, and single display under DOS;
2. The motherboard supports vertical 1.4 HD interface, supports 4K output; supports resolution 4096/3840*2160@30Hz;
3. The motherboard LVDS and EDP signals are selected one by one, LVDS is supported by default, and EDP can be supported, the pins are shared, and EDP uses EDP-B screen cable (20Pin backlight is separated and independent);
3) Mini-PCIE:
Motherboard MSATA interface The default SATA signal supports MSATA disks; there is no USB signal and it cannot be changed to coexist with USB signal. The SATA signal can be changed to PCIE signal, and the WiFi module is supported after the change;
The default PCIE signal of the motherboard Mini-PCIE interface is PCIE signal, there is no USB signal, and it only supports WIFI module by default; it can be changed to coexist with USB signal, and it supports 4G/Bluetooth/WIFI module after the change. After the change, the 2nd/4th/6th/8th/10th pins of F_USB2 pins have no signal, and the Mini-PCIE interface cannot be changed to SATA signal;
4）USB interface:
The motherboard supports 10USB (2*USB3.0, 8*USB2.0) by default, and supports 9USB after changing to support 4G/Bluetooth ;
All USB ports and pins on the motherboard default to S power (no power after shutdown), external USB ports can be changed to A power (power after shutdown), and built-in USB pins cannot be changed to A power;
The motherboard supports 10USB (2*USB3.0, 8*USB2.0) by default, and supports 9USB after changing to support 4G/Bluetooth ;
All USB ports and pins on the motherboard default to S power (no power after shutdown), external USB ports can be changed to A power (power after shutdown), and built-in USB pins cannot be changed to A power;
5）COM port:
The motherboard supports 6*COM ports, and supports RS232 by default; COM1 supports RS232/422/485 optional, through BIOS settings (page 23);
The 9th pin of motherboard COM1/2 can be set to 0V/5V/12V through JPCOM1/2, and the default is 0V;
The motherboard supports 6*COM ports, and supports RS232 by default; COM1 supports RS232/422/485 optional, through BIOS settings (page 23);
The 9th pin of motherboard COM1/2 can be set to 0V/5V/12V through JPCOM1/2, and the default is 0V;
6）Network card:
The motherboard supports Intel i226-V dual-gigabit network card, triple-gigabit network card, and quad-gigabit network card optional; POE power supply cannot be changed;
Sound card:
The motherboard supports Realtek sound card by default, and USB sound card cannot be changed;
The motherboard supports Intel i226-V dual-gigabit network card, triple-gigabit network card, and quad-gigabit network card optional; POE power supply cannot be changed;
Sound card:
The motherboard supports Realtek sound card by default, and USB sound card cannot be changed;
Product packaging
Packaging Details | Every item is packed with individual Anti-static bubble bag and separated by stiff cardboards in carton boxes. 1Piece/Carton, 5Pieces/Carton, 10Pieces/Carton |
Company Profile
FAQ
Q1: Can you put my brand name (logo) on these products or provide customized solutions
A: Yes, we can support OEM/ODM service, the process of customization is following:(1) Provide your specific requirement.(2) Our engineer draws the design draft
(3) You confirm the design draft.(4) We start produce it.
Q2: What is the Minimum Order Quantity (MOQ)?
A: We can sell one piece of sample for your test.
Q3: What is the lead time of your products?
A: 3 working days for a few samples, 15 working days for a large quantity, support negotiation.
Q4: Will it be ok to run the device 24 hours a day and 7 days a week, just like a desktop PC? Will it be overheated?
A: There's no problem with running the device 24/7. l've done it for about a month and have had no problems. Just
set your monitor to sleep when you're not using the computer.
set your monitor to sleep when you're not using the computer.
Q5: What is the quality control in your factory?
A: Quality is our top priority. We have IQC (Incoming Quality Control), production inspection, reliability testing, out-going inspection and after sales data analysis etc..
Q6: What's the warranty of your products?
A: Non-artificial damage, 1 years warranty. The second year and the third year, we can repair it free, but we will only charge the actual costs of the parts that needs to be replaced.
Q7: Are you a factory or trading company?
A: We are a professional consumer electronics trading company which located in Shenzhen, China.
Q8: What Payment Methods Your Company Accept?
A:It’s Usually Wire Transfer T/T. For Partner Relationship, We May Consider Other Payment Terms.
Q9: How Do You Guarantee The Quality Of Your?
A:Our Products Comply With And CCC/ CE/ FCC /ROHS /CQC /EN50155/IEC EN 60945/EN 50121/EN 60601 Standards.
